3COM O FFICE CO NNEC T
®

Specifications

F R E E D O M T O C H O O S E A B E T T E R N E T W O R K
WIRELESS 108Mbps 11G POE ACCESS POINT DATA SHEET
®
Minimum System Requirements
Computer with an Ethernet 10BASE-T, 10/100, or
10/100/1000 interface configured for Internet commu-
nication
Operating system that supports an Ethernet connec-
tion with an IP stack (Installation CD requires
Windows 98, Windows ME, Windows XP, or
Windows 2000)
PCs and laptops require 802.11g or 802.11b adapter
cards for wireless access
Interfaces
RJ-45, 10BASE-T/100BASE-TX Ethernet port with
802.3af PoE support
DB-9 female RS-232 serial console port
802.11b/g Wi-Fi compliant
Wireless Data Rates
802.11g: 108, 54, 48, 36, 24, 18, 12, 9 & 6 Mbps
802.11b: 11, 5.5, 2 & 1 Mbps
Frequency Band
802.11b/g: 2.4-2.4835 GHz
Wireless Transmit Power
18 dBM
Users Supported
Up to 64 simultaneous 802.11b/g wireless users
1024 total MAC addresses supported
Operating Range
Indoor maximum: 100 meters (328 feet)
Outdoor maximum: 457 meters (1,499 feet)
Operating Channels:
802.11g: 11 for North America, 13 for Europe (ETSI),
14 for Japan
802.11b: 11 for North America, 13 for Europe (ETSI),
14 for Japan
Modulation Technique
DSSS (Direct Sequence Spread Spectrum)
OFDM (Orthogonal Frequency Division Multiplexing)
Media Access Protocol
CSMA/CA
PoE Power Consumption
4.67 Watts
Receive Sensitivity
802.11g:
108 Mbps: - 68 dBm
54 Mbps: - 71.5 dBm
48 Mbps: - 73 dBm
36 Mbps: - 78 dBm
24 Mbps: - 82 dBm
18 Mbps: - 83 dBm
12 Mbps: - 88 dBm
11 Mbps: - 86 dBm
9 Mbps: - 88 dBm
6 Mbps: - 90dBm
802.11b:
11 Mbps: - 85 dBm
5.5 Mbps: - 89 dBm
2 Mbps: - 90 dBm
1 Mbps : - 93 dBm
Standards Conformance
Wi-Fi certified, IEEE 802.11b, IEEE 802.11g,
IEEE 802.3, IEEE 802.3af, IEEE 802.1X, IEEE 802.1Q,
AES, WPA, WEP, HTTP, SNMP
Antenna
One removable 2dB Gain antenna with RP-SMA
connector
Security
WPA AES and TKIP encryption; 64/128/152-bit WEP
encryption; 802.1X with EAP-TLS, EAP-TTLS, and
PEAP; WPA-PSK authentication; MAC address
authentication and filtering; 802.1Q VLAN; multiple
SSID; RADIUS client authentication, authorization,
and accounting
Networking Protocols
TCP/IP, Bridging Protocol, DHCP, HTTP, FTP,
NetBIOS, WINS
Performance
Dynamic rate shifting
Packet bursting
Clear channel connect
802.11g SuperG mode
Management
Command line interface (via Telnet or SSH)
HTTP or S-HTTP Web browser interface
SNMP support
Access Point Discovery program
Auto configuration
Syslog support
DHCP client support
Pre-set defaults
Upgradeable firmware
LEDs
Power, LAN Activity, Status, Wireless activity
Power Supply
24 VDC, 300mA
Physical Dimensions
Width: 14.1 cm (5.5 in)
Depth: 10.0 cm (3.9 in)
Height: 2.7 cm (1.0 in)
Weight: 1.0 kg (2.2 lb)
Regulatory/Agency Approvals
Safety:
EN 60950, IEC 60950 Edition 3, UL 60950 3rd
edition,/CSA 22.2 60950, European Community
CE notice
Emissions:
Canada ICES-003 Class B, FCC Part 15, Class B, EN
55022 Class B, CISPR 22 Class B, CNS 13438 Class A,
ETSI EN 301 489-17
Environmental:
EN60060 (IEC68), UL listed-CSA certified
Environmental Operating Ranges
Operating temperature: 0 to 50°C (32 to 122 °F)
Storage temperature: -20 to 70°C (-4 to 158 °F)
Humidity: 0 to 90 percent non-condensing
Package Contents
3Com ® OfficeConnect ® Wireless 108Mbps 11g PoE
Access Point
24-volt power adapter
CD-ROM with Quick Start and User Guide and
configuration software
Warranty booklet
Warranty
Three year hardware warranty with advanced hard-
ware replacement and 90 days free technical support.
Refer to www3com.com/warranty for details.
