Setting Up a Digicast Digital Satellite Receiver
D.2

Required Information for Setting Up a Digicast Satellite Receiver

To set up the Digicast receiver for receiving a live satellite feed, gather the following data:
1. Which frequency band is being used?
2. Downlink frequency of the carrier from the satellite?
3. Local Oscillator of the LNB?
4. Which DVB Type?
5. Symbol Rate?
6. Which modulation of the carrier from the satellite?
7. FEC of the carrier from the satellite?
(Range = 1/4 to 9/10 FEC)
8. Pilots:
9. Which Filter Roll Off (for DVB-S2 Only)?
10. Secondary (backup) Carrier?
11. Which LNB Power Requirement?
12. Which Spectral Inversion mode?
