- Page 1 ® ORKS PCLTA-21 PCI Interface User’s Guide Version 1 C o r p o r a t i o n 078-0271-01A...
- Page 2 Parts manufactured by vendors other than Echelon and referenced in this document have been described for illustrative purposes only, and may not have been tested by Echelon. It is the responsibility of the customer to determine the suitability of these parts for each application.
- Page 3 Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experience radio/TV technician for help. Changes or modifications not expressly approved by Echelon Corporation could void the user’s authority to operate the equipment. Safety United States...
-
Page 5: Table Of Contents
Contents FCC Notice CE Declaration of Conformance PCLTA-21 Introduction Overview Audience Content Related Documentation Installing the PCLTA-21 Card PCLTA-21 Card Software Installation Windows 2000 and XP Software Installation Procedure ® Windows 98 Software Installation Procedure Windows 2000 and XP Software Removal Procedure Windows 98 Software Removal Procedure Windows 2000 and XP Virtual-Mode DOS Driver Installation Results... - Page 6 Automatic Flush Cancel Transceiver Diagnostics General Settings Uplink Buffering PCLTA-21 Diagnostics Driver Status Diagnostic Commands Test Comm Service Restart Reset Electrical and Mechanical Interfaces PCLTA-21 Board Layout PCLTA-21 TP-RS485 Jumper Settings P1 and P2 PCI Bus Connector Network Connector Mechanical Considerations Echelon...
-
Page 7: Pclta-21 Introduction
PCLTA-21 Introduction This guide describes the mechanical characteristics and the hardware and software driver installation for the Echelon PCLTA- 21 Interface (Models 74501, 74502, 74503, 74504, and 74505). Echelon’s PCLTA-21 card is a high-performance L ® ORKS interface for desktop and embedded personal computers equipped with a 3 or 5V 32-bit PCI interface and a compatible operating system. -
Page 8: Overview
The PCLTA-21 installation software provides a software-based control panel and a software driver for Microsoft Windows 98, 2000, or XP operating system. Installation software also is available on Echelon’s web site at www.echelon.com/downloads. The control panel provides a convenient means of setting and modifying installation parameters, as well as displaying error messages. -
Page 9: Installing The Pclta-21 Card
Installing the PCLTA-21 Card This chapter describes the procedures for installing the PCLTA-21 card. PCLTA-21 PCI Interface User’s Guide... -
Page 10: Pclta-21 Card Software Installation
PCLTA-21 Card Software Installation There are two versions of the PCLTA-21 installation software, one for Windows 2000 and XP and one for Windows 98. Each version installs the files required by the associated Windows operating system to recognize the PCLTA-21 card, as well as the downloadable LNS and MIP images. -
Page 11: Windows 98 Software Installation Procedure
The path may be modified using the Browse button; however, if a directory other than c:\lonworks is chosen, the PCLTA-21 images path will have to be specified to enable use of the PCLTA-21 card. This is accomplished during PCLTA-21 Configuration. See Chapter 3, Configuring and Testing the PCLTA-21 Adapter. - Page 12 3. Open the Windows Start menu and select the Run command. 4. When prompted for a program name, enter the following: E:Win98\SETUP.EXE (where E: represents your CD ROM) 5. When prompted with a list of languages, click on the desired language. A checkmark will appear to the left of the language to be installed.
-
Page 13: Windows 2000 And Xp Software Removal Procedure
DOS applications to be used in a Windows 98 DOS shell/window. For more information see Virtual-Mode DOS Driver later in this chapter. The following line is added to the CONFIG.SYS file: DEVICE=C:\LONWORKS\BIN\LDVVDD.SYS /D1 10. Software installation is complete. At the prompt to restart the computer, remove the PCLTA-21 installation CD and shut down the computer. -
Page 14: Windows 2000 And Xp Virtual-Mode Dos Driver Installation Results
Windows 2000 and XP Virtual-Mode DOS Driver Installation Results The Windows 2000 and XP PCLTA-21 installation software will prompt the installer to automatically add the virtual-mode DOS driver. This driver is small in size, and allows a DOS session under Windows to have access to the PCLTA-21 card through the device driver running as a part of Windows. -
Page 15: Pclta-21 Card Hardware Installation
parameter you would access the 9th device, as determined by the /D9 option. These options are typically needed when more than one network interface is present in the system. ORKS PCLTA-21 Card Hardware Installation ESD Warning This product contains devices which are sensitive to static electricity. Before installing or removing the PCLTA-21 card or the network cables, discharge any static electricity which may have accumulated to earth ground by touching the case or power supply. -
Page 16: Troubleshooting
Troubleshooting As a plug-and-play device, the PCLTA-21 card should operate as desired following completion of the installation process. If the card does not function correctly, the most likely causes are system resource constraints or software incompatibilities. These problems are described in detail in the following sections. - Page 17 The PCLTA-21 L Network Interface device icon is found under the ORKS Interface device type. If there is a problem with the card, there ORKS will be a red circle with an exclamation point next to its icon. IRQ resource problems may generally be resolved by disabling another device in the system.
