Sony SAVA-D900 Service Manual

Dvd home theater active speaker system
Hide thumbs Also See for SAVA-D900:
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
Ver 1.1 2002. 01
This set is composed of the following table.
Front Speaker
Center/Rear Speaker
Woofer Speaker
Main Unit
Sony Corporation
9-929-278-12
2002A1600-1
Home Audio Company
© 2002.1
Published by Sony Engineering Corporation
(Photo : SAVA-D900)
(Photo : SS-T900)
SAVA-D900FR
SS-T900
SAVA-D900R
SAVA-D900
SPECIFICATIONS
SAVA-D900/D900FR/
D900R/SS-T900
(Photo : SAVA-D900FR)
(Photo : SAVA-D900R)
Model Name Using Similar Mechanism NEW
Mechanism Type
Base Unit Type
Optical Pick-up Type

ACTIVE SPEAKER SYSTEM

US Model
CDM53J-DVBU1
DVBU1
KHM-220AAA
— Continued on next page —
DVD HOME THEATER

Advertisement

Table of Contents
loading

Related Manuals for Sony SAVA-D900

Summary of Contents for Sony SAVA-D900

  • Page 1: Active Speaker System

    Base Unit Type DVBU1 Woofer Speaker SAVA-D900R Optical Pick-up Type KHM-220AAA Main Unit SAVA-D900 SPECIFICATIONS — Continued on next page — DVD HOME THEATER ACTIVE SPEAKER SYSTEM Sony Corporation 9-929-278-12 2002A1600-1 Home Audio Company © 2002.1 Published by Sony Engineering Corporation...
  • Page 2 THE PARTS LIST ARE CRITICAL TO SAFE OPERATION. REPLACE THESE COMPONENTS WITH SONY PARTS Earth Ground WHOSE PART NUMBERS APPEAR AS SHOWN IN THIS MANUAL OR IN SUPPLEMENTS PUBLISHED BY SONY. Fig. A. Using an AC voltmeter to check AC leakage.

  • Page 3: Table Of Contents

    1. GENERAL 6. EXPLODED VIEWS ................. 4 6-1. Overall Section ............72 6-2. Main Unit (SAVA-D900) Section ........ 73 2. DISASSEMBLY 6-3. Main Chassis Section ..........74 2-1. Grille Frame (B) Assy ........... 6 6-4. Amplifier Chassis Section ........... 75 2-2.

  • Page 4: General

    SECTION 1 GENERAL This section is extracted from instruction manual.

  • Page 6: Disassembly

    SECTION 2 DISASSEMBLY Note: Follow the disassembly procedure in the numerical order given. SAVA-D900 (MAIN UNIT) 2-1. GRILLE FRAME (B) ASSY 2 Grille frame (B) assy Main unit (L-ch) section Note : Be careful not to open 1 excessively as shown.

  • Page 7: Amplifier Chassis

    2-3. AMPLIFIER CHASSIS 0 Heatsink and AMP board 7 Two screws 4 Connecters (transistor) 3 Cord bushing 8 Twelve screws (BVTP3 5 Connecters 9 Back panel (L/A) 1 Connecter 2 Connecter 6 Screw (BVTP3 2-4. AMP BOARD 9 THERMO board 8 Bracket 7 Screw 0 Heatsink...

  • Page 8: Power Transformer (T900)

    2-5. POWER TRANSFORMER (T900) 3 Four screws (BVTT4 1 Connector 4 Power transformer (T900) 2 Connectors 2-6. PS BOARD 2 Six screws (BVTP3 5 STBY board 4 Four screws (BVTP3 3 PS board 1 Connector...

  • Page 9: Mechanism Section

    2-7. MECHANISM SECTION 4 Six screws (BVTT4 7 Mechanism section 6 Flat wire 1 3 screws (BVTP3 2 2 screws (BVTP3 5 Four connectors 3 2 screws (BVTT4 Main unit (L-ch) section qs Panel (L/C) back 2 Four screws 2-8. VIDEO BOARD (BVTP3 6 TUNER unit 3 Nine screws...

  • Page 10: Main Board And Dvd Board

    2-9. MAIN BOARD AND DVD BOARD qs Four screws (BVTP3 qf DVD assy qd DVD board qa Flat wire 0 Connector 9 Flat wire 8 Bracket 4 Flat wire 7 Four screws (BVTP3 6 MAIN board 3 Flat wire 5 Four screws (BVTP3 2 Flat wire 1 Flat wire...

