INSTRUCTION MANUAL FOR
POWER GENERATOR PACKAGE
Part Number 283782
Rated for
28.5-V DC Input and
120-V AC, 60-Hz, 1600-Watt
Single-Phase Output
Optional Accessory for
Specification 6914G
Hobart Jet-Ex
28.5-V DC Generator Set
Hobart Brothers Company
Power Systems Group
Troy, Ohio 45373

Advertisement

loading

Summary of Contents for Hobart 283782

  • Page 1 TO-221 051592 INSTRUCTION MANUAL FOR POWER GENERATOR PACKAGE Part Number 283782 Rated for 28.5-V DC Input and 120-V AC, 60-Hz, 1600-Watt Single-Phase Output Optional Accessory for Specification 6914G Hobart Jet-Ex 28.5-V DC Generator Set Hobart Brothers Company Power Systems Group...
  • Page 2 This page intentionally left blank.
  • Page 3 The 120-V Power Generator Package covered by this manual, and identified by Hobart Part No. 283782, is an optional kit for use with Specification 6914G trailer-mounted ground power units. This power generator package mounts on the right rear side of the mounting frame between the wheels.
  • Page 4 TO-221 / Instruction Manual 120-V Power Generator Package - Part No. 283782 (5) Wide temperature range of operation The power generator will operate efficiently and safely at temperatures ranging between F (- 34 C) and 130 F (54 C) .
  • Page 5: Installation

    TO-221 / Instruction Manual 120-V Power Generator Package - Part No. 283782 2. Installation A Specification 6914G ground power unit may be ordered from the factory with the 120-V AC power generator package installed. Or, the power generator package may be purchased separately and installed in the field on a machine previously purchased.
  • Page 6 TO-221 / Instruction Manual 120-V Power Generator Package - Part No. 283782 a. Drill Holes for Mounting Generator and Generator Cover (1) Refer to Figure 3. Mark points for drilling holes on ground power unit as indicated in this diagram. Drill 5/16-inch holes at these points - a total of six holes.
  • Page 7 TO-221 / Instruction Manual 120-V Power Generator Package - Part No. 283782 (3) Place the generator in proper mounting position (as shown in Figure 2) , and make certain that holes in generator base and holes in the mounting bracket are lined up properly for inserting mounting screws.
  • Page 8 TO-221 / Instruction Manual 120-V Power Generator Package - Part No. 283782 Connecting Negative Power Generator Cable at Unit’s Output Terminal Panel Figure 4 3. Operation of the Power Generator Kit No special instructions are required for using the power generator kit, once input power is provided to the kit from the ground power unit.
  • Page 9: Parts Replacement

    12RT-662-11 b. Attaching Hardware The power generator kit, as received from Hobart Brothers, contains all hardware necessary for the initial mounting of the power generator package. In the event that it becomes necessary to replace items of hardware - such as after a repair is made - screws, nuts, and washers needed for mounting the generator package are available at most hardware stores.
  • Page 10: Service Information

    TO-221 / Instruction Manual 120-V Power Generator Package - Part No. 283782 5. Service Information If you have any questions concerning your Hobart Ground Power Division equipment, you are invited to contact our service department by mail, telephone, or FAX. Write:...
