1. Assembling cleaner

It is extremely important to
read and follow all the
instruction steps in order.
The assembled cleaner will look like this drawing.
If you need assistance with any step of the assembly or operation:
Visit us on-line at www.hoover.com to find the service
outlet nearest you (click on the "Service" button) OR call
1-800-944-9200 for an automated referral of authorized
service outlet locations (U.S. only) OR call
1-330-499-9499 to speak with a representative in our
Consumer Response Center.

Carton contents

Remove all parts from carton and
identify each item shown.
Note that some of the items are
shipped together in the sealed
bag with the owner's manual.
1-1
A
E
A. Upper handle
B. Bag compartment assembly
C. Cord
D. Hose and tool holder
E. Cleaner base
B
C
G
F
I
F. Handle bolt and nut and hose
holder screw packet (One extra
nut included)
G. Upper handle screws (2)
H. Paper filter bag
I. Hose, cleaning tools, crevice
wand (stores inside extension
wand) and extension wand
D
H