  • Page 11: Base Unit (Dvbu1)

    2-11. BASE UNIT (DVBU1) 2 Base unit (DVBU1) 1 Two screws (PTPWH M2.6) 2-12. MAGNET ASSY 8 Four screws (BVTP M2.6) 6 Bracket (chassis) 2 Four screws (BVTP M2.6) 4 Screw (BVTP M2.6) 7 Connector (CN710) 9 Magnet assy 5 Screw (BVTP M2.6) 3 Fitting base (guide) assy...

  • Page 12: Tray (Sub)

    2-13. TRAY (SUB) 1 Turn the pulley (LD) and move the slider (selection) in the direction of the arrow L. 2 Turn the pulley (mode) in the direction of the arrow to adjust the tray (sub) that you want to remove. (It depends on the height and position of the stocker.) 3 Turn the pulley (LD) and move the slider...

  • Page 13: How To Assemble The Gears

    2-15. HOW TO ASSEMBLE THE GEARS 3 Gear (gear B) Portion A Adjust the gear (gear B) with the portion A as shown. 1 Slide the slider (u/d) fully in the arrow direction. 4 Gear (gear A) 2 Gear (U/D slider) Gear Slider (U/D) gear Linearly...

  • Page 14: How To Attach The Stocker

    2-17. HOW TO ATTACH THE STOCKER 2 Portion A of tray (sub) Hook the portion A of tray (sub) 1 Stocker section to the slider (selection). Portion A Sticking of of tray (sub) slider (selection) 3 Two step screws 4 Two step screws 2-18.

  • Page 15: Test Mode

    DISC 2 — All cliar of STR side SWMODE STOP DISC 3 — Key Check SWMODE STOP EJECT 3 SAVA-D900’s key Display Check SWMODE BAND EJECT 5 STOP Speaker Check SWMODE STOP EJECT 4 STOP * The speaker check mode is the test mode in which the sound signel that is input to the TV INPUT is output from all speakers at the unity sound level.
  • Page 16 3-1. GENERAL DESCRIPTION ### Syscon Diagnosis ### The Test Mode allows you to make diagnosis and adjustment easily Diag All Check using the remote commander and monitor TV. The instructions, No. 2 Version diagnostic results, etc. are given on the on-screen display (OSD). 2-3.
  • Page 17 2-digit hexadecimal number. 5. Supply Model Type Caution: Do not conduct this check with a mechanical deck SAVA-D900 connected. An access is made to the stream supply and servo control (2-5) Region IC (IC303) and external RAM (IC304) using check data.
  • Page 18 6. AV Decoder (5-4) ARP to RAM Address Bus Data write other address read discord check Error 10: ARP RAM address bus error (6-2) 1930 RAM Caution: Address and data display in case of an error is Data write read, and accord check different from the display of other diagnosis (de- Error 13: AVD RAM read data discord scribed later).
  • Page 19 Check Items List Error Codes List 00: Error not detected 2) Version 01: RAM write/read data discord (2-2) Revision 02: Gate array NG (2-3) ROM Check Sum 03: EEPROM NG (2-4) Model Type 08: ARP register read data discord (2-5) Region 09: ARP RAM data bus error 10: ARP...
  • Page 20 3-4. DRIVE AUTO ADJUSTMENT 1. DVD-SL (single layer) [ENTER] Select , insert DVD single layer disc, and press key, On the Test Mode Menu screen, press key on the remote and the adjustment will be made through the following steps, then commander, and the drive auto adjustment menu will be displayed.
  • Page 21 2. CD 3. DVD-DL (dual layer) [ENTER] [ENTER] Select , insert CD disc, and press key, and the Select , insert DVD dual layer disc, and press key, and adjustment will be made through the following steps, then adjusted the adjustment will be made through the following steps, then values will be written to the EEPROM.
  • Page 22 4. SACD 3-5. DRIVE MANUAL OPERATION [ENTER] Select , insert SACD disc, and press key, and the On the Test Mode Menu screen, select , and the manual operation adjustment will be made through the following steps, then adjusted menu will be displayed. For the manual operation, each servo on/ values will be written to the EEPROM.
  • Page 23 0. Disc Check Memory Disc Type 1. Disc Type Auto Check Disc Check 2. DVD SL 12 cm 3. DVD DL 12 cm 4. CD 12cm 5. SACD 12 cm 1. SL Disc Check 6. dvd SL 8 cm 2. CD Disc Check 7.
  • Page 24 Reset SLED TILT Reset the Sled and Tilt to initial position. 3-6. MECHA AGING Turn ON/OFF the laser. ### Mecha Aging ### Turn ON/OFF the spindle. Focus Search the focus and turn on the focus. 1. TRAY Aging Turn ON/OFF the tracking servo. 2.
  • Page 25 3-8. VERSION INFORMATION How to see Emergency History ## Version Information ## IF con. Ver. x. xxx (xxxx) Group SYScon. Ver. x. xxx (xxxx) Model Region 1 : Emergency Code 2 : Don’t Care These codes are used for verification of software designing. Exit: RETURN 3 : Historical order 1 to 9 Emergency Codes List...

