Roland FP-7F Brochure & Specs

Pro performance in a travel-friendly instrument
Play piano in any environment
Authentic piano sounds, natural keyboard touch, and functions to expand
your range of musical enjoyment are all packed into this compact keyboard.
Take this instrument anywhere, and enjoy your music in any environment,
from lessons to live performances.
FP-4F-BK with optional KS-18Z
FP-7F/FP-4F Specifications
Keyboard
Keyboard 88 keys [FP-7F] Ivory Feel-S Keyboard with Escapement [FP-4F] Ivory Feel-G Keyboard with Escapement
Touch Sensitivity [FP-7F] 100 levels/Fixed Touch, Hammer Response (Off, 1 – 10) [FP-4F] 5 levels, Fixed Touch
Keyboard Mode Whole, Dual (volume balance adjustable), Split (split point adjustable)
Sound Generator (Conforms to GM2 / GS / XGlite)
Piano Sound SuperNATURAL Piano Sound
Damper Resonance (Off, 1 – 10), String Resonance (Off, 1 – 10), Key Off Resonance (Off, 1 – 10)
Piano Effects [FP-7F only] Open/Close Lid (0 – 6), Cabinet Resonance (Off, 1 – 10), Hammer Noise (-2 – 2),
Duplex Scale (Off, 1 – 10), Damper Noise (Off, 1 – 10)
Max. Polyphony 128 voices
Tone [FP-7F] 351 tones (including 8 drum sets, 1 SFX set) [FP-4F] 345 tones (including 8 drum sets, 1 SFX set)
Temperaments 8 types, selectable temperament key
Stretched Tuning Off, Preset [FP-7F o nl y] User tuning (adjustable in individual notes: -50.0 – +50.0 cent)
Master Tuning 415.3 Hz – 466.2 Hz (adjustable in increments of 0.1 Hz)
Transpose
-6 – +5 (in semitones)
Reverb (Off, 1 – 10), Only for Organ Tones: Rotary Speaker Effect (Slow, Fast)
Effects
[FP-7F o n ly] Only for MIC INPUT: Harmony (Off, 3 types), Reverb (Off, 1 – 10)
Equalizer 4-band Digital Equalizer
Metronome
Tempo Quarter Note = 10 – 500
Beat 2/2, 0/4, 2/4, 3/4, 4/4, 5/4, 6/4, 7/4, 3/8, 6/8, 9/8, 12/8
Recorder
Song 1 Song
Note Storage Approx. 30,000 notes
Tempo
Quarter Note = 10 – 500
Resolution 120 ticks per quarter note
Playable Song Format Standard MIDI Files (Format 0/1), Roland Original Format (i-Format)
Transpose -6 – +5 (in semitones)
Session Partner
Rhythms 80 types x 2 variations
Chord Progression Automatic or input with keyboard (User Programmable)
Audio
Playable Song Format Audio File (WAV 44.1 kHz / 16-bit Linear Format), Audio CDs (CD-DA) (when using an optional CD drive)
Audio Playback Center Cancel, Audio Playback Speed (75 – 125 %), Playback Transpose (-6 – +5, in semitones)
Internal Memory
Songs Max. 99 songs
Song Save Format Standard MIDI Files (Format 0)
FP-7F/FP-4F Options
Dedicated Stand
KSC-44-BK / KSC-44-WH
FP-7F shown with the optional stands (KSC-44-BK / KSC-44-WH / KS-18Z)
FP-4F-BK with optional KSC-44-BK
Committed to producing products that are inviting to use and easy on the environment
Roland's Miyakoda Factory in Hamamatsu, Japan, is a state-of-the-art facility that has acquired internationally recognized ISO14001 certification
for its environmental management systems and ISO9001* for quality assurance. Recycled plastic is used for Ivory Feel keyboards and keyboard
parts with no lead materials used in the pianos. Using Roland's original digital-cell production method, each instrument is individually made by
hand and carefully assembled with low-environmental impact.
*ISO14001 is an international standard for environmental management systems issued by the International Organization for Standardization (ISO). Similarly, ISO9001 is an
international ISO standard for quality management systems. The International Organization for Standardization is a non-government organization that issues internationally
recognized industrial standards, quality control standards, and other standards.
