Style Play operating mode
30
Keyboard/Ensemble: Keyboard Control
Keyboard/Ensemble: Keyboard Control
This page lets you enable/disable the Damper and Expression
pedals, plus the Joystick, for each of the Upper Keyboard tracks.
Damper
On
When you press the Damper pedal and release
the keys, the track's sound is kept sustained.
Off
The Damper pedal is not active on any track set
to this status.
Joystick X
This enables/disables the left/right movement of the Joystick
(Pitch Bend, and sometimes a Sound parameter's control; for
Pitch Bend settings, see "Mixer/Tuning: Tuning" on page 22).
Joystick Y
This enables/disables the front/rear movement of the Joystick
(Y+: Modulation, and sometimes a different Sound parameter's
control; Y-: Various controls, or non-active).
Expression
This parameter allows you to switch the Expression control on/
off on each individual Keyboard track. The Expression control is
a relative level control, always subtracted from the Volume value
of the track.
As an example, imagine you have a Piano sound assigned to
Upper 1, and a Strings sound assigned to Upper 2. If you turn
the Expression switch on on Upper 2, and off on Upper 1, you
can use a continuous pedal to control only the Strings' volume,
while the Piano remains unchanged.
To program a pedal or Assignable Slider to act as an Expression
control, see "Controllers: Foot Controllers" on page 146. You can
only assign this function to a volume-type pedal, not to a switch-
type one. Assign the "KB Expression" option to the pedal or
Assignable Slider, then select Write Global-Global Setup from
the page menu to save the setting to the Global.
Play/Mute icon
Track's play/mute status.
Play status. The track can be heard.
Mute status. The track cannot be heard.
Pad/Switch: Pad
This page lets you select a different hit sound or sequence for
each of the four PAD buttons.
Assignments can be saved into the current Style Settings or
SongBook entry. The Pads share the FX A group with the Style
tracks.
Note: You can also choose different Hits or Sequences from the Pad
panel of the main page.
Note: Each Style or SongBook entry can change the Pad assign-
ment.
Pad assignment
Name of the Hit or Sequence assigned to each Pad. Touch the
box to make the Pad Select window appear (see "Pad Select win-
dow" on page 8).
Volume
Volume for each of the four Pad tracks.
0...127
Volume level.
Pan
Pan for each of the four Pad tracks.
-64...-1
Left stereo channel.
0
Center.
+1...+63
Right stereo channel.
FX Send (Master 1, 2)
Send level to the Master FX processors for each of the four Pad
tracks.
0...127
Level of the Pad track (direct) signal sent to the
effect processor.
EQ Gain [dB] (Hi, Mid, Low)
Equalization for each of the four Pad tracks.
-18.0...+0.0...18.0
Gain value of the High, Middle, or Low band.
Pad lock icon
This lock avoids selecting a different Style or SongBook entry
changes also the Hit or Sequence Pads assigned to the Pads.
For more information on parameter locks, see "General Con-
trols: Lock" on page 141.