  • Page 26: Electrical Adjustment

    SECTION 4 ELECTRICAL ADJUSTMENTS 4-1. ADJUSTMENT OF VIDEO SYSTEM In making adjustment, refer to 4-2. Adjustment Related Parts Arrangement. 1. Video Level Adjustment (DVD BOARD) <Purpose> Note: During diagnostic check, the characters and color bars can This adjustment is made to satisfy the NTSC standard, and if not be seen only with the NTSC monitor.

  • Page 27: Adjustment Related Parts Arrangement

    3. Checking S Video Output S-C (DVD BOARD) 4-2. ADJUSTMENT RELATED PARTS <Purpose> ARRANGEMENT This checks whether the S-C satisfies the NTSC Standard. If it is DVD BOARD (SIDE A) not correct, the colors will be too dark or light. CN005 Mode Video level adjustment in test mode...

  • Page 28: Diagrams

    SECTION 5 DIAGRAMS 5-1. CIRCUIT BOARDS LOCATION SAVA-D900 (MAIN UNIT) DISP board DVD board FFC board MAIN board PS board VIDEO board THERMO board S-VIDEO board AMP board V-CONNECT board REG board STBY board • Mechanism section (CDM53J-DVBU1) CLAMP MOTOR board...
  • Page 29 SAVA-D900/D900FR/D900R/SS-T900 WAVEFORMS THIS NOTE IS COMMON FOR PRINTED WIRING – DVD (1/12) SECTION – – DVD (4/12) SECTION – – TK SECTION – BOARDS AND SCHEMATIC DIAGRAMS. (In addition to this, the necessary note is printed in each block.) 3.4Vp-p 1.0Vp-p...

  • Page 30: Block Diagrams

    SAVA-D900/D900FR/D900R/SS-T900 5-2. BLOCK DIAGRAMS – DVD SECTION – J1102 IC1101 VIDEO SW VIDEO IC1104 INPUT IC303 IC401 J1103 AV DECODER MONITOR OUT OPTICAL DEVICE IC001 DVD/CD RF AMP HAD0 DIGITAL SERVO HA0-7 HD8-15 HAD21 DVD/CD J1105 PDIC HD8-15 MONITOR OUT...

  • Page 31: Main Section

    SAVA-D900/D900FR/D900R/SS-T900 – MAIN SECTION – IC1105 IC906 IC1205 IC1701 INPUT SELECT A/D CONV J1101 POWER AMP IC1106 IC502 IC504 VOL CONT IC1202 IC1207 IC1301 LIN- LOUT3 L-CH (L-ch SPEAKER) LINA LOUTA IC201 IC502 TONE CONT LIN+ MUTE IC1702 Q1301 POWER AMP...

  • Page 32: Printed Wiring Board - Dvd Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 28 for Circuit Boards Location. 5-3. Printed Wiring Board – DVD Section – There are few cases that the part printed on this (Page 49) (Page 53) (Page 49) diagram isn’t mounted in this model. MAIN...
  • Page 33 SAVA-D900/D900FR/D900R/SS-T900 There are few cases that the part printed on this diagram isn’t mounted in this model. • Semiconductor Location Ref. No. Location D701 D806 D902 D903 D905 D906 D907 D908 D909 D910 IC002 IC005 IC201 IC203 IC207 IC304 IC402...

  • Page 34: Schematic Diagram - Dvd (1/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 29 for Waveforms. • See page 67 for IC Block Diagrams. 5-4. Schematic Diagram – DVD (1/12) Section –...

  • Page 35: Schematic Diagram - Dvd (2/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-5. Schematic Diagram – DVD (2/12) Section – • See page 29 for Waveforms. • See page 69 for IC Block Diagrams.

  • Page 36: Schematic Diagram - Dvd (3/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-6. Schematic Diagram – DVD (3/12) Section –...

  • Page 37: Schematic Diagram - Dvd (4/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-7. Schematic Diagram – DVD (4/12) Section – • See page 29 for Waveforms. • See page 68 for IC Block Diagrams. R607...

  • Page 38: Schematic Diagram - Dvd (5/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 29 for Waveforms. • See page 68 for IC Block Diagrams. 5-8. Schematic Diagram – DVD (5/12) Section –...

