MICRO INDOOR/OUTDOOR COLOR BULLET CAMERA
LOREx NEW DIY "MICRO" COLOR CAMERA
or Business use, operates Indoors or Outdoors with high resolution
(420 TV lines) picture quality. The small form factor of this Micro
Color Camera is ideal for "Covert Applications" and easily connects
to any TV/ VCR or DVR.
FE ATU RES
ß
Small enough to be used for certain covert applications
ß
Advanced micro image sensor for superior image quality
ß
Excellent low light sensitivity (Min 0.5 Lux)
ß
420 Lines of Resolution
ß
Weatherproof Housing Ideal for Indoor and Outdoor
Applications (IP66)
SpECIFIC AT I ONS
Image Sensor:
1/4" Advanced Micro Image Sensor
Video Format
NTSC
Effective Pixels:
H: 656, V: 492
Resolution:
420 TV Lines
Scan System:
2:1 Interlace
Sync System:
Internal
S/N Ratio:
48dB
Iris:
AES
AES Shutter Speed:
1/60~1/50,000 Sec
Mini Illumination:
0.5 Lux
Video Output:
Composite 1.0Vpp @ 75 ohm
Lens/ Lens Mount:
3.6mm F 2.0/ Fixed
FOV (Diagonal):
42 degrees
IR LED/ Night Vision Range:
N/A
Power Requirement:
12V DC
Power Consumption:
50mA (Typical) @ 12Vdc
Operating Temp Range:
-10°~50° C / 14° - 122° F
Dimension:
DIA: 10mm, Length: 53mm (Excl. Stand)
Unit Weight:
121gr (Incl. Stand)
Environmental Rating:
IP 66
SG4934W Series
Lorex Technology Inc.
300 Alden Road, Markham,
3700 Koppers Street
Ontario L3R 4C1 Canada.
Baltimore, Maryland 21227, USA.
P L U G A N D P L A Y S E C U R I T Y
for Home
WITH ADVANCED IMAGE SENSOR
DIM E NSIO N S
2.0"in / 53mm
pACk AG E I NFO RMATIO N
UPC:
SG4934W: 7-78597-04934-3
SG4934WF: 7-78597-24934-7
Weight:
1.0kgs / 2.2 lbs
Dimensions:
(W x H x D) 8.9" x 10.6" x 3. 1 "
227mm x 270mm x 79mm
Cube:
0.005 cbm
Contents:
Camera, Mounting Bracket, 12V DC Power Supply,
RCA/BNC Connector, 60 Ft. Extension Cable, Quick
Start Guide, Warranty Card
w w w . l o r e x c c t v . c o m
As our product is subject to continuous improvement, Lorex Technology & subsidiaries reserve the right to
modify product design, specifications & prices without notice and without incurring any obligation. E&OE
0.6"in / 15 mm
©2008 Lorex Technology Inc.
1-07282008
