Echelon PCC-10 User Manual

Pci network interface card
Hide thumbs Also See for PCC-10:
Table of Contents

Advertisement

Quick Links

See also: User Manual
PCC/PCLTA Network Interface
User's Guide
078-0450-01A

Advertisement

Table of Contents
loading

Related Manuals for Echelon PCC-10

Summary of Contents for Echelon PCC-10

  • Page 1 PCC/PCLTA Network Interface User's Guide 078-0450-01A...
  • Page 2 Neuron Chips and other OEM Products were not designed for use in equipment or systems which involve danger to human health or safety or a risk of property damage and Echelon assumes no responsibility or liability for use of the Neuron Chips or LonPoint Modules in such applications.

  • Page 3: Table Of Contents

    Installing and Configuring the PCLTA-20 Network Interface ....4 Installing the PCLTA-20 Hardware............. 4 Configuring the PCLTA-20 Network interface ........4 Installing and Configuring the PCC-10 Network Interface ......5 Installing the PCC-10 Card Hardware ..........5 Configuring the PCC-10 Network interface ........5 Electrical and Mechanical Interfaces..........
  • Page 4 Preface...

  • Page 5: Preface

    Preface You can install and configure a PCC-10, PCLTA-20, or PCLTA-21 PCI network interface card on your computer so that you can manage, test, and monitor and control ® ® ™ your L network with an LNS or OpenLDV application. The...

  • Page 6: Purpose

    Echelon support and training services. You can also enroll in training classes at Echelon or an Echelon training center to learn more about developing devices. You can find additional information about device development training at www.echelon.com/training/.
  • Page 7 Attn. Customer Support 550 Meridian Avenue San Jose, CA 95126 Phone (toll-free): 1-800-258-4LON (258-4566) Phone: +1-408-938-5200 Fax: +1-408-790-3801 lonsupport@echelon.com Europe English Echelon Europe Ltd. German Suite 12 French Building 6 Italian Croxley Green Business Park Hatters Lane Watford Hertfordshire WD18 8YH...

  • Page 9: Installing And Configuring The Pcc/Pclta Network Interface Cards

    Installing and Configuring the PCC/PCLTA Network Interface Cards This chapter describes how to install the PCC/PCLTA network interface cards and configure them using the L Interfaces application. ORKS PCC/PCLTA Network Interfaces User's Guide...

  • Page 10: Installing The Pcc/Pclta Network Interface Cards

    The following section describes how to install and configure the hardware for the PCLTA-21, PCLTA-20, and PCC-10 network interface cards. Make sure the driver software is installed before installing the hardware and configuring the network interface. The driver software is installed automatically when you install OpenLDV 4.0.

  • Page 11: Configuring The Pclta-21 Network Interface

    Configuring the PCLTA-21 Network interface In most cases, PCLTA-21 initialization occurs automatically upon installation of the card and subsequent power-up of the computer. Manual initialization will be required following software installation to a directory other than c:\lonworks, or after moving the PCLTA-21 system images. To manually load the firmware image to the PCLTA-21card after you have installed the hardware, follow these steps: 1.

  • Page 12: Installing And Configuring The Pclta-20 Network Interface

    ORKS ® Instructions document 078-0145-01 version D or later if using an Echelon SMX transceiver. The height of the PLM-10, PLM-2X, and PLM-30 Power Line SMX Transceivers is such that two (2) PCI slots must be allocated for a PCLTA-20 equipped with a PLM transceiver, even though the card will be plugged into only one slot.

  • Page 13: Installing And Configuring The Pcc-10 Network Interface

    Accessory and is designed to be used with UL Listed equipment. The PCC-10 is not compatible with ExpressCard slots. Do not force the insertion of a PCC-10 card. You can only insert the PCC-10 card one way into a computer PC Card slot. The keyed notches prevent the card from being inserted upside down. If you reboot the computer after installing the software, insert the PCC-10 card into an open computer PC Card slot.
  • Page 14 3. The details pane lists the PCC-10 card’s system image and transceiver properties. 4. Optionally, you can modify the PCC-10 card’s transceiver properties following these steps: Click anywhere in the Transceiver property, and then click the box to the right.
  • Page 15 Click OK to save any changes. Note: For more information on configuring, testing, and diagnosing the PCC-10 network interface, see the LonWorks Interfaces online help. PCC/PCLTA Network Interfaces User's Guide...
  • Page 16 Installing and Configuring the PCC/PCLTA Network Interface Cards...

  • Page 17: Electrical And Mechanical Interfaces

    Electrical and Mechanical Interfaces This chapter describes the hardware interfaces and mechanical layout of the PCC/PCLTA cards. PCC/PCLTA Network Interfaces User's Guide...

  • Page 18: Pclta-21 Board Layout

    PCLTA-21 Board Layout The following figure shows the layout of the PCLTA-21 card Models 74501, 74502, 74503, and 74504. The PCLTA-21 card Model 74504 (TP-RS485) includes jumpers that must be configured to set the correct speed on the RS-485 channel. P1 and P2 PCI Bus Connector The pinout of the PCI connector is the standard pinout for the 32-bit PCI bus used in Windows- compatible computers.

  • Page 19: Network Connector

    Network Connector The PCLTA-21 Model 74501-74503 cards are supplied with a removable two terminal, BLZ 5180/2/180 for the network connection. The wiring to the twisted pair channel is polarity insensitive. The connector will accept 12 to 26 AWG (1.2 mm to 0.45 mm) wire. See the Junction Box and Wiring Guidelines for Twisted Pair L Networks, L FTT-10A Free Topology Transceiver...

  • Page 20: Pclta-20 Board Layout

    The following section describes the PCC-10 board. Network Port The PCC-10 has a 15-pin network port connector for interfacing with a free topology or link power channel, and for connecting external transceiver pods. The following figure shows the numbering scheme of the 15-pin Hirose male connector on the PCC-10 card (the top of the PCC-10 card is the side with the product label).
  • Page 21 The R1 resistors used in the PCC-10 card buffer the CPx lines to and from the Neuron 3150 Chip, and have a value of 82Ω ±5%. Examples of how to interface the PCC-10 card to external transceivers can be found in Appendix A, External Transceivers. The following table describes the functions of the card’s network port.

  • Page 22: Network Connector

    The following table describes the electrical characteristics of the card’s digital inputs and outputs. Network Connector The PCC-10 card includes a standard 68-pin computer PC Card connector for interfacing with a host computer or embedded controller. This connector conforms to PCMCIA PC Card Standard, Release 2.1 guidelines for Type II I/O cards.
  • Page 23 The Switchcraft A3MBAU XLR male connector is compatible with a wide variety of female connectors, as shown in the following table. You can create a general purpose cable that includes a 15-pin Hirose connector, a two or 14-conductor cable plus shield, and flying leads for connection to a network or an external pod. An example pinout of at 14-conductor cable assembly is shown in the following table.
  • Page 24 www.echelon.com...