  • Page 39: Schematic Diagram - Dvd (6/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-9. Schematic Diagram – DVD (6/12) Section – • See page 69 for IC Block Diagrams. (Page 40) (Page 40)

  • Page 40: Schematic Diagram - Dvd (7/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-10. Schematic Diagram – DVD (7/12) Section – (Page 39) (Page 39)

  • Page 41: Schematic Diagram - Dvd (8/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-11. Schematic Diagram – DVD (8/12) Section – • See page 29 for Waveforms. • See page 67 for IC Block Diagrams. • See page 63 for IC Pin Functions. PIN FUNCTION (Page 42)

  • Page 42: Schematic Diagram - Dvd (9/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 68 for IC Block Diagrams. 5-12. Schematic Diagram – DVD (9/12) Section – (Page 41)

  • Page 43: Schematic Diagram - Dvd (10/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-13. Schematic Diagram – DVD (10/12) Section – • See page 29 for Waveforms. • See page 65 for IC Pin Functions. PIN FUNCTION...

  • Page 44: Schematic Diagram - Dvd (11/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 68 for IC Block Diagrams. 5-14. Schematic Diagram – DVD (11/12) Section –...

  • Page 45: Schematic Diagram - Dvd (12/12) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-15. Schematic Diagram – DVD (12/12) Section – (Page 44) (Page 44) (Page 44) (Page 44) (Page 43)

  • Page 46: Printed Wiring Board - Tk Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 28 for Circuit Boards Location. 5-16. Printed Wiring Board – TK Section – There are few cases that the part printed on this diagram isn’t mounted in this model. (Page 32) (Page 32)

  • Page 47: Schematic Diagram - Tk Section

    SAVA-D900/D900FR/D900R/SS-T900 5-17. Schematic Diagram – TK Section – • See page 29 for Waveforms. (Page 34) (Page 34)

  • Page 48: Schematic Diagram - Main Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 29 for Waveforms. • See page 71 for IC Block Diagrams. 5-18. Schematic Diagram – MAIN Section –...

  • Page 49: Printed Wiring Board - Main Section

    SAVA-D900/D900FR/D900R/SS-T900 5-19. Printed Wiring Board – MAIN Section – • See page 28 for Circuit Boards Location. There are few cases that the part printed on this diagram isn’t mounted in this model. • Semiconductor Location (Page 53) Ref. No. Location...

  • Page 50: Schematic Diagram - Amp Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 70 for IC Block Diagrams. 5-20. Schematic Diagram – AMP Section – (Page 60) (Page 61) (Page 60) (Page 48)

  • Page 51: Printed Wiring Board - Amp Section

    SAVA-D900/D900FR/D900R/SS-T900 5-21. Printed Wiring Board – AMP Section – • See page 28 for Circuit Boards Location. There are few cases that the part printed on this diagram isn’t mounted in this model. • Semiconductor Location Ref. No. Location D1701...

  • Page 52: Schematic Diagram - Video Section

    SAVA-D900/D900FR/D900R/SS-T900 5-22. Schematic Diagram – VIDEO Section – (Page 48) (Page 34)

  • Page 53: Printed Wiring Board - Video Section

    SAVA-D900/D900FR/D900R/SS-T900 5-23. Printed Wiring Board – VIDEO Section – • See page 28 for Circuit Boards Location. There are few cases that the part printed on this diagram isn’t mounted in this model. (Page 32) (Page 49)

  • Page 54: Schematic Diagram - Display Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 70 for IC Block Diagrams. 5-24. Schematic Diagram – DISPLAY Section –...

  • Page 55: Printed Wiring Board - Display Section

    SAVA-D900/D900FR/D900R/SS-T900 5-25. Printed Wiring Board – DISPLAY Section – • See page 28 for Circuit Boards Location. There are few cases that the part printed on this diagram isn’t mounted in this model. (Page 49) • Semiconductor Location Ref. No. Location...

  • Page 56: Schematic Diagram - Motor Section

    SAVA-D900/D900FR/D900R/SS-T900 5-26. Schematic Diagram – MOTOR Section – (Page 34) (Page 34)

  • Page 57: Printed Wiring Board - Motor Section

    SAVA-D900/D900FR/D900R/SS-T900 5-27. Printed Wiring Board – MOTOR Section – • See page 28 for Circuit Boards Location. There are few cases that the part printed on this diagram isn’t mounted in this model. (Page 32) (Page 32)

  • Page 58: Printed Wiring Board - Ps Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 28 for Circuit Boards Location. 5-28. Printed Wiring Board – PS Section – There are few cases that the part printed on this diagram isn’t mounted in this model. • Semiconductor (Page 49) Location Ref. No. Location...
  • Page 59 SAVA-D900/D900FR/D900R/SS-T900 There are few cases that the part printed on this diagram isn’t mounted in this model. 1-677-431...

