  • Page 3 This document applies to regulatory model IN112a/IN114a/IN116a/IN112aT/IN114aT/ for collection or recycling options. IN114STa Input ratings: 100-240Vac, 2.6A, 50-60Hz InFocus reserves the right to alter product offerings and specifications at any time without notice.

  • Page 4: Table Of Contents

    Table of Contents Introduction Positioning the projector Connecting a computer source VGA connection Connecting power Optional computer connections Displaying an image Adjusting the image Connecting a video device Video device connections HDMI connection Composite video connection VGA connection Component video connection S-video connection Audio Shutting down the projector...
  • Page 5 Place the projector in a horizontal position no greater than 15 degrees off • Only genuine InFocus lamps are tested for use in this projector. Use of non axis. InFocus lamps may cause electrical shock and fire, and may void the projector •...

  • Page 6: Introduction

    IN112a/IN112aT has native SVGA 800 x 600 resolution, IN114a/IN114aT/IN114STa has native XGA 1024 x 768 resolution, and IN116a has native WXGA 1280 x 800 resolution. It is compatible with a wide variety of computers and video devices.
  • Page 7 Connector panel IN112a/IN114a/IN116a/IN114STa The projector provides both computer and video connection options, including: S-video RS 232 • VGA computer (2) computer HDMI audio in/out • Composite video (model dependent) • HDMI (model dependent) • S-video (model dependent) • USB connector for firmware upgrades, mouse control and Screen Save mode.

  • Page 8: Positioning The Projector

    IN112aT and IN114a/IN114aT must be at least 45.3” (1.2m) from the projection 40”/1.0m 32”/0.8m 62”/1.6m 69”/1.7m screen, IN116a must be at least 55.4” (1.4m) from the projection screen, and IN114STa must be at least 15” (0.4m) from the projection screen. 60”/1.5m 48”/1.2m 94”/2.4m 103”/2.6m...

  • Page 9: Connecting A Computer Source

    Connecting a computer source connect VGA cable VGA connection Connect one end of the provided computer cable to th Computer 1/Computer 2 connector on the projector and the other to the VGA connector on your computer. If you are using a desktop computer, you will need to disconnect the monitor cable from the computer’s video port first.

  • Page 10: Displaying An Image

    Displaying an image press Power button Press the Power button. The Power LED lights blue, and the fans start to run. When the lamp comes on, the start up screen displays. It can take up to a minute for the image to achieve full brightness.

  • Page 11: Adjusting The Image

    Adjusting the image adjust height If necessary, adjust the height of the projector by rotating the elevator foot to extend the foot. elevator foot If necessary, rotate the leveling foot located at the rear of the projector. Avoid placing your hands near the hot exhaust vent at the front of the projector. adjust distance Position the projector the desired distance from the screen at a 90 degree angle to the screen.

  • Page 12: Connecting A Video Device

    No video cables are provided with the projector. You can order cables from Audio InFocus or provide your own. For audio, connect a 3.5mm stereo cable to the Audio 1/Audio 2 connector on the projector and to your source. If your source uses RCA audio connectors, a Y- HDMI connection cable or adapter may be used.

  • Page 13: Shutting Down The Projector

    LAMP: Blinking red The lamp failed to ignite. POWER: Solid blue Contact Technical Support if the problem TEMP: Blinking red persists. Visit www.infocus.com/support LAMP: Blinking red to contact service. POWER: Solid blue The lamp has reached its end of life and must be replaced.
  • Page 14 Problem Solution Result Correct image No start up screen Plug power cord into the projector press the Power button Press the SOURCE button Computer image projected Only start up screen appears activate laptop’s external port Restart laptop...
  • Page 15 Problem Solution Result Press the Auto Image button on remote Computer image projected No computer image, just the words “Signal out of Adjust computer refresh rate (Windows 7: Control range” Panel > Display > Screen Resolution > Advanced Settings > Adapter tab). Varies per operating system. You may also need to set a different resolution on your computer, as shown in the following problem, “image fuzzy or cropped”...
  • Page 16 Problem Solution Result Change the computer's "Resolution" setting to match Image fuzzy or cropped Image clear and not cropped the projector's resolution (Windows 7: Control Panel > Display > Screen Resolution). Varies per operating system. Move projector, adjust height Correct image Image not centered on screen MDL: IN112a FW: 0.14...
  • Page 17 Problem Solution Result Image not square Adjust Keystone on keypad Square image Adjust Sharpness in the Basic Menu Image not sharp Correct image Basic Menu MDL: IN112a FW: 0.14 Aspect Ratio Auto Auto Image Execute Brightness Contrast Auto Keystone Keystone Presets Presentation Sharpness...
  • Page 18 Problem Solution Result Turn off Ceiling Mount in Basic menu Correct image Image upside down Basic Menu MDL: IN112a FW: 0.14 Aspect Ratio Auto Auto Image Execute Brightness Contrast Auto Keystone Keystone Presets Presentation Sharpness Volume Ceiling Mount Advanced Menu Turn off Rear Project in Advanced Menu >...
  • Page 19 Problem Solution Result Turn off the internal LCD display on your laptop The video embedded in my PowerPoint presentation Embedded video plays correctly does not play on the screen Make sure vents aren’t blocked, turn off the projector Lamp turns on Lamp won’t turn on, the projector is overheating and allow it to cool for one minute Overheating...
  • Page 20 Still need assistance? If you need assistance, visit our website at www.infocus.com/support or call us. See the Quick Start Guide for support contact information. This product is backed by a limited warranty. An extended warranty plan may be purchased from your dealer.

