Omron MicroAir NE-U03V Instruction Manual

Omron MicroAir NE-U03V Instruction Manual

Portable nebulizer
Hide thumbs
Table of Contents

Advertisement

Quick Links

R
INSTRUCTION MANUAL
PORTABLE NEBULIZER
M
NE-U03V
ODEL

Advertisement

Table of Contents
loading

Related Manuals for Omron MicroAir NE-U03V

Summary of Contents for Omron MicroAir NE-U03V

  • Page 1 INSTRUCTION MANUAL PORTABLE NEBULIZER NE-U03V ODEL...

  • Page 2: Table Of Contents

    Available Accessories …………………………………………………………15 Specifications …………………………………………………………………16 Common Questions About The MicroAir …………………………………17, 18 Warranty ………………………………………………………………………20 INTRODUCTION Thank you for buying the Omron A.I.R.S. Model NE-U03V MicroAir Nebulizer. ® The MicroAir changes liquid medicine into an aerosol form. This change is done using vibration.

  • Page 3: Important Safeguards

    4. Never operate this product if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or if it has fallen into water. Return the product to OMRON Healthcare, Inc. for service. 5. Keep the cord away from heated surfaces.

  • Page 4: Know Your Unit

    KNOW YOUR UNIT Mouthpiece Mask Mesh Cap (Extra Cap Included) Vibration Horn Unit Cover Medication On/Off Button MicroAir Unit Rinse Bottle AC Adapter* Battery Lid AC Jack * The shape of the plug may vary from country to country.

  • Page 5: Cautions-Warnings

    CAUTIONS - WARNINGS 1. WARNING The most delicate part of the unit is the mesh cap.NEVER touch the mesh cap directly. Follow the cleaning instructions exactly to avoid damaging the mesh cap. (See page 10 for cleaning instructions.) 2. WARNING Before using the MicroAir for the first time, or after storing it for an extended period, be sure to clean and sterilize all necessary parts as explained on page 10.

  • Page 6: Cautions-Warnings

    CAUTIONS - WARNINGS 10. WARNING Fill the medication 9. WARNING Do not submerge the cup before using unit in water to the unit. Do not prevent damage. shake the unit dur- ing use. 11. CAUTION Assure that the 12. CAUTION Check the medication proper adapter is cup and mouthpiece used for connection...

  • Page 7: Unit Assembly

    UNIT ASSEMBLY How to Assemble A. Clean and sterilize all unit parts before the first use or after a long storage period. B. Fill the medication cup before plugging in the unit and turning on the power. 2. Attach the 1.

  • Page 8: Operating Instructions

    OPERATING INSTRUCTIONS 1. Before Operating Make sure all parts are mounted properly. Check to fill the medication up to correct level of 5 ml. 2. Plug In Connect the adapter into a standard AC 120V outlet. Four (4) "AA" alkaline batteries may also be used to run the unit.

  • Page 9: Unit Disassembly & Maintenance

    UNIT DISASSEMBLY & MAINTENANCE NOTE: The mesh cap may be damaged by hardened medication that is left in the vibration horn effecting how the unit nebulizes. The following are maintenance recommendations after each use to keep your unit working at its best level. NOTE: Be sure that the unit is turned OFF.

  • Page 10: Cleaning

    CLEANING Be sure unit is OFF and the power cord is disconnected before cleaning. Nebulizer Parts and Casing (EXCEPT MESH CAP) There are several ways to clean the medication cup and mouthpiece. A. Soak parts in a mixture of one part vinegar and three parts distilled water for 30 minutes B.

  • Page 11: Mesh Cleaning

    MESH CLEANING NOTE: The mesh cap is the most delicate part of the MicroAir. It is important not to directly touch the mesh cap. Follow the cleaning instructions to avoid damaging the mesh cap and keep it in good condition. A.

  • Page 12: Storage

    STORAGE 1. Completely dry all cleaned and sterilized parts. Mesh Cap Attach the mesh cap to the unit as describe in the operating instructions. Handle the mesh cap with care as it is very fragile and may be easily damaged. Medication Cup Attach the medication cup to the unit as described in the operating instructions.

  • Page 13: Battery Operation

    BATTERY OPERATION Using Batteries Turn the unit upside down. The battery lid will lift off by pressing down towards the arrows. Insert four (4) "AA" alkaline batteries matching the polarities to the marks( + or - ) inside the unit. Replace the battery lid by pressing downward until it clicks into place as shown on the right.

  • Page 14: Troubleshooting Guide

    Switch to AC operation. horn clean? Clean the vibration horn. ➄ Is the mesh cap broken? Replace cap. * Do not try to repair unit - no parts of the unit are user serviceable. Return unit to authorized OMRON dealer.

  • Page 15: Available Accessories

    AVAILABLE ACCESSORIES A full range of accessories make the MicroAir adjustable to virtually every requirement. Medication Cups ( Aerosol Mask ( MODEL #U03-7) MODEL #U03-2) A 5 ml Medication Cup Plastic Aerosol Mask Mouthpiece ( Mesh Cap ( MODEL #U03-3) MODEL #U03-4) Plastic Mouthpiece AC Adapter (...

  • Page 16: Specifications

    SPECIFICATIONS* Power Source: AC 120v 60 Hz Power Consumption: Approximately 1.2 w Vibration Frequency: Approximately 65 KHz Nebulization Rate: 0.25 ml/min ±0.05 Particle Size Range: 6 ~ 9.5 microns Medication Cup: Maximum capacity 5 ml Dimensions: 67 x 32 x 165 mm Weight: 148 grams, approximately 5.2 oz Battery:...

  • Page 17: Common Questions About The Microair

    COMMON QUESTIONS ABOUT THE MICROAIR Can I use any type of double “AA” batteries in the MicroAir? We recommend that alkaline batteries be used for best performance. How long will a set of batteries operate the MicroAir? The expected battery life is 300 minutes of operation. What other sources of power can the MicroAir use? The MicroAir can operate from either AC power or battery.

  • Page 18: Common Questions About The Microair

    COMMON QUESTIONS ABOUT THE MICROAIR Will the mesh break easily? The mesh is like all small delicate parts that can be broken if not gently handled. It is important that after cleaning the mesh that it be placed back on the unit. This will protect the mesh from damage while the unit is not being used.

  • Page 19: Warranty

    To make a warranty claim, return your Omron Nebulizer, freight prepaid and insured (or assume the risk of loss or damage during shipment) to OMRON HEALTHCARE, INC., 300 Lakeview Parkway, Vernon Hills, IL 60061, Attention: Service Department. All requests for warranty service should include the model number of your Omron Nebulizer, proof of purchase (including date of purchase), your phone number and the nature of your service request.
  • Page 20 Distributed by OMRON HEALTHCARE, INC. 300 Lakeview Parkway Vernon Hills, Illinois 60061 Phone: 1-800-634-4350 www.omronhealthcare.com Copyright © OMRON HEALTHCARE, INC. NE-U03 INST Rev B OMRON uses recycled paper to help preserve our natural resources.
