Connecting a computer source

VGA connection

Connect one end of the provided computer cable to the Computer in 1/
Computer in 2 connector on the projector and the other to the VGA connector
on your computer. If you are using a desktop computer, you will need to
disconnect the monitor cable from the computer's video port first.
HDMI connection (IN116 only)
HDMI is a standard, uncompressed, all-digital audio/video interface. HDMI
provides an interface between sources, such as set-top boxes, DVD players, and
receivers and your projector. Plug an HDMI cable into the video-out connector on
the video device and into the HDMI connector on the projector.

Connecting power

Connect the black power cord to the Power connector on the rear of the
projector and to your electrical outlet. If the Power Saving Mode feature is off, the
Power LED on the Status Indicator Panel (page 11) blinks blue. If the Power Saving
Mode feature is on, the Power LED is steady blue. By default, this feature is off.
You can change the setting, see page 28. NOTE: Always use the power cord that
shipped with the projector.

Optional computer connections

To get sound from the projector, connect an audio cable (optional cable, not
included) to your computer and to the Audio in connector on the projector. You
may also need an adapter.
If you are using a desktop computer and want to see the image on your computer
screen as well as on the projection screen, connect to the desktop's computer
cable to Computer 1 and the desktop's monitor cable to the Computer out
connector on the projector.
connect VGA cable
connect HDMI (IN116 only)
connect power
connect audio cable
7
