LG WM2688H*M Service Manual
Washing machine
Hide thumbs
Also See for WM2688H*M:
- Product & training manual (115 pages) ,
- Training manual (64 pages) ,
- Owner's manual (48 pages)
Table of Contents
Troubleshooting
Related Manuals for LG WM2688H*M
Summary of Contents for LG WM2688H*M
-
Page 1: Washing Machine
Website: http: //www.LGEservice.com E-mail: http: //www.LGEservice.com/techsup.html WASHING MACHINE SERVICE MANUAL CAUTION READ THIS MANUAL CAREFULLY TO DIAGNOSE PROBLEMS CORRECTLY BEFORE SERVICING THE UNIT. MODEL: WM2688H*M... - Page 2 DEC. 2005 PRINTED IN KOREA P/No.:3828ER3048Q...
-
Page 3: Table Of Contents
CONTENTS 1. SPECIFICATIONS .........................3 2. FEATURES & TECHNICAL EXPLANATION ................4 3. PARTS IDENTIFICATION ......................7 4. INSTALLATION & TEST ....................... 8 5. OPERATION ..........................11 6. WIRING DIAGRAM/PROGRAM CHART ..................14 7. TROUBLESHOOTING.........................15 7-1. BEFORE PERFORMING SERVICE ...................15 7-2. QC TEST MODE.........................15 7-3. -
Page 4: Specifications
1. SPECIFICATIONS ITEM WM2688H*M COLOR W:BLUE WHITE, N:NAVY BLUE POWER SUPPLY AC 120 V, 60 Hz PRODUCT WEIGHT 192 lbs (87kg) WASHING 280 W ELECTRIC POWER DRAIN MOTOR 80 W CONSUMTION WASH HEATER 1000 W WASH 46 rpm REVOLUTION SPEED... -
Page 5: Features & Technical Explanation
2. FEATURES & TECHNICAL EXPLANATION 2-1. FEATURES ■ Ultra Capacity The Larger drum enables not just higher head drop and stronger centrifugal force, but 추가선택 예약 also less tangling and wrinkling of the laundry. Heavier loads, such as king size comforters, blankets, and curtains, can be washed. -
Page 6: Water Level Control
2-2. NEURO FUZZY WASHING TIME OPTIMIZATION To get the best washing performance, optimal time is determined by the water temperature, the selected washing temperature, and the size of the load. water temperature washing time the best selected NEURO- washing washing rinsing time temperature FUZZY... -
Page 7: Water Circulation
2-5. THE DOOR CAN NOT BE OPENED While program is operating When a power failed and power plug is taken out in operation While Door Lock lights turn on. White the motor is in the process of intertial rotating, through the operation is paused. 2-6. -
Page 8: Parts Identification
3. PARTS IDENTIFICATION & Steam Nozzle Drum Light Door Seal Safety Cover (PLC Modem) ACCESSORIES... -
Page 9: Installation & Test
4. INSTALLATION & TEST Before servicing, ask the customer what the trouble is. Check the setup (power supply is 120 V AC, remove the transit bolts..). Check with the troubleshooting guide. Plan your service method by referring to the disassembly instructions. Service the unit. - Page 10 HOW TO CONNECT THE INLET HOSE Verify that the rubber washer is inside of the valve connector. Tighten the inlet hose securely to prevent leaks. CONNECT THE DRAIN HOSE Make sure that the hose is not twisted. Avoid submerging the end of the hose. The end of the drain hose should be placed less than 96”...
- Page 11 TEST OPERATION Preparation for Press the POWER button. Press the Start/Pause washing. button. Connect the power plug to Listen for a click to determine if the outlet. the door has locked. Connect the inlet hoses. Check the water heating Check the automatic Check the water supply.
-
Page 12: Operation
5. OPERATION ■ WM2688H*M... - Page 13 Power Button Status Indicator • It shows elapsed time of the cycle the washer is • Use this button to turn the power operating. On/Off. Start/Pause Cycle Selector Knob • Use this button to Start/ • Rotate the Cycle selector knob to select the cycle designed for Stop the washer.
