  • Page 1 MX661 Digital Projector User Manual...

  • Page 2: Table Of Contents

    Displaying image through Q Presenter ..............57 Projector features........7 Using the projection login code..60 Shipping contents ........8 Projecting MX661 QPresenter App... 61 Projector exterior view......9 Presenting from a USB Reader.... 66 Positioning your Shutting down the projector ....69 projector .....

  • Page 3: Important Safety Instructions

    Important safety instructions Your projector is designed and tested to meet the latest standards for safety of information technology equipment. However, to ensure safe use of this product, it is important that you follow the instructions mentioned in this manual and marked on the product. Safety Instructions Please read this manual before Always open the lens shutter or...
  • Page 4 Safety Instructions (Continued) The lamp becomes extremely hot Do not place this product on an during operation. Allow the unstable cart, stand, or table. The projector to cool for approximately product may fall, sustaining serious 45 minutes prior to removing the damage.
  • Page 5 Safety Instructions (Continued) Do not place this projector in any of Do not block the ventilation holes. the following environments. - Do not place this projector on a blanket, bedding or any other soft surface. - Space that is poorly ventilated or - Do not cover this projector with a cloth confined.
  • Page 6 BenQ to have the projector serviced. Do not step on the projector or place any objects upon it. Besides probable...

  • Page 7: Introduction

    3D Function supported Various 3D formats make the 3D function more flexible. By presenting the depth of the images, you can wear BenQ 3D glassed to enjoy the 3D movies, videos and sporting events in a more realistic way. •...

  • Page 8: Shipping Contents

    Shipping contents Carefully unpack and verify that you have all of the items shown below. If any of these items are missing, please contact your place of purchase. Standard accessories The supplied accessories will be suitable for your region, and may differ from those illustrated. *The warranty card is only supplied in some specific regions.

  • Page 9: Projector Exterior View

    Projector exterior view External control panel Front/upper side (See "Projector" on page 10 details.) Lamp cover Zoom ring Focus ring Lens cover Vent (heated air exhaust) Speaker Front IR remote sensor Projection lens Audio output jack Microphone input jack Audio input jack S-Video input jack RGB (PC)/Component video (YPbPr/ YCbCr) signal input jack...

  • Page 10: Controls And Functions

    Controls and functions Projector Volume /Arrow keys ( Left, Right) Adjusts the sound level. When the On-Screen Display (OSD) menu is activated, the #7 and #9 keys are used as directional arrows to select the desired menu items and to make adjustments.
  • Page 11 If you intend to mount your projector on the ceiling, we strongly recommend that you use a proper fitting BenQ projector ceiling mount kit and that you ensure it is securely and safely installed. If you use a non-BenQ brand projector ceiling mount kit, there is a safety risk that the projector may fall from the ceiling due to an improper attachment through the use of the wrong gauge or length screws.

  • Page 12: Remote Control

    Remote control Eco Blank Press the Eco Blank button to turn off the image for a period of time with 70% lamp power saving. Press again to restore the image. See "Hiding the image" on page 41 for details. SmartEco Displays the lamp mode selection bar(Normal/Economic/SmartEco).
  • Page 13 14. Source 19. CC Displays the source selection bar. See Display the video term description on "Switching input signal" on page 32 screen which is provided for hard-of- details. hearing viewers. 15. Volume +/- 20. Test Adjusts the sound level. See "Adjusting Displays the test pattern.

  • Page 14: Replacing The Remote Control Battery

    Replacing the remote control battery To open the battery cover, turn the remote control over to view its back, push on the finger grip on the cover and slide it up in the direction of the arrow as illustrated. The cover will slide off. Remove any existing batteries (if necessary) and install two AAA batteries observing the battery polarities as indicated in the base of the battery compartment.

  • Page 15: Positioning Your Projector

    Rear Ceiling Select this location with the projector suspended upside- down from the ceiling behind the screen. Note that a special rear projection screen and the BenQ Projector Ceiling Mounting Kit are required for this installation location. Set Rear Ceiling in the SYSTEM SETUP: Basic >...

  • Page 16: Obtaining A Preferred Projected Image Size

    All measurements are approximate and may vary from the actual sizes. BenQ recommends that if you intend to permanently install the projector, you should physically test the projection size and distance using the actual projector in situ before you permanently install it, so as to make allowance for this projector's optical characteristics.

