Figure 15.
Add Device Window
NOTE:
Although the screen also has a TCP/IP tab, the SW HDMI LC does not have
a LAN port. Do not select the TCP/IP tab.
5.
Click Connect. Your switcher name is added to the Connected Devices field in
Firmware Loader window.
6.
In the New Firmware File (Optional) section, click Browse.
7.
In the Open window, locate the firmware file to be uploaded to your switcher and
double-click on its name. The file extension must be .S19.
CAUTION:
Uploading a file with an incorrect extension may cause the unit to
stop functioning.
Figure 16.
Selecting the Firmware File
The path to the selected firmware file appears in the Path field on the Add Device
screen.
SW HDMI LC • Remote Communication and Control
19