  • Page 60: Schematic Diagram - Ps (1/2) Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 70 for IC Block Diagrams. 5-29. Schematic Diagram – PS (1/2) Section –...

  • Page 61: Schematic Diagram - Ps (2/2) Section

    SAVA-D900/D900FR/D900R/SS-T900 5-30. Schematic Diagram – PS (2/2) Section – RY1901...

  • Page 62: Printed Wiring Board - Power Section

    SAVA-D900/D900FR/D900R/SS-T900 • See page 28 for Circuit Boards Location. 5-31. Printed Wiring Board – POWER Section – There are few cases that the part printed on this diagram isn’t mounted in this model. (Page 58) (Page 58)

  • Page 63: Ic Pin Functions

    5-32. IC PIN FUNCTIONS • IC202 DIGITAL SERVO & DIGITAL SIGNAL PROCESSOR (MB911101APFV-G-BND) (DVD Board) Pin No. Pin Name Function DREQ2/PB5/CS1L Analog filter gain control DACK2/PB6/CS1H VES gain control “H” : VES PB7/DW1 Rear CH boost “H” : rear boost VCC3 –...
  • Page 64 Pin No. Pin Name Function Address bus A8 Address bus A9 Address bus A10 Address bus A11 Address bus A12 Address bus A13 Address bus A14 Address bus A15 A16/P60 Address bus A16 A17/P61 Address bus A17 A18/P62 Address bus A18 A19/P63 Address bus A19 A20/P64...
  • Page 65 • IC903 I/F MICROCOMPUTER (M30622MA-A38FP) (DVD Board) Pin No. Pin Name Function IFSIO Data output for SYS COM IFSCO Clock input for SYS COM YSSCSB Chip select for SUB DSP (YSS912) YSS_CS Chip select for MIN DSP (YSS912) YSS_CI Data output for DSP (YSS912) YSS_SO Data input for DSP (YSS912) YSSCK...
  • Page 66 Pin No. Pin Name Function TUN_DO Data output for LC72137 TUN_DI Data input for LC72137 TUNED Tuning end for LC72137 FAULT/BTCE1 FAULT for digital amplifier PROTECT/BTCE2 PROTECT for digital amplifier VOL_CE Chip enable for IC507 (TC9482) VOL_DAT Data output for IC507 (TC9482) VOL_CLK Clock for IC507 (TC9482) SWMUTE...

  • Page 67: Ic Block Diagrams

    5-33. IC BLOCK DIAGRAMS • DVD BOARD IC005, 404 NJM2370U33-TE2 THERMAL PROTECTION NOISE BYPASS BANDGAP REFERENCE IC202 MB91101APFV-G-BND 100 99 98 97 96 95 94 93 92 91 90 89 88 87 86 85 84 83 82 81 80 79 78 77 76 75 AN3 CS1L/PB5/DREQ2 74 AN2...
  • Page 68 IC204 IDT71V016S20PHAU-TL IC304 MSM51V18160D-60TSKR1 ADDRESS BUFFER ON CHIP GENERATOR DQ16 OUTPUT OUTPUT BUFFERS BUFFERS ROW/COLUMN DQ13 DECODERS OUTPUT ENABLE BUFFER DQ12 BYTE ENABLE INPUT INPUT BUFFER CHIP ENABLE BUFFERS BUFFERS BUFFER I/O 0 I/O15 SELECTOR 64K X 16 I/O 1 I/O14 MEMORY ARREY...
  • Page 69 IC701 CXD8791AQ 128 127 126 108 107 106 105 104 103 HRD/HRXD TEST SIB0 INT6N HWR/HFS TEST SIB1 Clock Host Generator GNDAS Interface VCCAS HA0/HCK VRT0 DAB0 8-bit DAC0 PWM2 VRB0 8-bit PWM1 VDD3V3 PWM0 PWM0 VSS3V3 256 word VRB1 8-bit 8-bit SARAM...

  • Page 70: Amp Board

    • DISP BOARD • CLAMP MOTOR BOARD,LOAD MOTOR BOARD IC1602 NJU3719 IC701 M54641L PARALLEL DATA OUTPUT BUFFER REFERENCE LATCH POWER OUT2 INPUT AMP. CIRCUIT AMP. CONTROL SHIFT POWER OUT1 INPUT REGISTER AMP. AMP. CONTROL CIRCUIT DATA • AMP BOARD • PS BOARD IC1706 STK350-230 IC1802 uPC1237HA OVER LOAD DET...
  • Page 71 • MAIN BOARD IC1201,IC1203 TC9184AP...

