Summary of Contents for Hanns.G HS233
- Page 1 HS233 HSG 1155...
- Page 2 Electromagnetic Compatibility, and 73/23/EEC and 93/68/EEC with regard to Low Voltage directive. Socket-outlet shall be near the equipment and shall be accessible. Trademark Notice: Hanns.G products incorporate High-Definition Multimedia Interface (HDMI ) technology. HDMI, the HDMI Logo, and High-Definition Multimedia Interface are trademarks or registered...
-
Page 3: Recycling Information
User’s Manual RECYCLING INFORMATION We, the Hanns.G care very much about our environment protection strategy and firmly believe that it helps us have healthier earth via appropriate treatment and recycling of industrial technology devices at the end-of-life. These devices contain recyclable materials, which can be re-decomposed and re-integrated into brand-new marvels. -
Page 4: Table Of Contents
User’s Manual TABLE OF CONTENTS SAFETY NOTICE ....................5 PRECAUTIONS....................5 SPECIAL NOTES ON LCD MONITORS ............6 BEFORE YOU OPERATE THE MONITOR ............7 FEATURES......................7 CHECKING THE CONTENTS OF THE PACKAGE ........7 INSTALLATION INSTRUCTIONS ..............8 POWER....................... 8 SETTING THE MONITOR ON THE WALL .......... -
Page 5: Safety Notice
User’s Manual SAFETY NOTICE 1. The changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. 2. Shielded interface cables and AC power cord, if any, must be used in order to comply with the emission limits. -
Page 6: Special Notes On Lcd Monitors
User’s Manual SPECIAL NOTES ON LCD MONITORS The following symptoms are normal with LCD monitor and do not indicate a problem. Due to the nature of the fluorescent light, the screen may flicker during initial use. Turn off the Power Switch and then turn it on again to make sure the flicker disappears. -
Page 7: Before You Operate The Monitor
User’s Manual BEFORE YOU OPERATE THE MONITOR FEATURES 58,4cm / 23” Wide Screen TFT Color LCD Monitor Crisp, Clear Display for Windows GP Green Product Ergonomic Design Space Saving, Compact Case Design CHECKING THE CONTENTS OF THE PACKAGE The product package should include the following items: LCD Monitor Cables and User manual... -
Page 8: Installation Instructions
User’s Manual INSTALLATION INSTRUCTIONS INSTALL REMOVE Figure.1. Installing and Removing the Base INSTALLATION: 1. Carefully place the monitor face down on a soft and flat surface (blanket, foam, cloth, etc) to prevent any damage to the monitor. 2. Align the base with the opening of the stand. 3. -
Page 9: Setting The Monitor On The Wall
*Installing the LCD Monitor requires special skill that should only be performed by qualified service personnel. Customers should not attempt to do the work themselves. Hanns.G bears no responsibility for improper mounting or mounting that results in accident or injury. You can ask qualified service... -
Page 10: Making Connections
User’s Manual MAKING CONNECTIONS CONNECTING TO A PC Turn off your computer before performing the procedure below. 1. Connect one end of the VGA cable to the back of the monitor and connect the other end to the computer’s VGA port. 2. -
Page 11: Adjusting The Viewing Angle
User’s Manual ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor, then adjust the monitor’s angle to your own preference. Hold the stand so you do not topple the monitor when you change the monitor’s angle. ... -
Page 12: Operating Instructions
User’s Manual OPERATING INSTRUCTIONS GENERAL INSTRUCTIONS Press the power button to turn the monitor on or off. The other control buttons are located on the front panel of the monitor (See Figure 4). By changing these settings, the picture can be adjusted to your personal preferences. -
Page 13: Front Panel Control
User’s Manual FRONT PANEL CONTROL Power Button: Press this button to switch ON/OFF of monitor’s power. Power Indicator: Blue — Power On mode. Orange — Power Saving mode. MENU: 1. Turn the OSD menu on. 2. Enter sub menu when OSD menu is ON. Adjust ▲▼: ... -
Page 14: How To Adjust A Settings
User’s Manual HOW TO ADJUST A SETTINGS PICTURE Adjust the brightness value of the display according to your preference. Select「BRIGHTNESS」option to adjust the BRIGHTNESS brightness value. Adjust the contrast value of the display according to your preference. Select「CONTRAST」option to adjust the contrast CONTRAST value. - Page 15 User’s Manual Select the「DCR」option to switch the function On or Off Select the「ECO」option to switch the function On or Off. Select the「SHARPNESS」option to adjust the sharpness of the SHARPNESS display. Set the value from 0 to 100. Select the「OD」option to switch the function On or Off. OTHER SETTINGS Select 「LANGUAGE」...
-
Page 16: Plug And Play
User’s Manual PLUG AND PLAY Plug & Play DDC2B Feature This monitor is equipped with VESA DDC2B capabilities according to the VESA DDC STANDARD. It allows the monitor to inform the host system of its identity and, depending on the level of DDC used, communicate additional information about its display capabilities. -
Page 17: Technical Support (Faq)
User’s Manual TECHNICAL SUPPORT (FAQ) Q & A FOR GENERAL PROBLEMS PROBLEM & QUESTION POSSIBLE SOLUTION *Check if the Power Switch is in the ON position. Power LED is not on *Power Cord should be connected. *Check if the PC system is Plug & Play compatible. *Check if the Video Card is Plug &... - Page 18 User’s Manual Addendum related to Windows 7 When you encounter display problem under Windows 7, you need to do the following: 1. Make sure your PC computer (Hardware requirement) can support Windows 7. 2. Make sure your video card can run Windows 7. 3.
-
Page 19: Error Message & Possible Solutions
User’s Manual ERROR MESSAGE & POSSIBLE SOLUTIONS CABLE NOT CONNECTED: 1. Check that the signal-cable is properly connected, If the connector is loose, tighten the connector’s screws. 2. Check the signal-cable’s connection pins for damage. INPUT NOT SUPPORT : Your computer has been set to unsuitable display mode, set the computer to display mode given in the following table. - Page 20 User’s Manual (HDMI INPUTS) Primary Video Format Timings MODE RESOLUTION 640×480p @ 60Hz 720×480p @ 60Hz 1280×720p @ 60Hz 720×576p @ 50Hz 1280×720p @ 50Hz 1920×1080i @ 60Hz 1920×1080i @ 50Hz Secondary Video Format Timings MODE RESOLUTION 1920x1080p @ 25Hz 1920x1080p @ 30Hz 1920x1080p @ 50Hz 1920x1080p @ 60Hz...
-
Page 21: Appendix
User’s Manual APPENDIX SPECIFICATIONS Driving system TFT Color LCD LCD Panel Size 58,4 cm / 23”Diagonal Pixel pitch 0.2655 mm(H) x 0.2655 mm(W) H-Frequency 30 kHz – 83 kHz Analog Signal Input V-Frequency 55 Hz – 76 Hz 30 kHz – 138 kHz H-Frequency (For Nvidia 3D mode up to 137.86 kHz) Digital Signal Input...