  • Page 17: Connection

    Connection When connecting a signal source to the projector, be sure to: Turn all equipment off before making any connections. Use the correct signal cables for each source. Ensure the cables are firmly inserted. • In the connections shown below, some cables may not be included with the projector (see "Shipping contents"...
  • Page 18 Computer system requirements for USB display Windows OS: Dual Core 2 GHz or higher (ATOM not supported) Graphic card Intel, nVIDIA or ATI graphic card with 64MB VRAM or above Operating system Windows XP SP3, Vista SP2, Windows 7 SPI and later USB 2.0 High Speed * Audio will not be supported on XP.

  • Page 19: Connecting A Computer Or Monitor

    Take a USB mini-B type to USB A type cable and connect one end to the A type jack of the computer. Connect the other end of the cable to the MINI-B jack on the projector. Go to "My Computer", find “MX661 QPresenter” and double click autorun.exe file to install the USB driver and start to presentation. •...
  • Page 20 signal from MONITOR-OUT jack varies depending on the input signal from COMPUTER IN-1 or COMPUTER IN-2 jack. • If you wish to use this connection method when the projector is in standby mode, make sure the Monitor Out function is turned on in the SYSTEM SETUP: Advanced > Standby Settings menu.

  • Page 21: Connecting Video Source Devices

    Connecting Video source devices You need only connect the projector to a Video source device using just one of the above connecting methods, however each provides a different level of video quality. The method you choose will most likely depend upon the availability of matching terminals on both the projector and the Video source device as described below: Terminal Terminal appearance...
  • Page 22 Connecting a HDMI source device The projector provides a HDMI input jack that allows you to connect it to a HDMI source device like a DVD player, a DTV tuner or a display. HDMI (High-Definition Multimedia Interface) supports uncompressed video data transmission between compatible devices like DTV tuners, DVD players and displays over a single cable.

  • Page 23: Connecting A Component Video Source Device

    Connecting a Component Video source device Examine your Video source device to determine if it has a set of unused Component Video output jacks available: • If so, you can continue with this procedure. • If not, you will need to reassess which method you can use to connect to the device. To connect the projector to a Component Video source device: Take a Component Video to VGA (D-Sub) adaptor cable and connect the end with 3 RCA type connectors to the Component Video output jacks of the Video source...

  • Page 24: Connecting An S-Video/Composite Source Device

    Connecting an S-Video/composite source device Examine your Video source device to determine if it has an unused S-Video/composite output jack available: • If it has both jacks, use the S-Video output jack for connection as the S-Video terminal provides better picture quality than the Video terminal. •...

  • Page 25: Operation

    Operation Starting up the projector Plug the power cord into the projector and into a power outlet. Turn on the power outlet switch (where fitted). Check that the POWER indicator light on the projector lights orange after power has been applied. •...

  • Page 26: Adjusting The Projected Image

    If the projector is activated for the first time, select your OSD language following the on- screen instructions. If you are prompted for a password, press the arrow keys to enter a six digit password. See "Utilizing the password function" on page 30 for details.
  • Page 27 Auto-adjusting the image In some cases, you may need to optimize the picture quality. To do this, press AUTO on the projector or remote control. Within 3 seconds, the built-in Intelligent Auto Adjustment function will re-adjust the values of Frequency and Clock to provide the best picture quality.

  • Page 28: Correcting Keystone

    Fine-tuning the image size and clarity Adjust the projected image to the size that you need using the zoom ring. Then sharpen the image by rotating the focus ring. Correcting keystone Keystoning refers to the situation where the projected image is noticeably wider at either the top or bottom.

  • Page 29: Using The Menus

    Using the menus The projector is equipped with On-Screen Display (OSD) menus for making various adjustments and settings. Below is the overview of the OSD menu. Main menu icon Main menu Highlight Status Sub-menu Press MENU/ EXIT to the previous page or to exit.

  • Page 30: Securing The Projector

    Securing the projector Using a security cable lock The projector has to be installed in a safe place to prevent theft. Otherwise, purchase a lock, such as the Kensington lock, to secure the projector. You can locate a Kensington lock slot on the rear side of the projector. See item 22 on page for details.

  • Page 31: If You Forget The Password

    Write down the number and turn off your projector. Seek help from the local BenQ service center to decode the number. You may be required to provide proof of purchase documentation to verify that you are an authorized user of the projector.

  • Page 32: Switching Input Signal

    You have successfully assigned a new password to the projector. Remember to enter the new password next time the projector is started. To leave the OSD menu, press MENU/EXIT. Disabling the password function To disable password protection, go back to the SYSTEM SETUP: Advanced > Security Settings >...

