- Page 1 TESLA C2075 ™ COMPUTING PROCESSOR INSTALLATION GUIdE...
- Page 2 TESL A C2075 inSTALL ATion guidE NVIdIA Tesla C2075...
-
Page 3: Table Of Contents
Equipment Hardware Installation Tesla C2075 installation Driver Installation Windows installation Verifying Windows installation Linux installation Verifying Linux installation References and Resources getting driver updates Registration, Support and Warranty Registering Your Tesla C2075 Computing board Warranty and Support Compliance and Certifications... -
Page 4: Introduction
™ are producing breakthroughs in their industries by achieving better results in a shorter period of time. Adding the nVidiA Tesla C2075 to an industry-standard workstation and configuring it with an nVidiA Quadro Professional graphics Solution enables performance scaling across a wide range of professional applications. -
Page 5: Minimum System Requirements
Minimum System Requirements Prior to unpacking your new Tesla C2075, confirm that your system meets all the system requirements for a smooth installation. > Operating System Microsoft Windows XP, Vista, Windows 7 (32-bit or 64-bit) Linux 32-bit and 64-bit on: Redhat Enterprise Linux 3.x, 4.x, 5.x... -
Page 6: Unpacking
Equipment The following equipment is included in the Tesla C2075 box. Installation CD Contains this file (installation guide), Linux drivers, and links to additional information on the Tesla C-series product. - Page 7 Tesla C2075 GPU Computing Processor installs into the PCi Express x16 slot in your computer. Power connectors and framelock connectors disabled connector Tesla C2075 Computing Processor...
-
Page 8: Hardware Installation
Tesla C2075. for the best system bandwidth between the host processor and the Tesla C2075, it is recommended (but not required) that the Tesla C2075 be installed in a PCi Express ×16 gen2 slot. because there are so many different computer systems on the market, the installation procedure for the Tesla C2075 can vary from system to system. - Page 9 The Tesla C2075 computing board is a dual-slot board and will take up two (2) slots. Save any hardware (such as screws) to use to anchor the Tesla C2075 computing board after it is seated properly. The Tesla C2075 will occupy two slots.
- Page 10 HARdWARE inSTALL ATionS Reinstall the computer cover and any cables that were removed earlier. 6-pin power connectors Connect one (1) 6-pin PCi Express power connector on the edge of the board 8-pin power connector Connect one (1) 8-pin oR one (1) 6-pin PCi Express power connector on the edge of the board Note: If you are using one 8-pin power connector, you must...
-
Page 11: Driver Installation
Power up your computer Click Cancel when the found new Hardware Wizard window displays. insert the installation Cd included in the Tesla C2075 package. Right-click on the Cd drive and select AutoPlay or explore the files on the Cd and double click setup.exe if it does not begin to auto play. - Page 12 ATion download the current display drivers for the Tesla C2075 from www.nvidia.com/drivers (make sure to select Tesla as the Product Type and C-Class as the Product Series along with the appropriate operating System). Click Agree & Download then follow instructions. once you have downloaded the software, click the Run button to begin the installation.
- Page 13 ATion double click on the Tesla C2075 driver executable file you downloaded from www.nvidia.com/drivers. Click AgREE And ConTinuE when the NVIDIA software license agreement window displays. Select an install option and click nEXT. if you select the Express (Recommended) install option, the install process will begin.
- Page 14 > 3d Vision drivers > nVidiA WMi if you select Custom (Advanced) install option, the Custom installation options screen displays to allow you to select options to be installed. if you would like to clean up your old profiles and settings, click the Perform a clean installation check box.
- Page 15 ATion Note: if you are installing the Tesla C2075 as a companion device to your primary Quadro board, a clean install is recommended. Click Continue Anyway (on Windows XP) or Install this driver software anyway (Windows Vista/7) if the Hardware installation...
- Page 16 This warning displays multiple times for each gPu in the system. Restart the computer if prompted by the user interface. Click Close to complete the installation. Note: it is highly recommended that you periodically visit www.nvidia.com/drivers to update to the latest driver versions.
