Behringer EUROPOWER PMP530M Brochure & Specs

Powered Mixers
EUROPOWER
PMP530M
Ultra-Compact 300-Watt 5-Channel
Powered Mixer with Multi-FX
Processor and FBQ Feedback
Detection System
Compact and rack-mountable
300-Watt powered mixer with
Multi-FX processor
Revolutionary Class-D amplifier
technology: enormous power,
incredible sonic performance and
super-light weight
Ultra-compact design at nearly
half the depth and weight of
conventional powered mixers
means no more lugging around
dead weight
Ultra-low noise ULN design for
highest possible headroom and
ultra-transparent audio
5-channel mixer section
features 5 mic/line channels,
plus separate CD/Tape input/output
Integrated 24-bit digital FX processor
with 100 awesome presets including
reverb, chorus, flanger, delay, pitch
shifter and various multi-effects
Revolutionary FBQ Feedback
Detection system instantly reveals
critical frequencies for easy
feedback removal
5 high-quality mic preamps with
switchable Pad and Clip LEDs
Effective, extremely musical 2-band
EQ on all channels
7-band graphic EQ allows precise
frequency correction
3 speaker outputs on 1/4" jack and
professional speaker connectors
If you need superior sound quality for
small club gigs, churches or speeches,
but want to keep the outboard gear to a
minimum—then look no further than the
EUROPOWER PMP530M. This 300-Watt
5-channel powered mixer weighs just
9.5 lbs (4.3 kg) and provides everything
you need in one efficient, highly portable
package. The PMP530M is ideally
suited for vocal groups, small bands,
churches, town halls, banquet rooms
and much more.
Big Power
Most powered mixers in this class
tease you with maybe 100 or 200-Watts of
peak output power. Not the PMP530M—
this bad boy comes armed to the teeth
with 300-Watts of the cleanest power.
Class-D amplifier and Switch Mode Power
Supply technology make it possible by
reducing the need for heavy transformers
and massive heat sinks. The PMP530M's
state-of-the-art design architecture keeps
it cool as a cucumber for hours and hours
of continuous operation.
So Easy to Operate
One of the PMP530M's most
impressive features is its ease of use.
Simply connect your passive loudspeakers
to the rear panel jacks, plug the power
cord into the wall and turn the unit on.
Oops, be sure the Main volume control
is set to zero first. Connect a microphone
to the channel 1 XLR socket and speak or
sing while adjusting the Channel 1 Level
control until the Clip LED barely flickers.
If it stays lit for more than a quick flash,
you'll need to turn it down a little. Turn up
the Main volume control and you should
be able to hear yourself through the
speakers. Follow the same procedure for
the other channels and you are done.
See, we told you it was easy!
Continued on next page
