General
External power supply .............. 100 VAC to 240 VAC, 50-60 Hz, external; to 12 VDC, 1 A, regulated
Power input requirements ......... 12 VDC, 0.5 A
Temperature/humidity ............... Storage: -40 to +158 °F (-40 to +70 °C) / 10% to 90%, noncondensing
Cooling .................................... Convection, no vents
Thermal dissipation
115 VAC, 60 Hz .................. 4.6 BTU/hr
240 VAC, 50 Hz .................. 5.5 BTU/hr
Mounting
Rack mount ........................ Yes, with optional 1U rack shelf
Furniture mount ................. Yes, with optional under-desk mounting kit or through-desk mounting kit
Enclosure type .......................... Metal
Enclosure dimensions ................ 1.75" H x 8.75" W x 3.0" D (1U high, half rack wide)
Product weight ......................... 0.5 lbs (0.3 kg)
Shipping weight ....................... 2 lbs (1 kg)
Vibration .................................. ISTA 1A in carton (International Safe Transit Association)
Regulatory compliance
Safety ................................. CE, c-UL, UL
EMI/EMC ............................ CE, C-tick, FCC Class A, ICES, VCCI
MTBF ........................................ 30,000 hours
Warranty .................................. 3 years parts and labor
NOTE: All nominal levels are at ±10%.
Specifications are subject to change without notice.
Operating: +32 to +122 °F (0 to +50 °C) / 10% to 90%, noncondensing
(4.4 cm H x 22.2 cm W x 7.6 cm D)
(Depth excludes connectors.)
SW HDMI LC • Reference Information
23
