Installation/OPERATION MANUAL
TRENDSETTER Gas Convection Oven
MODELS:
PLEASE READ ALL SECTIONS OF THIS MANUAL
THIS PRODUCT HAS BEEN CERTIFIED AS COMMERCIAL COOKING EQUIPMENT AND MUST BE INSTALLED
BY PROFESSIONAL PERSONNEL AS SPECIFIED.
WE SUGGEST INSTALLATION, MAINTENANCE AND REPAIRS SHOULD BE PERFORMED BY YOUR LOCAL
AUTHORIZED GARLAND SERVICE AGENCY LISTED IN YOUR INFORMATION MANUAL PAMPHLET.
In the event you have any questions concerning the installation, use, care or service of the product, write our
Customer Service Department.
NOTE: Unit must be installed with no less than 6" clearance from Combustible construction at rear and sides.
RETAIN FOR FUTURE REFERENCE.
Printed in U.S.A.
TG3/4, TTG3/4
TG3/4-CH: TTG3/4-CH;
TG3/4-X: TTG3/4-X
TG3/4V; TTG3/4V;
TG3/4EC-CH; TTG3/4EC-CH
Continuous product improvement is a Garland policy, therefore
Specifications and design are subject to change without notice.
Garland Commercial Industries, Inc.
Freeland, Pennsylvania 18224
Phone (717) 636-1000
Telex 887610