  • Page 72: Exploded Views

    6-1. OVERALL SECTION SAVA-D900FR SAVA-D900FR (Front speaker) (Front speaker) SS-T900 (Center/Rear speaker) SAVA-D900R SAVA-D900 (Woofer speaker) (Main unit) Ref. No. Part No. Description Remarks X-4952-875-1 BASE ASSY 4-967-287-01 CUSHION (A) 4-914-430-11 SCREW(4X20), TAPPING...

  • Page 73: Main Unit (Sava-D900) Section

    Ver 1.1 2002.01 6-2. MAIN UNIT (SAVA-D900) SECTION supplied supplied supplied MECHANISM SECTION AMPLIFIER SECTION Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-4952-874-1 FRAME (B) ASSY, GRILLE A-4473-108-A DISP BOARD, COMPLETE 4-914-430-11 SCREW (4X20), TAPPING...

  • Page 74: Main Chassis Section

    6-3. MAIN CHASSIS SECTION supplied supplied FAN101 CDM53J-DVBU1 supplied supplied supplied supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks A-4473-102-A DVD BOARD, COMPLETE 1-792-675-11 WIRE (FLAT TYPE)(18 CORE) A-4473-105-A MAIN BOARD, COMPLETE 1-792-672-11 WIRE (FLAT TYPE)(15 CORE) A-4473-110-A S-VIDEO BOARD, COMPLETE 1-792-679-11 WIRE (FLAT TYPE)(12 CORE) A-4473-113-A CONNECT BOARD, COMPLETE...

  • Page 75: Amplifier Chassis Section

    6-4. AMPLIFIER CHASSIS SECTION supplied T900 supplied supplied FAN371 supplied supplied with Q1704, 1705 supplied supplied supplied supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks A-4473-116-A STBY BOARD, COMPLETE 4-228-035-01 PANEL (L/B), BACK A-4473-117-A REG BOARD, COMPLETE 4-228-034-01 PANEL (L/A), BACK A-4473-115-A PS BOARD, COMPLETE 4-217-350-11 STOPPER, CORD...

  • Page 76: Mechanism Section-1 (Cdm53J-Dvbu1)

    6-5. MECHANISIM SECTION-1 (CDM53J-DVBU1) M702 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 4-951-620-41 SCREW (2.6), +BVTP * 215 4-214-129-01 COVER 1-675-728-11 LOAD MOTOR BOARD 4-211-235-01 BELT (COMMUNICATION) 4-211-215-01 GEAR (EJECT) 4-211-236-01 BELT (LOADING) 1-675-724-11 INIT/COUNT SW BOARD 4-211-231-01 PULLEY (MODE) 1-675-726-11 SENSOR BOARD 4-211-214-01 PULLEY (LD)

  • Page 77: Mechanism Section-2 (Cdm53J-Dvbu1)

    6-6. MECHANISIM SECTION-2 (CDM53J-DVU1) supplied supplied S707 supplied M701 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 4-985-672-01 SCREW (+PTPWH M2.6), FLOATING 4-211-245-01 SPRING, COMPRESSION 3-053-847-01 INSULATOR 4-951-620-41 SCREW (2.6), +BVTP 4-223-291-02 TRAY (DVD) 4-211-221-01 GEAR (LD MOVABLE) 4-211-208-12 CHASSIS (MOLD) 4-211-217-02 GEAR (SELECTION) 4-223-292-02 HOLDER (DVD)

  • Page 78: Woofer Speaker (Sava-D900R) Section

    Ver 1.1 2002.01 6-7. WOOFER SPEAKER (SAVA-D900R) SECTION supplied supplied supplied supplied supplied SP401 supplied supplied supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-4952-878-1 PANEL (R) ASSY, DISPLAY 4-228-007-01 PANEL (R), BACK X-4952-874-1 FRAME (B) ASSY, GRILLE A-4412-182-A CABINET (R) ASSY, SPEAKER X-4953-236-1 PANEL (B/R) ASSY SP401...

  • Page 79: Front Speaker (Sava-D900Fr) Section

    6-8. FRONT SPEAKER (SAVA-D900FR) SECTION supplied supplied SP502 supplied supplied SP501 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-4952-877-1 FRAME (A) ASSY, GRILLE 4-874-614-21 SCREW (4) (3.5X14), TAPPING X-4952-895-1 CABINET (A) ASSY, SPEAKER SP501 1-529-671-11 SPEAKER (10cm) X-4953-234-1 PANEL (A) ASSY, FRONT SP502 1-529-673-11 SPEAKER (2.5cm)