-
Page 18: Common Resource Problems Under Windows 98
This problem can be corrected through the use of device name aliasing. To create a device alias, follow these instructions 1. Open the file named ECHELON.INI, which should reside in the Windows directory. If this file does not exist, then create one with a text editor. -
Page 19: Lonmanager Isa Protocol Analyzer Compatibility
The following example creates a device alias that routes all service requests for LON1 to the PCCLON1 PCLTA-21 card. [DRIVERALIAS] LON1=PCCLON1 LonManager ISA Protocol Analyzer Compatibility The device driver for the PCLTA-21 card and the driver for the Model 33100-00 LonManager Protocol Analyzer ISA-bus card share the same Windows VxD identifier. -
Page 21: Configuring And Testing The Pclta-21 Card
Configuring and Testing the PCLTA-21 Card This chapter explains how to configure and test the PCLTA-21 card using the Control Panel application installed in Chapter 2. PCLTA-21 PCI Interface User’s Guide... -
Page 22: Pclta-21 Configuration
PCLTA-21 Configuration PCLTA-21 configuration is accomplished by using the L Plug ‘n Play ORKS control panel application. Open the control panel application by selecting the ® Plug ‘n Play icon in the Windows Control Panel. ORKS Figure 3.1 PCLTA-21 Control Panel and Icon The L Plug ‘n Play control panel application is divided into three ORKS... -
Page 23: Device Specific Settings
To manually initialize the PCLTA-21 card, verify that the control panel application’s System Image Path entry is correct, then click the Apply button. An error will be reported if an attempt is made to view the transceiver type before the PCLTA-21 card is initialized. Testing the card with the Diagnostics button produces the diagnosis: “Image file not found.”... -
Page 24: System Image Path
Network Image Windows XP or 2000 Windows 98 LNS Fast Network Image PCLTA21VNI PCL10VNI (LNS 3 and newer) TX LED lights every time the PCLTA-21 sends a packet. RX LED lights every time the PCLTA-21 sees a packet, whether or not it is addressed to the PCLTA-21. -
Page 25: Diagnostics
Figure 3.3 PCLTA-21 Transceiver Dialog Box Diagnostics Opens the PCLTA-21 Diagnostics dialog. For more information, see the section on PCLTA-21 Diagnostics, later in this chapter. General Settings The PCLTA-21-generic options consist of four controls (figure 3.4). These controls are defined as follows: Figure 3.4 PCLTA-21 Generic Controls Uplink Buffering For Windows 2000 and XP, this controls the number of 4Kbyte operating system... -
Page 26: Pclta-21 Diagnostics
For Windows 98, the term “Layer6 Buffering” refers to the same parameter as Uplink Buffering. There is also a “Layer2 Buffering” setting that should always be left at its default value of 20. PCLTA-21 Diagnostics A number of diagnostic and testing services are provided by the PCLTA-21 control panel application. -
Page 27: Diagnostic Commands
• Loaded Image Size: the size, in bytes, of the currently-loaded PCLTA-21 system image. This may be zero if the PCLTA-21 card is in the initial boot state. • Interrupt Count: the number of interrupts the driver has processed for this device. -
Page 28: Comm
Comm The Comm button is not available if you are using the PCLTA21VNI image. If you are using the PCLTA21VNI image, first select the PCLTA21NSI image, click Apply, run the Comm test, then reselect the PCLTA21VNI image, and click Apply. The Comm feature is not designed to work across routers. -
Page 29: Service
Service The Service button is not available if you are using the PCLTA21VNI image. If you are using the PCLTA21VNI image, first select the PCLTA21NSI image, click Apply, click the Service button, then reselect the PCLTA21VNI image, and click Apply. The Service button will cause the PCLTA-21 card to broadcast a service pin message on the network. - Page 30 Configuring and Testing the PCLTA-21 Card...
-
Page 31: Electrical And Mechanical Interfaces
Electrical and Mechanical Interfaces This chapter describes the hardware interfaces and mechanical layout of the PCLTA-21 card. PCLTA-21 PCI Interface User’s Guide... -
Page 32: Pclta-21 Board Layout
PCLTA-21 Board Layout Figure 4.1 shows the layout of the PCLTA-21 card Models 74501, 74502, 74503, and 74504. Model 74504 (TP-RS485) includes jumpers that must be configured to set the correct speed on the RS-485 channel (figure 4.2). Figure 4.1 PCLTA-21 Models 74401-74404 Mechanical Layout and Interfaces Electrical and Mechanical Interfaces... -
Page 33: Pclta-21 Tp-Rs485 Jumper Settings
TP/RS485-78 TP/RS485-39 ID = 12 ID = 5 (default) TP/RS485-625 TP/RS485-1250 ID = 10 ID = 11 Figure 4.2 PCLTA-21 TP-RS485 Jumper Settings P1 and P2 PCI Bus Connector The pinout of the PCI connector is the standard pinout for the 32-bit PCI bus used in Windows-compatible PCs. -
Page 34: Mechanical Considerations
Terminal Connection Shield RS-485 - RS-485+ Use only shielded cabling suitable for an RS-485 channel. The use of unshielded cabling could result in damage to the adapter due to common mode voltage associated with differences in ground potential between different devices. Mechanical Considerations PCLTA-21 Models 74401 –...
