- Page 1 TESLA K40 GPU ACCELERATOR BD-06902-001_v05 | November 2013 Board Specification...
- Page 2 • August 1, 2013 GG, SM Updated core clocks speeds • Updated block diagram in Figure 1 • Added new section: “NVIDIA GPU Boost on Tesla • September 19, 2013 GG, SM K40” Updated “Power Specifications” section • General updates throughout the board •...
-
Page 3: Table Of Contents
TABLE OF CONTENTS Overview ......................1 Key Features ....................2 NVIDIA GPU Boost on Tesla K40 ................3 NVIDIA GPU Boost for HPC Workloads ..............3 API for NVIDIA GPU Boost on Tesla ................ 4 Tesla K40 Block Diagram ..................6 Environmental Conditions ................... - Page 4 LIST OF FIGURES Figure 1. K40 Passive Board ................1 Figure 2. Tesla K40 Block Diagram ................ 6 Figure 3. Tesla K40 GPU Accelerator ..............8 Figure 4. Tesla K40 Bracket ................9 Figure 5. 6-Pin PCI Express Power Connector ............10 Figure 6.
-
Page 5: Overview
Tesla (267 mm length) form factor comprised of a single GK110B GPU. The Tesla K40 is designed for servers and offers a total of 12 GB of GDDR5 on-board memory and supports PCI Express Gen3. The Tesla K40 uses a passive heat sink for cooling. -
Page 6: Key Features
Memory bandwidth 288 GB/sec Interface: 384-bit Total board memory: 12 GB ● 24 pieces of 256M × 16 GDDR5, SDRAM ● BIOS 2Mbit serial ROM BAR1 size: 16 GB Tesla K40 GPU Accelerator BD-06902-001_v05 | 2... -
Page 7: Nvidia Gpu Boost On Tesla K40
Some boards in a cluster have access to better cooling than others. By default the Tesla K40 ships with the core clock set to the base clock. HPC workloads can have one or more characteristics as described. When selecting one of the supported boost clocks a good strategy is to characterize the workload with the available boost clocks. -
Page 8: Api For Nvidia Gpu Boost On Tesla
Overview API FOR NVIDIA GPU BOOST ON TESLA Tesla K40 gives full control to end-users to select the core clock frequency via NVML or . NVML is a C-based API for monitoring and managing the various states of nvidia-smi Tesla products. It provides a direct access to submit queries and commands via nvidia- . -
Page 9: Table 1. Nvidia-Smi Commands
To allow “non-root” access to change nvidia-smi -acp 0 graphics clock When using non-default applications clocks, driver persistence mode should be enabled. Persistence mode ensures that the driver stays loaded even when no NVIDIA CUDA ® ® or X applications are running on the GPU. This maintains current state, including requested applications clocks. -
Page 10: Tesla K40 Block Diagram
Overview TESLA K40 BLOCK DIAGRAM Figure 2 is the block diagram for the Tesla K40 GPU dual-slot computing processor module. Figure 2. Tesla K40 Block Diagram ENVIRONMENTAL CONDITIONS Table 2 lists the environmental operating and storage conditions for the Tesla K40 board. -
Page 11: Configuration
Overview CONFIGURATION The Tesla K40 board is available in the following configuration. Table 3. Board Configuration Specifications Tesla K40 Generic SKU reference 699-22081-0202-xxx Chip GK110B • Base clock: 745 MHz Core clocks • Boost clocks: 810 MHz and 875 MHz Memory clock 3.0 GHz... -
Page 12: Mechanical Specifications
Tesla K40 GPU Accelerator TESLA K40 BRACKET As shown in Figure 4, the Tesla K40 includes a vented bracket. If you are an OEM who qualifies for bracket modifications, you have the option of receiving your module with no bracket installed. -
Page 13: Figure 4. Tesla K40 Bracket
Mechanical Specifications Figure 4. Tesla K40 Bracket Tesla K40 GPU Accelerator BD-06902-001_v05 | 9... -
Page 14: Power Connectors
Mechanical Specifications POWER CONNECTORS The Tesla K40 GPU accelerator is a performance optimized, high-end product and uses power from the PCI Express connector as well as external power connectors. Figure 5 and Figure 6 show the specifications and Table 4 and Table 5 show the pinouts for the 6-pin and 8-pin PCI Express power connectors. -
Page 15: Figure 6. 8-Pin Pci Express Power Connector
Mechanical Specifications Figure 6. 8-Pin PCI Express Power Connector Tesla K40 GPU Accelerator BD-06902-001_v05 | 11... -
Page 16: Table 4. 6-Pin Pci Express Power Connector Pinout
6-Pin PCI Express Power Connector Pinout Pin Number Description +12 V +12 V +12 V Sense Table 5. 8-Pin PCI Express Power Connector Pinout Pin Number Description +12 V +12 V +12 V Sense1 Sense0 Tesla K40 GPU Accelerator BD-06902-001_v05 | 12... -
Page 17: Power Specifications
POWER SPECIFICATIONS The Tesla K40 GPU accelerator requires power from the PCI Express connector as well as one or two auxiliary power connectors. Table 6. Auxiliary Power Connectors 8-Pin Header 6-Pin Header Support Notes Connect 8-pin cable Connect 6-pin cable... -
Page 18: Table 7. Power Requirements
The peak current values are characterized over a 1 ms time interval, with 5-sigma confidence. These are values based on characterization data using the TDP application under TDP test conditions. Peak current values may be higher with applications that consume more power than the TDP application. Tesla K40 GPU Accelerator BD-06902-001_v05 | 14... -
Page 19: Support Information
Conformité Européenne (CE) Federal Communications Commission (FCC) Industry Canada - Interference-Causing Equipment Standard (ICES) Korean Communications Commission (KCC) Underwriters Laboratories (cUL) Voluntary Control Council for Interference (VCCI) Tesla K40 GPU Accelerator BD-06902-001_v05 | 15... -
Page 20: Languages
