- Page 1 ISSUED: OCT. 11, 2005 REVISED: JAN. 1, 2007 HOSHIZAKI REFRIGERATED GLASS MERCHANDISER KD-90D MODEL INSTRUCTION MANUAL...
-
Page 2: Table Of Contents
1. This booklet is an integral and essential part of the product and should be handed over to the user. Read the warnings contained in this booklet carefully as they give important indications regarding the safety of the installation, use and maintenance. -
Page 3: General Information
I. GENERAL INFORMATION 1. CONSTRUCTION Fastener Left Side Glass Sheet Bracket Drain Hose Ground Fault Circuit Interrupter (GFCI) Angle Front Glass Fluorescent Lamp Drip Pan Thermometer Fluorescent Lamp Switch Thermostat Sliding Door Power Cord 3-Prong Plug Glass Shelf Right Side Glass Evaporator Air Filter Rear Cover... -
Page 4: For Safety And Best Operating Results
2. FOR SAFETY AND BEST OPERATING RESULTS Hoshizaki refrigerated glass merchandiser is not designed as a refrigerator. Use this merchandiser only as a display case. The following are recommendations for proper use. * Select a proper installation site (see “II. INSTALLATION AND OPERATING INSTRUCTIONS”). -
Page 5: Installation And Operating Instructions
II. INSTALLATION AND OPERATING INSTRUCTIONS 1. UNPACKING This merchandiser contains fragile glass parts. Handle with care. Visually inspect the exterior of the shipping container and the merchandiser. Any severe damage noted should be reported to the carrier. * Unpack the merchandiser carefully. * Carry the merchandiser by holding its bottom. -
Page 6: Electrical Connections
* Allow at least 6” (15 cm) clearance around the merchandiser for proper air circulation and ease of maintenance and/or service should they be required. 2) Level the merchandiser in both the left-to-right and front-to-rear directions. Metal shims should be added under the feet to level the system. 3. -
Page 7: Final Check List
5. FINAL CHECK LIST 1) Is the merchandiser level? 2) Is the merchandiser in a site where the ambient temperature is within 50°F (10°C) to 86°F (30°C) all year around? 3) Is there at least 6” (15 cm) clearance around the merchandiser? 4) Have all shipping carton, tape(s) and packing been removed from the merchandiser? 5) Have all electrical connections been made? 6) Has the Drain Tank been installed on the bottom of the merchandiser? -
Page 8: Shut Down
This refrigerated merchandiser is not designed to store foods for a long period as a normal refrigerator. Always shut off the merchandiser after service hours, by turning off the GFCI. Remove all stored items from the merchandiser, and move them into a refrigerator. -
Page 9: Maintenance And Cleaning Instructions
III. MAINTENANCE AND CLEANING INSTRUCTIONS 1. This refrigerated merchandiser must be maintained individually, referring to the Instruction Manual. 2. Before carrying out any cleaning or maintenance operations, unplug the merchandiser. 3. This merchandiser is made of fragile glass. Handle with care. To prevent injury to individuals and damage to the equipment, do not use ammonia type cleaners. - Page 10 the location. Use warm water and a neutral cleaner especially to remove oily dirt. Rinse and dry the Air Filter thoroughly, and place it in position.
- Page 12 HOSHIZAKI AMERICA, INC. 618 HIGHWAY 74 SOUTH PEACHTREE CITY, GA 30269 U.S.A. PHONE: 770-487-2331 www.hoshizakiamerica.com HOSHIZAKI ELECTRIC CO., LTD. 3-16 MINAMIYAKATA, SAKAE, TOYOAKE, AICHI 470-1194 JAPAN PHONE: 0562-97-2111 9174GE10B...