FP-4F-WH with optional KSC-44-WH and RPU-3
External Memory
External Storage USB Flash Memory (sold separately)
Songs [FP-7F] Max. 999 songs [FP-4F] Max. 99 songs
Song Save Format Standard MIDI Files (Format 0)
Other
Internal Songs [FP-7F] 74 songs [FP-4F] 73 songs
Display [FP-7F] Graphic LCD 128 x 64 dots (with backlit) [FP-4F] Custom LCD (with backlit)
[FP-7F] To Internatl Memory: 30 x 25 sets (max.), To External Memory: 30 x 99 sets (max.)
Registrations
[FP-4F] To Internatl Memory: 20 x 25 sets (max.), To External Memory: 20 x 99 sets (max.)
Other Functions V-LINK, Tone Demo, Panel Lock [FP-7F only ] Looper, Audio Key, Piano Designer
External Memory connector, USB (MIDI) connector, PEDAL jacks (DAMPER/R, SOFT/L (FC1)*,
SOSTENUTO/C (FC2)*): 1/4-inch phone type (*Assignable),
OUTPUT jacks (L/MONO, R): 1/4-inch phone type ,
Connectors
INPUT jacks (L/MONO, R): 1/4-inch phone type (FP-7F) / RCA phono type (FP-4F),
PHONES jack x 2: Stereo 1/4-inch phone type, MIDI connectors (IN, OUT), DC IN jack,
[FP-7F] MIX IN jack: Stereo miniature phone type, MIC INPUT jack: 1/4-inch phone type
Rated Power Output [FP-7F] 13W x 2 [FP-4F] 12W x 2
Speakers [FP-7F] (8cm x 12 cm) x 2 (with speaker box) [FP-4F] (8cm x 12 cm) x 2
[FP-7F] 100 dB [FP-4F] 98 dB
Volume Level (SPL)
* These figures were measured according to the method that is based on Roland's technical standard.
Control VOLUME, BALANCE, LCD CONTRAST [FP-7F only] MIC VOLUME, SPEAKER switch
Power Supply DC 12 V (AC Adaptor)
Power Consumption
[FP-7F] 26 W [FP-4F] 24 W
Finish Black, White
[FP-7F] 1,346 (W) x 375 (D) x 137 (H) mm / 53 x 14-13/16 x 5-7/16 inches
1,346 (W) x 397 (D) x 949 (H) mm / 53 x 15-11/16 x 37-3/8 inches (FP-7F with
dedicated stand KSC-44 and music rest)
Dimensions
[FP-4F] 1,342 (W) x 305 (D) x 135 (H) mm / 52-7/8 x 12-1/16 x 5-3/8 inches
1,342 (W) x 341 (D) x 940 (H) mm / 52-7/8 x 13-7/16 x 37-1/16 inches (FP-4F with
dedicated stand KSC-44 and music rest)
[FP-7F] 24.0 kg / 52 lbs 15 oz
36.6 kg / 80 lbs 12 oz (FP-7F with dedicated stand KSC-44 and music rest)
Weight
[FP-4F] 16.6 kg / 36 lbs 10 oz
29.1 kg / 64 lbs 3 oz (FP-4F with dedicated stand KSC-44 and music rest)
Owner's Manual, AC Adaptor, Power Cord (for AC Adaptor), Music Rest,
Accessories
Damper Pedal (capable of continuous detection)
Keyboard Stand Pedal Unit Damper Pedal Expression Pedal Dynamic Microphone USB Flash Memory
KS-18Z RPU-3 DP-10 EV-5 DR-50 M-UF2G
(for FP-7F)
For additional pedals. FP-7F/FP-4F
package includes one DP-10.
Visit us online at www.Roland.com Roland, , SuperNATURAL and V-Piano are either registered trademarks or
trademarks of Roland Corporation in the United States and/or other countries.
All specifications and appearances are subject to change without notice.
All trademarks used in this catalog are the property of their respective companies.
Printed in Japan Feb. 2011 RAM-4682 GR-UPR-SS AIDG1
USB CD Drive
CD-01A
