Hobart AC Generator/AC Welder Champion 4500 Specifications

PROCESSES
AC Stick (AC SMAW)
Welding
FEATURES
Generator power
Briggs & Stratton Intek engine
™
Versatile receptacle package
140 amp AC welder
Lightweight and rugged
Hobart's 5/3/1 Industrial Warranty
SPECIFICATIONS
(SUBJECT TO CHANGE WITHOUT NOTICE.)
Rated Output
140 A, 20 V at 30% duty cycle
110 A, 25 V at 60% duty cycle
90 A, 25 V at 100% duty cycle
Certified by Canadian Standards Association to both Canadian and U.S. Standards.
ENGINE SPECIFICATIONS
Engine Brand Model
1450 Intek
Briggs & Stratton*
*Engine warranted separately by manufacturer. 2-year consumer use, 1-year commercial use.
Hobart Welders
U.S. Distributor Sales
Hobart Retail Sales
Canadian Sales
International Sales
Champion
AC Generator/AC Welder
BENEFITS
4,500 watts surge power and 4,000 watts continuous power
Fuel-efficient engine with 1-gallon fuel tank
Unit features two 20 A 120 VAC and two 20 A 240 VAC receptacles with heavy-duty covers
Can handle AC stick electrodes up to 5/32 in diameter
Portable at 190 lb (86 kg) with rollbar frame built for added protection
Five-year warranty on transformers, stabilizers and generators; three years on electronics (drive motors, rectifiers);
and one year on guns (MIG and plasma torches)
Amperage Range Single-Phase Generator Power
60 – 140 A Single-phase, 4 kVA/kW, 120/240 VAC, 60 Hz
(SUBJECT TO CHANGE WITHOUT NOTICE.)
Displacement
™ Series
305 CC
An Illinois Tool Works Company
Phone 920-735-4576 FAX 800-637-2315
Phone 800-626-9420 FAX 800-424-1544
Phone 888-489-9353 FAX 519-421-0480
Phone 920-735-4509 FAX 920-735-4125
4500
™
Type
1 cylinder, 4-cycle, OHV air-cooled
Web Site HobartWelders.com
L ightweight and compact, Hobart's Champion
4500 welder/generator provides you with the
power you need wherever and whenever you need it.
This unit is an excellent source of generator power,
providing up to 4500 surge watts of AC power for
emergency backup, as well as hand tools, grinders,
lights and battery chargers. As an AC welder, the
Champion 4500 delivers up to 140 A of welding
power, making it an ideal choice for main tenance
and repair projects.
Comes Complete With:
10 ft (3 m) No. 4 electrode cable with holder
10 ft (3 m) work cable and clamp
Applications
Farm/Home
Light Maintenance and Repair
Light Fabrication
LIGHT INDUSTRIAL
Dimensions Net Weight
H: 20-3/4 in (527 mm) 190 lb (86 kg)
W: 22-3/4 in (577 mm)
D: 31-1/4 in (793 mm)
Start Ignition Fuel/Oil Capacity
Recoil Fuel: 1 gal (4 L) Oil: 28 oz (0.8 L)
213423
Jan. 2008
™
