5. Attach connectors to vehicle lower anchors.
Pull firmly on connectors to be sure they
are attached
6. Tighten LATCH by pushing down hard on
base and pulling the adjustment belt back
through belt path
7. NEVER put two LATCH connectors on one
vehicle LATCH anchor
8. Test infant restraint for secure installation as
described in infant restraint "Final Safety
Check" page 9.
9. Check that the LATCH stays tight and does not
slip from the tightened position. If it does not stay
tight, try another seating position or contact
Graco at 1-800-345-4109.
10. To remove LATCH, push button while
pulling on the LATCH belt as shown
11. Press and hold LATCH release hinge
12. Push connector in, lift connector up and
pull out (away from anchor point)
13. Repeat steps 11 and 12 for other connector.
.
.
.
.
.
.
6
CLICK!