-
Page 14: Option Button
Option Button • PREWASH: Use this option for loads that need pretreatment. It adds 16 minutes prewash and a spin cycle. • RINSE+SPIN: Use this option to rinse and then spin. • EXTRA RINSE: This option provides an additional rinse. •... -
Page 15: Wiring Diagram/Program Chart
6. WIRING DIAGRAM PROGRAM CHART DISPLAY PWB DISPLAY PWB 2 3 4 5 6 7 8 9 10 11 2 3 4 5 2 3 4 5 6 7 8 9 10 11 12 13 2 3 4 5 2 3 4 5 6 7 8 9 2 3 4 5 2 3 4 5... -
Page 16: Troubleshooting
QC TEST MODE... -
Page 17: Error Display
7-4. ERROR DISPLAY If you press the START/PAUSE button when an error is displayed, any error except will disappear and the machine will go into the pause status. In case of if the error is not resolved within 20 sec., or the in case of other errors, if the error is not resolved within 4 min., power will be turned off automatically and the error code will blink. - Page 18 ERROR SYMPTOM CAUSE • The connector (3-pin, male, white) in the MOTOR HARNESS is not connected to the connector (3-pin, female, white) of STATOR ASSEMBLY. • The electric contact between the connectors (3-pin, male, white) in the MOTOR HARNESS LOCKED and 4-pin, female, white connector in the MAIN PWB MOTOR ASSEMBLY is bad or unstable.
-
Page 19: Error Diagnosis And Check List
8. ERROR DIAGNOSIS AND CHECK LIST 8-1. DIAGNOSIS AND SOLUTION FOR ABNORMAL OPERATION SYMPTOM GUIDE FOR SERVICE CALL No power Is the power plug connected firmly to 120 V AC outlet? Power failure? or Breaker opened? Is the outlet controlled by a switch? Visit to service. - Page 20 SYMPTOM GUIDE FOR SERVICE CALL Door error Was the load too large? Visit to service. Drain trouble Visit to service.
- Page 21 SYMPTOM GUIDE FOR SERVICE CALL Suds overflow from the Is a HE (High Efficiency) detergent used? appliance. (In this condition, wash and spin do not operate normally) Is the proper amount of detergent used as recommended? Recommend to reduce the amount of detergent.
-
Page 22: Fault Diagnosis And Troubleshooting
8-2. FAULT DIAGNOSIS AND TROUBLESHOOTING CAUTION 1. Be careful of electric shock if disconnecting parts while troubleshooting. 2. First of all, check the connection of each electrical terminal with the wiring diagram. 3. If you replace the MAIN PWB ASSEMBLY, reinsert the connectors correctly. NO POWER Check the fuse or reset Is the supplied voltage 120 V AC? - Page 23 VIBRATION & NOISE IN SPIN Have all the transit bolts and base packing Remove the transit bolts been removed? and Base packing. Is the washer installed on a solidly constructed Move the washer or floor? reinforce the floor. Check if the washer is perfectly level as follows: ase Packing Level Check the leveling of the washer with a Level...
-
Page 24: No Water Supply
NO WATER SUPPLY WASH/RINSE SOIL LEVEL Steam Bleach DETERGENT DOES NOT FLOW IN Bleach Steam... -
Page 25: Abnormal Sound
LIQUID DETERGENT/SOFTENER/BLEACH DOES NOT FLOW IN Refer to Is water supplied? NO WATER SUPPLY Check the wiring on the Are the plugs correctly connected to the terminals of Bleach dispenser. the INLET VALVE ASSEMBLY? team Put it in the correct Is liquid detergent/softener/bleach put in the correct SOFTENER compartment. -
Page 26: Heating Without Water
HEATING WITHOUT WATER When pressing WASH/RINSE and SOIL LEVEL at the same time after draining, is the water level frequency Replace the 255? SENSOR SWITCH When pressing WASH/RINSE and SOIL LEVEL ASSEMBLY. buttons at the same time while washing, is the water level frequency between 230 - 243 ? Replace the MAIN PWB Check the voltage between two pins while pressing... - Page 27 WASH HEATER TROUBLE Replace the Heater Assembly HEATING CONTINUOUSLY ABOVE THE SETTING WATER TEMPERATURE SOIL LEVEL at the same time Extra Hot: 70 °C Water Temperature [°C] When checking the THERMISTOR on the tub, Push the THERMISTOR is the THERMISTOR loose? tightly to the rubber.