  • Page 33: Magnifying And Searching For Details

    • The input signal type effects the options available for the Picture Mode. See "Selecting a picture mode" on page 35 for details. • For best display picture results, you should select and use an input signal which outputs at this resolution.

  • Page 34: Selecting The Aspect Ratio

    The picture can only be navigated after the picture is magnified. You can further magnify the picture while searching for details. Selecting the aspect ratio The 'aspect ratio' is the ratio of the image width to the image height. Most analog TV and computers are in 4:3 ratio,and digital TV and DVDs are usually in 16:9 or 16:10 ratio.

  • Page 35: Optimizing The Image

    Optimizing the image Selecting a picture mode The projector is preset with several predefined picture modes so that you can choose one to suit your operating environment and input signal picture type. To select an operation mode that suits your need, you can follow one of the following steps.

  • Page 36: Using Wall Color

    Using Wall Color In the situation where you are projecting onto a colored surface such as a painted wall which may not be white, the Wall Color feature can help correct the projected picture’s color to prevent possible color difference between the source and projected pictures. To use this function, go to the DISPLAY >...

  • Page 37: Setting A Preferred Color Temperature

    *About color temperatures: There are many different shades that are considered to be "white" for various purposes. One of the common methods of representing white color is known as the “color temperature”. A white color with a low color temperature appears to be reddish white. A white color with a high color temperature appears to have more blue in it.
  • Page 38 Please refer to the illustration to the right for how the colors relate to each other. For example, if you select Red and set its Yellow range at 0, only pure red in the projected GREEN picture will be selected. Increasing its range will include red close to yellow and red close to magenta.

  • Page 39: Setting The Presentation Timer

    Setting the presentation timer The presentation timer can indicate the presentation time on the screen to help you achieve better time management when giving presentations. Follow these steps to utilize this function: Press Timer Set up on the remote control or go to the SYSTEM SETUP: Basic >...

  • Page 40: Remote Paging Operations

    SYSTEM SETUP: Basic Go to the > Presentation Timer menu and highlight Off. Press MODE/ENTER. A confirmation message displays. Highlight Yes and press MODE/ENTER to confirm. You will see the message “Timer is Off!” displaying on the screen. How to use the Timer On key? Timer On is a multi-functional key.

  • Page 41: Hiding The Image

    Hiding the image Press the Eco Blank button from projector or remote control to turn off the image for a period of time with up to 70% lamp power saving. Press any key on the projector or remote control to restore the image. The word "Eco Blank"...

  • Page 42: Operating In A High Altitude Environment

    Operating in a high altitude environment We recommend you use the High Altitude Mode when your environment is 1500 m – 3000 m above sea level, and ambient temperature is between 0°C–35°C. China region only applies at altitude up to 2000m. Do not use the High Altitude Mode if your altitude is between 0 m and 1500 m and ambient temperature is between 0°C and 35°C.

  • Page 43: Personalizing The Projector Menu Display

    Turning off the Power on/off ring tone To turn off the ring tone: Repeat steps 1-2 in Muting the sound section. Highlight Power on/off Ring Tone and select Off. The only way to change Power on/off ring tone is setting On or Off here. Setting the sound mute or changing the sound level will not affect the Power on/off ring tone.

  • Page 44: Use Teaching Template

    Use teaching template Making writing on the board easier for teachers, you can use build-in template by OSD or remote control. Open the OSD menu and go to the DISPLAY > Teaching Template . Choose Blackboard/ Whiteboard > Off/ Letter Formation/ Worksheet/ Coordinate Chart.

  • Page 45: Select The Lamp Saver Mode

    Select the lamp saver mode • Using the remote control. Press SmartEco and Highlight Lamp Mode and press to select Normal/ Economic/SmartEco. • Using the OSD menu. Press MENU/EXIT and then press until the SYSTEM SETUP: Advanced menu is highlighted. Press to highlight Lamp Mode and press MODE/ENTER.

  • Page 46: Controlling The Projector Through A Lan Environment

    Controlling the projector through a LAN environment Network Settings allow you to manage the projector from a computer using a web browser when the computer and the projector are properly connected to the same local area network. Wired connection Internet IP Router If you are in a DHCP environment: Take a RJ45 cable and connect one end to the LAN input jack of the projector and...

