For 128-bit encryption:
Hexadecimal: 26 hexadecimal digits in the range of "A-F", "a-f " and "0-9"
(e.g. 00112233445566778899AABBCC).
For 152-bit encryption:
Hexadecimal: 32 hexadecimal digits in the range of "A-F", "a-f " and "0-9"
(e.g. 00112233445566778899AABBCCDDEEFF).
4. When you are done, click the Apply button and click OK for the changes to take effect.
Important Note: The WEP keys must be set up exactly the same on all wireless devices in
order to communicate with each other.
This table describes the options available from the Security section:
Security Description
Enable WEP Enables the data encryption for the wireless node. If you disable the
Encryption data encryption (by unchecking the box) then no encryption method
will be used; this is also called Open System data encryption. To enable
encryption is to use the Shared Key data encryption method.
Create with A Passphrase is use to automatically generate the WEP hexadecimal
Passphrase numbers for the key. If your wireless network Access Point uses a
Passphrase, you can use that here.
Once you type in the Passphrase, the generated key will be shown
before you click OK or Apply button.
Manual Entry The WEP hexadecimal numbers are needed if a Passphrase is not used
in the wireless Access Point but rather if the key is manually entered.
Key Length The key length must be the same between all wireless nodes and Access
Points in the same network. The possible values for the data encryption
level are 64-bit, 128-bit, and 152-bit. The 64-bit data encryption is
also called 40-bit data encryption by some vendors.
Note: The 152-bit encryption mode only applies to the 802.11a mode.
Key1 The WAG511 device uses a selected WEP key to encrypt and decrypt
information. When set to 64-bit (also called 40-bit), 128-bit data
Key2
encryption mode, or 152-bit, you may specify up to four different keys
Key3 to encrypt wireless data.
Key4
Select one of the keys as a default key.
Note: The 152-bit only apply on 802.11a mode.
14
Profile Section
The Profile area allows you to set values for all parameters by selecting a previously defined profile.
To create a profile, in the Profile Name field, type a Profile Name; for example: Home, Office.
When you are done, click the Save button in the Profile area, and click Apply. If one of the
profiles is no longer used, display the name in the Profile Name field, then choose Delete. You
can add and modify multiple profiles at any time.
Stations Section
The Stations section displays all of the Access Points and the Ad-Hoc Stations that are available.
To display Access Points around the working environment, select the Re-Scan button. In
addition to showing the MAC Address of each Access Point, you can also view the Channel,
Signal, Security, and Network Modes.