  • Page 21: Using The Remote Control

    Using the remote control • Auto Image button to resynch the projector to the source. • Resize button to switch among aspect ratios (see page 25). The remote uses two (2) AAA batteries (not provided). They are easily installed • Help button to get help with connecting sources and improving the picture.

  • Page 22: Using The Audio

    Using the audio connect audio cable Using the projector’s speakers Connect the audio source to the Audio 1/Audio 2 connectors to hear audio through the projector speakers. Amplified speakers may also be connected to the projector using the Audio Out connector.

  • Page 23: Using The Keypad Buttons

    Using the keypad buttons Most buttons are described in detail in other sections, but here is an overview of their functions: Power–turns the projector on and off (page 8). Right arrow - When the menu is displayed, the right arrow button navigates through the menu.

  • Page 24: Optimizing Computer Images

    Optimizing computer images Presentation features Several features are provided to make giving presentations easier. Here is an After the projector is running and the image is on the screen, you can optimize the overview, details are found in the menu section. image using the onscreen menus.

  • Page 25: Optimizing Video Images

    Optimizing video images Customizing the projector You can customize the projector for your specific setup and needs. See page 27 After your video device is connected properly and the image is on the screen, you for details on these features. can optimize the image using the onscreen menus.

  • Page 26: Using The Menus

    Using the menus To open the menus, press the Menu button on the keypad or remote. (The menus automatically close after 60 seconds if no buttons are pressed.) Use the keypad navigation buttons arrow buttons to move up and down to review the menu options. To enter a submenu, highlight the desired submenu and press >...

  • Page 27: Basic Menu

    Basic Menu Basic Menu To adjust the following settings, highlight the setting, use the right and left arrows Basic Menu MDL: IN112a FW: 0.14 to adjust the values. Aspect Ratio ◄ Auto ► Auto Image Execute Aspect Ratio: Aspect ratio is the ratio of the image width to image height. TV Brightness screens are usually 4:3.

  • Page 28: Advanced Menu

    Advanced Menu White Intensity: increases the brightness of whites that are near 100%. Image: Force Wide: when this is off, the analog locking algorithms choose the stan- 3D Control: dard mode resolution (4:3) as the preferred default resolution. When this is 3D: allows you to enjoy 3D (stereoscopic) content.
  • Page 29 Ceiling Mount: turns the image upside down for ceiling-mounted projection. Advanced Menu Advanced Menu Rear Project: reverses the image so you can project from behind a translu- MDL: IN112a FW: 0.14 cent screen. Image 3D Control... Setup Color... Keypad/Remote Settings... Status/Service PC...
  • Page 30 4-button press sequence. If menu. you enter an incorrect PIN 3 times in succession, the projector will automat- ically shut down. If you lose or forget your custom PIN, contact InFocus Power-up Source: determines which source the projector checks first for Technical Support.
  • Page 31 Timer Auto Off Time: automatically turns the projector off after no signals are detected for a preset number of minutes. If an active signal is received before the projector powers down, the image will be displayed. High Altitude Setting High Altitude: We recommend you turn on the High Altitude Mode when your environment is between 5000' (1500m) and 10,000' (3000m) above sea level.

  • Page 32: Maintenance

    Maintenance Cleaning the lens Apply a non-abrasive camera lens cleaner to a soft, dry cloth. • Projector must be off and the lens must be at room temperature. • Avoid using an excessive amount of cleaner, and don’t apply the cleaner directly to the lens.

  • Page 33: Replacing The Projection Lamp

    NOTE: Be sure to use the InFocus lamp module designed for this projector. You can order new lamps from www.infocus.com (in select areas), your retailer or your dealer. Only genuine InFocus lamps are tested for use in this projector. Use of non InFocus lamps may cause electrical shock and fire, and may void the projector warranty.
  • Page 34 Turn off the projector and unplug the power cord. turn off and unplug wait 60 minutes Wait 60 minutes to allow the projector to cool thoroughly. projector Remove the lamp door, located on top of the projector, by removing the screw on the side of the lamp door, sliding the door right, and lifting the lamp door off.
  • Page 35 Keystone 25 Computer 1/Computer 2 8 Computer 2 27 Lamp Low Power 28 Connecting Video device 11 Magnify Level 27 Contacting InFocus 19 Menu Transparency 28 Contrast 25 menu usage 24 Customer service contact information 19 Mute 27 Detect Film 26...
  • Page 36 Power connector 8 TV tuner 11 Power cord 8 Power Saving Mode 28 USB 5 Prevent PC Screen Saver 26 Programmed Dimming 28 Vert Shift 27 Projector Vertical Position 26 Connecting video devices 11 Volume 25 Keypad buttons 22 Volume button 21 Menus 24 Positioning 6 Warranty 19...