-
Page 17: Verifying Windows Installation
Verifying Windows Installation it is recommended that you verify your installation by going to the Windows device Manager and verifying that the Tesla C2075 has been installed correctly and is recognized by the drivers. use the following procedure to verify the installation of the board: go to Start >... -
Page 18: Linux Installation
32-bit or 64-bit Linux driver (the driver will have a similar naming convention as.NVIDIA-Linux-x86-100.14.11-pkg1.run or NVIDIA-Linux-x86_64-100.14.11-pkg2.run). Change to the directory containing the downloaded file. Run as root the nVidiA-Linux*.run file downloaded in Step 1. As the root user you can run the following executables: cd download_directory NVIDIA-Linux-x86-xxx-xx-xx.run or NVIDIA-Linux-x86_64-xxx-xx-xx.run The NVIDIA-Linux*.run file is a self-extracting archive. - Page 19 dRiVER inSTALL ATion Select Accept to accept the License Agreement. Select Yes if a warning window displays indicating that there are drivers already installed. Selecting Yes tells the installation process to overwrite the previously installed drivers.
- Page 20 When the installer is run, it will determine if it has a precompiled kernel interface for the kernel you are running. if it does not have one, it will check if there is one on the nVidiA fTP site and download it. Select OK to compile a kernel interface.
-
Page 21: Verifying Linux Installation
Run nvidia-xconfig utility. nvidia-xconfig will find the X configuration file and modify it to use the nVidiA X driver. in most cases, you can answer Yes when the installer asks if it should run it. if you need to reconfigure your X server later, you can run nvidia-xconfig again from a terminal. -
Page 22: References And Resources
REfEREnCES And RESouRCES REfERENCES ANd RESOURCES Getting Driver Updates during nVidiA software installation, the installation wizard provides an option to check for updated software online. You can also download software updates by visiting: www.nvidia.com/drivers... -
Page 23: Registration, Support And Warranty
You can also elect to receive automatic notification of special promotions and software updates through email to ensure that your Tesla C2075 computing board continues to operate optimally. Warranty and Support The Tesla C2075 is covered by a 36 month warranty. -
Page 24: Compliance And Certifications
CoMPLiAnCE And CERTifiCATionS COMPLIANCE ANd CERTIfICATIONS The following regulatory compliance statements apply to the products documented by this manual. US federal Communications Commission Compliance fCC– federal Communications Commission Title 47 of Code of federal Regulation (CfR) part 15 CAuTion: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void the user’s authority to operate the equipment. - Page 25 CoMPLiAnCE And CERTifiCATionS > Reorient or relocate the receiving antenna. > increase the separation between the equipment and receiver. > Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. > Consult the dealer or an experienced radio/TV technician for help.
- Page 26 CoMPLiAnCE And CERTifiCATionS JAPAN COMPLIANCE VCCI - Voluntary Control Council for Interference by Information Technology Equipment > V-1/09.04: Agreement of Voluntary Control Council for interference by information Technology Equipment > V-2/09.04: Rules for Voluntary Control Measures > V-3/09.04: normative Annex 1 Technical Requirements >...
- Page 27 CoMPLiAnCE And CERTifiCATionS KOREA COMPLIANCE KC – Korea Certification > kn 22 (CiSPR 22: information technology equipment-Radio disturbance characteristics - limit and methods of measurement) > kn 24 (CiSPR 24: information technology equipment - immunity characteristics-limit and methods of measurement) b급...
- Page 28 CoMPLiAnCE And CERTifiCATionS EUROPEAN UNION COMPLIANCE CE – European Conformity (Conformité Européenne) Product comply with both the EMC directive (2004/108/ EC) and the Low Voltage directive (2006/95/EC) issued by the Commission of the European Community. Compliance with these directives implies conformity to the following European norms (The equivalent international standards are in parenthesis) >...
- Page 29 CoMPLiAnCE And CERTifiCATionS UL, CUL COMPLIANCE > uL60950-1, 2 edition, 2007-03-27: information technology equipment - Safety - Part 1: general requirement > CSA C22.2 no. 60950-1-07, 2 edition, 2007-03: information Technology equipment - Safety - Part1: general requirement...
- Page 30 Corporation. Specifications mentioned in this publication are subject to change without notice. This publication supersedes and replaces all information previously supplied.
- Page 31 www.nvidia.com...
