VARIABLE SPEED

JIG SAW
ELECTRIC SANDER
ELECTRIC SANDER
Part No. 6460200
MODEL No. CON300
Part No. 6462052
OPERATING & MAINTENANCE
INSTRUCTIONS
LS0610
1

Advertisement

Table of Contents
loading

Summary of Contents for Clarke CONTRACTOR CON300

  • Page 1: Variable Speed

    VARIABLE SPEED JIG SAW ELECTRIC SANDER ELECTRIC SANDER Part No. 6460200 MODEL No. CON300 Part No. 6462052 OPERATING & MAINTENANCE INSTRUCTIONS LS0610...
  • Page 3: Pack Contents

    Sound Power Level L 95.5 dB(A) ..........Please note that the details and specifications contained herein, are correct at the time of going to print. However, CLARKE International reserve the right to change specifications at any time without prior notice.
  • Page 4: Safety Precautions

    SAFETY PRECAUTIONS WARNING! As with all machinery, there are certain hazards involved with their operation and use. Exercising respect and caution will considerably lessen the risk of personal injury. However, if normal safety precautions are overlooked or ignored, personal injury to the operator or damage to property, may result.
  • Page 5: Dust Extraction

    15. ALWAYS use recommended accessories. The use of improper accessories could be hazardous. 16. ALWAYS remove plug from electrical outlet when adjusting, changing parts, or working on the machine. 17. NEVER operate machine while under the influence of drugs, alcohol or medication.
  • Page 6: Electrical Connections

    Should you wish to replace a detachable fuse carrier, ensure that the correct replacement is used (as indicated by marking or colour code). Replacement fuse covers can be obtained from your local Clarke dealer or most electrical stockists. FUSE RATING The fuse in the plug must be replaced with one of the same rating (5 amps) and this replacement must be ASTA approved to BS1362.
  • Page 7: Fitting The Sandpaper

    PREPARATION WARNING! Disconnect the plug from the power source before fitting/changing the sandpaper. FITTING THE SANDPAPER To fit the sandpaper, proceed as follows: Lift the clamp lever, see figure 1. Fig 1 Insert the end of the sandpaper Clamp and push the clamp lever down. Lever Fold the sandpaper around the vibrating plate, ensuring the...
  • Page 8: Operation

    OPERATION Connect the plug to the mains supply socket and switch on. Hold the sander firmly with both hands. OPERATING THE TRIGGER SWITCH WARNING! Never start the sander when it is in contact with the work piece. Hold the sander in mid air and Handle Lock-on Fig 3...
  • Page 9: Using The Sander

    Replace worn sanding sheets. The performance of your sander is dependant on the quality of the sanding sheets being used. Replacement sanding sheets are available from your CLARKE dealer (see page 13). Remove the sander from the work area before releasing the trigger.
  • Page 10: Maintenance

    • Check to make sure that the fuse has not blown, if it has, replace the fuse. If the fuse blows repeatedly, consult your CLARKE dealer. • If the fuse is OK and the machine still does not work, consult your CLARKE dealer.
  • Page 11: Parts Diagram

    PARTS DIAGRAM...
  • Page 12: Parts List

    PARTS LIST ACCESSORIES Accessories are available from your nearest CLARKE dealer, or via the CLARKE International Sales department on 01992 565 300. REPLACEMENT SANDING SHEETS Replacement sanding sheets are available from your CLARKE dealer. Please quote the following part numbers:...
  • Page 13: Declaration Of Conformity

    DECLARATION OF CONFORMITY When disposing of this product, ensure it is disposed of according to all local ordinances. It must not be disposed of with general household waste.
  • Page 14: Vibration Emissions

    VIBRATION EMISSIONS HAND-ARM VIBRATION Employers are advised to refer to the HSE publication “Guide for Employers”. All hand held power tools vibrate to some extent, and this vibration is transmitted to the operator via the handle, or hand used to steady the tool. Vibration from about 2 to 1500 hertz is potentially damaging and is most hazardous in the range from about 5 to 20 hertz.
  • Page 15 VIBRATION EMISSIONS The uncertainty factor should also be taken into account when assessing a risk. The two figures ‘ a ’ and ‘ K ’may be added together and the resultant value used to assess the risk. It should be noted that if a tool is used under abnormal, or unusual conditions, then the vibration level could possibly increase significantly.