  • Page 80: Center/Rear Speaker (Ss-T900) Section

    6-9. CENTER/ REAR SPEAKER (SS-T900) SECTION supplied SP602 SP602 SP601 supplied Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks X-4952-880-1 FRAME ASSY, GRILLE A-4412-183-A CABINET ASSY, SPEAKER X-4953-237-1 PANEL (ST) ASSY, FRONT SP601 1-529-673-11 SPEAKER (2.5cm) 4-874-614-21 SCREW (4) (3.5X14), TAPPING SP602 1-529-672-11 SPEAKER (8cm)

  • Page 81: Electrical Parts List

    SECTION 7 ELECTRICAL PARTS LIST NOTE: • Due to standardization, replacements in the • CAPACITORS: • SEMICONDUCTORS parts list may be different from the parts uF: µF In each case, u: µ, for example: specified in the diagrams or the components •...
  • Page 82 CONNECTOR CLAMP MOTOR DISP Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R1711 1-216-049-91 RES-CHIP 1/10W < TRANSISTOR > R1712 1-216-085-00 METAL CHIP 1/10W R1713 1-216-037-00 METAL CHIP 1/10W Q701 8-729-029-66 TRANSISTOR DTC114ESA R1714 1-216-085-00 METAL CHIP 1/10W R1715 1-249-381-11 CARBON...
  • Page 83 DISP Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < DIODE > R1638 1-216-029-00 METAL CHIP 1/10W R1639 1-216-029-00 METAL CHIP 1/10W D1605 8-719-032-86 DIODE SEL5420E (DVD) R1640 1-216-029-00 METAL CHIP 1/10W D1606 8-719-032-86 DIODE SEL5420E (TUNER) R1641 1-216-029-00 METAL CHIP 1/10W...
  • Page 84 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks A-4473-102-A DVD BOARD, COMPLETE C333 1-162-970-11 CERAMIC CHIP 0.01uF C334 1-162-970-11 CERAMIC CHIP 0.01uF ******************** C337 1-162-970-11 CERAMIC CHIP 0.01uF < CAPACITOR > C338 1-162-970-11 CERAMIC CHIP 0.01uF C339 1-162-970-11 CERAMIC CHIP 0.01uF...
  • Page 85 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C607 1-162-970-11 CERAMIC CHIP 0.01uF C914 1-162-970-11 CERAMIC CHIP 0.01uF C608 1-162-970-11 CERAMIC CHIP 0.01uF C915 1-107-826-91 CERAMIC CHIP 0.1uF 10.00% 16V C701 1-162-970-11 CERAMIC CHIP 0.01uF C916 1-104-851-11 TANTAL.
  • Page 86 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < DIODE > FB085 1-216-801-11 METAL CHIP 1/16W FB087 1-216-801-11 METAL CHIP 1/16W D701 8-719-073-01 DIODE MA111-(K8).S0 FB105 1-469-760-21 INDUCTOR D801 8-719-059-50 DIODE MA3J142D0LSO FB106 1-469-760-21 INDUCTOR D802 8-719-073-01 DIODE MA111-(K8).S0 FB901 1-469-760-21 INDUCTOR...
  • Page 87 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks FB965 1-469-681-21 INDUCTOR IC302 8-759-486-55 IC NJM2370U33-TE2 FB966 1-469-681-21 INDUCTOR IC303 8-759-567-27 IC CXD8784R FB967 1-469-760-21 INDUCTOR IC304 8-759-583-44 IC MSM51V18160D-60TSKR1 FB968 1-469-681-21 INDUCTOR IC401 8-752-398-60 IC CXD1930BQ FB969 1-469-760-21 INDUCTOR IC402...
  • Page 88 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R014 1-216-801-11 METAL CHIP 1/16W R329 1-216-833-91 RES-CHIP 1/16W R035 1-216-821-11 METAL CHIP 1/16W R330 1-216-833-91 RES-CHIP 1/16W R036 1-216-821-11 METAL CHIP 1/16W R331 1-216-833-91 RES-CHIP 1/16W R037 1-216-825-11 METAL CHIP 2.2K 1/16W...
  • Page 89 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R553 1-216-295-91 SHORT R822 1-216-845-11 METAL CHIP 100K 1/16W R601 1-216-833-91 RES-CHIP 1/16W R823 1-216-833-91 RES-CHIP 1/16W R602 1-216-833-91 RES-CHIP 1/16W R824 1-216-833-91 RES-CHIP 1/16W R604 1-216-833-91 RES-CHIP 1/16W R825 1-216-830-11 METAL CHIP...