-
Page 28: Will Not Circulate Water
WILL NOT CIRCULATE WATER Is the impeller of the drain pump clogged? Remove foreign material. Hose onnector (Water circulation Hose & Steam Nozzle) Remove foreign material. Are the Hose Connector and/or Hose clogged? Reconnect or repair Is the connector disconnected, disassembled? the connector. -
Page 29: Spin Trouble
SPIN TROUBLE Check the SENSOR SWITCH ASSEMBLY or HOSE (Pressure). Check during spin if the frequency of the water If the problem is on the SENSOR level is 248 or more. SWITCH ASSEMBLY or the HOSE, replace the SENSOR SWITCH ASSEMBLY or the HOSE. -
Page 30: Disassembly Instructions
9. DISASSEMBLY INSTRUCTIONS Be sure to unplug the machine out of the outlet before disassembling and repairing the parts. CONTROL PANEL ASSEMBLY TOP PLATE ASSEMBLY Unscrew 2 screws on the back of the top plate. Pull the top plate backward and upward as shown. Disconnect the Display PWB Assembly connector from Trans cable. - Page 31 MAIN PWB ASSEMBLY Disconnect the POWER connector and SENSOR SWITCH ASSEMBLY. Remove the Protect Cover. PROTECT COVER Disconnect the connectors. Unscrew 1 screw on the back. Disassemble the Main PWB.
-
Page 32: Dispenser Assembly
DISPENSER ASSEMBLY Disassemble the top plate assembly. Pull out the drawer. Push out the DISPENSER ASSEMBLY after unscrew 2 screws. Unscrew the nut at the lower part of the dispenser. Disassemble the 4 connectors from the valves. Wire Color Blue Housing (YL-BK) Red Housing(VT-BK) White Housing(WH-BK) Blue Housing(GY-BK) - Page 33 CABINET COVER Unscrew the 5 screws from upper of the canbinet cover. Unscrew the screw from filter cover. Put a flat ( - ) screwdriver or putty knife into the both sides of the filter cover, and pull it out. Unscrew the screw from the lower side of the cabinet cover.
- Page 34 Open the door. Disassemble the clamp assembly. Tilt the cabinet cover. Disconnect the door switch connector. NOTE: When assembling the CABINET COVER, connect the connector. Lift and separate the cabinet cover. Disassemble the clamp assembly. Disassemble the Gasket.
-
Page 35: Door Lock Switch Assembly
DOOR Open the door. Unscrew the 7 screws from the HINGE COVER. Put a flat ( - ) screwdriver into the openng of the hinge, and pull out the hinge cover. Unscrew a screw from the lower side of door. Disassemble the door upward. - Page 36 Disassemble the cabinet cover. Separate the pump hose, the bellows and the circulation hose assembly from the pump assembly. Disassemble the pump assembly in arrow direction. Disassemble the cabinet cover. Separate 2 connectors from the heater. Loosen the nut and pull out the heater. CAUTION •...
- Page 37 Disassemble the cabinet cover. Separate the heater from the tub. Remove any foreign objects (wire, coin, etc.) by inserting a long bar in the opening. TOP PLATE ASSEMBLY Unscrew 2 screws on the back of the top plate. Pull the top plate backward and upward as shown. Disconnect the connector.
- Page 38 Disassemble the back cover. Remove the bolt. Pull out the Rotor. Unscrew the 2 screws from the tub bracket. Remove the 6 bolts on the stator. Unplug the 2 connectors from the stator. Disassemble the damper hinges from the tub and base.
- Page 39 To check out the fault diagnosis of TSG, in case of removing the water inside, you can pull out the plug and let the water drain away. Be cautious in case of the TSG is hot temperature. Remove the housing coupled the TSG (Heater, Water level frequency-sensor, Thermistor) Taking out the screw of the TSG and Body...
- Page 40 Taking out the screws of Body Frame (2EA) Separate the hoses from the TSG. Remove the Body Frame and then, separate the Body Frame TSG from the washer...
-
Page 41: Exploded View
10. EXPLODED VIEW 10-1. CABINET & CONTROL PANEL ASSEMBLY M400 M410 A105 A201 A220 A303... -
Page 42: Drum & Tub Assembly
10-2. DRUM & TUB ASSEMBLY K143 K123 K115 F466 K111 F315 F465 F463 K513 K122 F464 K125 K130 K121 K311 K512 K560 K135 K131 F328 K342 F467 K340 F468 K346 K344 K345 F145 K105... -
Page 43: Dispenser Assembly
10-3. DISPENSER ASSEMBLY F327 HOT (RED) COLD (BLUE)
