Page 1: Instruction Manual
PORTABLE HOME SECURITY VIDEO CAMERA Instruction Manual English Version1.0 MODEL: SG6227 www.lorexcctv.com Copyright © 2007 Lorex Technology Inc. - Page 2 CAUTION RISK OF ELECTRIC SHOCK. DO NOT OPEN CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE. REFER SERVICING TO QUALIFIED SERVICE PERSONNEL. Explanation of two Symbols The lightning flash with arrowhead symbol, within an equilateral triangle, is intended to alert the user to the presence of uninsulated "dangerous voltage“...
-
Page 3: Safety Instructions
SAFETY INSTRUCTIONS IMPORTANT SAFEGUARDS All the safety and operating instructions should be read before the appliance is operated and retained for future reference. 1. HEED WARNINGS - All warnings on the appliance and in the operating instructions should be adhered to. 2. -
Page 4: Table Of Contents
TABLE OF CONTENTS PAGE INTRODUCTION & FEATURES……………………………………… SYSTEM INCLUDES………………………………………………….. CONTROLS AND FUNCTIONS Camera Controls …………………………………………………..….. INSTALLATION Camera ............……………….…..SYSTEM OPERATION Additional camera connection……………………………………. Alarm Alert ………………………………………………………… Auto & Manual Viewing Options…………………………………. Auto Scanning……………………………………………………… Selectable Dwell Settings………………………………………… OPTIONAL ACCESSORIES ............TROUBLE SHOOTING ..........………..…... TECHNICAL SPECIFICATIONS ............ -
Page 5: Introduction & Features
• Up to 300 feet wireless transmission • Listen-in audio • Auto scanning – up to four cameras • Camera has AC or battery option • Compatible with all Lorex 2.4 GHz wireless devices • Connect up to four cameras (additional cameras sold separately) -
Page 6: System Includes
SYSTEM INCLUDES: 2.4 GHz Color Wireless Camera Owner’s Manual with 8 Infra-red emitters Also includes: 1 - 6V DC 300mA Adapter (Camera) with battery option (4 “AA”, not included) 1 - Mounting hardware for Camera... -
Page 7: Camera Controls
CAMERA CONTROLS 1. CDS Sensor - Turns on the IR emitters in low light conditions. 2. Infrared LED’s - Enhance the picture quality in low light conditions. 3. Lens - Color CMOS Image Sensor. 4. Microphone - Built-in condenser microphone provides listen-in audio capability from camera to monitor. -
Page 8: Camera Installation
CAMERA INSTALLATION NOTE Ensure the power switch on the monitor and camera are set to the OFF position before proceeding with the following steps. OPTION #1 OPTION #2 WALL DESK Option 1: You can place the camera on a desk or any leveled surface. Select a location that is near an AC outlet and within reach of the AC adapter cord. -
Page 9: Additional Camera Connection
OPERATION Camera (1) Connect the power adapter to the camera power input and turn on the camera by pressing the Power. Ensure the camera is set to channel 2,3 or 4. NOTE Try to position both the Camera and Monitor as high off the ground as possible for better picture reception. -
Page 10: Alarm Alert
ALARM ALERT This video security system is equipped with an Audio-based Alarm system, which alerts you of sound at the camera. To activate the Alarm feature, hold the Alarm button on the monitor for 2 seconds. A red light will illuminate to indicate that Alarm mode is active, and the monitor will go to Standby mode (video will not appear on the LCD screen, and the speaker sound will cease). -
Page 11: Auto Scanning
AUTO SCANNING This video security system provides you with the option to automatically switch between the four camera locations. If you have fewer than four cameras, you can also set the system to scan between three or two locations. Setting Auto Scan to 2 or 3 camera locations: 1. -
Page 12: Optional Accessories
OPTIONAL ACCESSORIES The following optional accessories are available to add to your existing system: SG6227 Accessory Camera - Used to view additional locations Time Lapse VCR - Used to record key events. Available in 40 or 1280 Hour Time Lapse VCR... -
Page 13: Troubleshooting
3.2” (W) x 1.7” (D) x 4.8” (H) Housings White ABS Because our products are subject to continuous improvement, LOREX and its subsidiaries reserve the right to modify product design and specifications without notice and without incurring any obligation. E&OE... -
Page 14: Care & Maintenance
CARE AND MAINTENANCE: Please follow these instructions to ensure proper care and maintenance of this system. Keep your monitor and camera dry. If it gets wet, wipe it dry immediately. Use and store your unit in normal temperature environment. Extreme temperatures can shorten the life of the electronic devices. - Page 15 It’s all on the web Product Information Specification Sheets User Manuals Software Upgrades Quick Start Guides Firmware Upgrades VISIT www.lorexcctv.com wwwlorexcctv.com Lorex Technology Inc.