  • Page 90 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R927 1-216-821-11 METAL CHIP 1/16W R997 1-216-833-91 RES-CHIP 1/16W R928 1-216-833-91 RES-CHIP 1/16W R999 1-216-821-11 METAL CHIP 1/16W R929 1-216-833-91 RES-CHIP 1/16W R1000 1-216-821-11 METAL CHIP 1/16W R933 1-216-833-91 RES-CHIP 1/16W R1001...
  • Page 91 INIT/COUNT SW IN SW LOAD MOTOR MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks 1-675-724-11 INIT/COUNT SW BOARD C1111 1-136-165-00 MYLAR 0.1uF 5.00% 50V C1112 1-136-165-00 MYLAR 0.1uF 5.00% 50V ****************** C1138 1-216-295-91 SHORT < SWITCH > C1141 1-124-903-11 ELECT 20.00% 50V...
  • Page 92 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C1259 1-126-964-11 ELECT 10uF 20.00% 50V C1932 1-104-665-11 ELECT 100uF 20.00% 25V C1260 1-126-964-11 ELECT 10uF 20.00% 50V C1945 1-216-295-91 SHORT C1261 1-126-964-11 ELECT 10uF 20.00% 50V C1301 1-136-161-00 MYLAR 0.047uF...
  • Page 93 MAIN Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < TRANSISTOR > R1218 1-216-095-00 METAL CHIP 1/10W R1219 1-216-099-00 METAL CHIP 120K 1/10W Q1301 8-729-040-96 TRANSISTOR 2SD1938(F) R1220 1-216-099-00 METAL CHIP 120K 1/10W Q1302 8-729-040-96 TRANSISTOR 2SD1938(F) R1221 1-216-113-00 METAL CHIP 470K...
  • Page 94 MAIN OUT SW Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R1315 1-216-057-00 METAL CHIP 2.2K 1/10W R1507 1-216-295-91 SHORT R1316 1-216-097-91 RES-CHIP 100K 1/10W R1508 1-216-295-91 SHORT R1317 1-216-073-00 METAL CHIP 1/10W R1509 1-216-295-91 SHORT R1318 1-216-057-00 METAL CHIP 2.2K...
  • Page 95 Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks C1805 1-104-665-11 ELECT 100uF 20.00% 25V * CN1905 1-564-243-11 PIN, CONNECTOR 6P C1806 1-126-964-11 ELECT 10uF 20.00% 50V * CN1906 1-564-242-00 PIN, CONNECTOR 5P C1807 1-162-290-31 CERAMIC 470PF CN1907 1-766-268-11 PIN, CONNECTOR (PC BOARD) 6P C1808 1-162-290-31 CERAMIC...
  • Page 96 SENSOR SENSOR2 STBY Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < IC > R1907 1-249-437-11 CARBON 1/4W R1908 1-260-292-11 CARBON 1/2W IC1604 8-759-708-08 IC NJM78L08A R1909 1-260-292-11 CARBON 1/2W IC1802 8-759-111-68 IC uPC1237HA R1923 1-249-381-11 CARBON 1/4W F IC1904 8-759-605-00 IC M5F78M07L...
  • Page 97 STBY S-VIDEO Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < CAPACITOR > C1129 1-104-665-11 ELECT 100uF 20.00% 16V C1130 1-165-319-11 CERAMIC CHIP 0.1uF 0 C1912 1-136-153-00 FILM 0.01uF C1131 1-165-319-11 CERAMIC CHIP 0.1uF C1915 1-136-153-00 FILM 0.01uF C1132 1-163-105-00 CERAMIC CHIP...
  • Page 98 S-VIDEO THERMO VIDEO Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks R1119 1-216-073-00 METAL CHIP 1/10W < DIODE > R1120 1-216-295-91 SHORT R1121 1-216-042-00 METAL CHIP 1/10W D003 8-719-073-01 DIODE MA111-(K8).S0 R1122 1-216-042-00 METAL CHIP 1/10W R1123 1-216-042-00 METAL CHIP 1/10W...
  • Page 99 VIDEO V-CONNECT Ref. No. Part No. Description Remarks Ref. No. Part No. Description Remarks < CONNECTOR > ACCESSORIES & PACKING MATERIALS ******************************* CN1809 1-695-092-11 SOCKET, CONNECTOR 7P 1-418-924-11 COMMANDER, STANDARD (RM-PP900) < IC > 1-754-147-11 ANTENNA (FM) 1-754-149-11 LOOPANT (AM) IC1101 8-759-710-29 IC NJM2235M 1-769-108-11 CORD,CONNECTION (VIDEO)
  • Page 100 SAVA-D900/D900FR/D900R/SS-T900 REVISION HISTORY Clicking the version allows you to jump to the revised page. Also, clicking the version at the upper right on the revised page allows you to jump to the next revised page. Ver. Date Description of Revision 2000.06...
