Digicast Media Router S2 Receiver CMR-5975 (MR-S2)
Configuring and Controlling the Digicast CMR‑ 5975 Media Router with SNMP
E.5.1

Private MIB OIDs on Digicast Products

The following describes how the Enterprise (Private) MIB elements (OIDs) can be used to obtain
(GET) information or configure (SET) a parameter on the Digicast CMR-5975 Media Router.
The Enterprise MIB elements (OIDs) are broken down as follows:
OID Number
1.3.6.1.4.1.18723.5975.1.1 dniAggregateStatsTunerStats
1.3.6.1.4.1.18723.5975.1.2 dniAggregateStatsTunerAcquiState Tuner Acquisition State GET
1.3.6.1.4.1.18723.5975.1.3 dniAggregateStatsEsNo
1.3.6.1.4.1.18723.5975.1.4 dniAggregateStatsEbNo
The Enterprise Traps are broken down as follows:
Trap Name
software reset
dropping packets
dropping packets cleared
redundancy primary on
redundancy backup on
dniEbNoThreshhold
dniEbNoThreshholdFail
dniRedundancyBackup
dniRedundancyPrimary
dniRedundancyModeConflict A conflict in redundancy mode has been detected
dniMPEGPIDConflict
dniDMAOverflow
dniDMAOverflowCleared
OID
Description
Software Reset has occurred
Unit is dropping packets
Unit has stopped dropping packets
Redundancy – Primary Online
Redundancy – Backup Online
EbNo value is now set above the defined limit
EbNo value has fallen below the defined limit
Redundant backup unit is now active
Redundant primary unit is now active
MPEG-TS PID Conflict has occurred
DMA Overflow
DMA Overflow Cleared
E–11
Description GET or SET
Tuner Statistics GET
Es/No in dB GET
Eb/No in dB GET
Revision 3
MN-CMR5975-IOM