  • Page 47: Wireless Connection

    Wireless connection BenQ wireless dongle Connect the BenQ wireless dongle (optional) to the TYPE-A input jack of the projector. Highlight Wireless LAN in SYSTEM SETUP: Advanced > Network Settings menu and press MODE/ENTER. Make sure the Status is Connect. Make sure the SSID information is displayed.
  • Page 48 Enter the address of the projector in the address bar of your browser and press Enter. For example: http://192.168.111.11 The BenQ remote network operation page opens. • The web page control supports IE version 7.0 or higher.
  • Page 49 Click Download to save Q Presenter software on your computer. You can also link to the web page control from Q Presenter > Settings > Control projector via web page on page 60. Execute the program installation. Open Q Presenter, search and connect a network display. See "Displaying image through Q Presenter"...
  • Page 50 The Display Setting page allows you to operate the projector as if you were using the OSD menus. These functions are some useful menu settings. The Picture Setting page allows you to manage the projector as if you were using the PICTURE menu.
  • Page 51 The Information page displays the information and status of this projector. The Conference Control page allows you to control computer’s display status of all the computers linked to this projector. The Crestron page is only available when you are on a Wired LAN network. It also allows you to control the projector remotely.
  • Page 52 i. These buttons function the same as the ones on the OSD menus or remote control. See "2. PICTURE" on page 71 "Remote control" on page 14 details. The Menu button can also be used to go back to previous OSD menu, exit and save menu settings.
  • Page 53 The tools page allows you to manage the projector, configure the LAN control settings and secure access of remote network operation on this projector. i. You can name the projector, keep track of its location and the person in charge of it.
  • Page 54 The info page displays the information and status of this projector. i. Press exit to go back to the Crestron remote network operation page. The Admin page allows you to enter Basic, Wired LAN, Wireless LAN and Mail pages once the password is entered. The default password is “0000”. If you want to change the password, please enter Basic page.
  • Page 55 The Basic page allows you to change the password and select connected persons. The number of connected persons may affect the network display performance. The Wired LAN page allows you to adjust the Wired LAN settings. Operation 55...
  • Page 56 The Mail page allows you to send alert e-mail to your ITS administrator. You can first try the Mail Test function to check if the Alert Mail works. Operation...

  • Page 57: Displaying Image Through Q Presenter

    Displaying image through Q Presenter The Q Presenter is an application running on the host PC. It connects to an available network display and transfers the desktop contents to the network display via local network connection. Be sure to turn off other virtual network control programs before using Q Presenter. Connect the projector with the RJ45 cable, and make sure your laptop or computer also link to the LAN.
  • Page 58 MAC version i. You can key in the IP address (see "Controlling the projector remotely through a web browser" on page 48 for details.) to connect the network directly or click “Search” to find the search results. You can activate audio streaming. MAC version is by keypad. iii.
  • Page 59 MAC version i. You can choose mirror or extension diplay your contents. ii. You can select to Play/Pause displaying desktop contents to connected network display. iii. 4-1 Display (up to 4 computers can shoot to 1 projector at the same time). Click the location you want to display.

  • Page 60: Using The Projection Login Code

    If your language isn’t included, the system will keep English as the default setting. v. You can link to the BenQ remote network operation page on page 48. Using the projection login code This function is designed to ensure network display through the correct projector. To toggle this function: Go to the SYSTEM SETUP: Advanced >...

  • Page 61: Projecting Mx661 Qpresenter App

    Projecting MX661 QPresenter App MX661 QPresenter is an easy-to-use app which enables your mobile devices to project the display to projector. You can remote control it through Wi-Fi network, and display your photos. Furthermore, it can also display the web browser content.
  • Page 62 iPad screen iPhone screen i. Projector List displays SSID and IP Address. Find the projector SSID to connect with it directly. If projection login code pop-up message Projector Login Code displays, enter the 4-digit Cancel code in the upper right corner of the Network page.
  • Page 63 Files page lets you to project Documents, Photos, and supports Dropbox on your iPad/iPhone. Documents features with Edit, Jump to page and Sketch functions. iPad screen iPhone screen i. Edit function lets you can delete documents on your iPad/iPhone ii. Jump to page function lets you to select the page directly. iii.
  • Page 64 Choose the Wi-Fi network which the projector connect to from the AP list (1). Enter the password (2) (3) and wait for projection (4). Network - Client Mode Network - Client Mode ID : benq Refresh Password : james-home 12345678901234567890123456 123456789012345678901234...
  • Page 65 iPad screen iPhone screen Web Browser lets you to display web page through Google internet search. Web Browser only can work under client mode. iPad screen iPhone screen Cam lets you to take and save photos in camera roll. iPad screen iPhone screen Operation 65...

  • Page 66: Presenting From A Usb Reader

    Presenting from a USB Reader This fature displays a slide show of images stored on a USB flash drive connected to the projector. It can eliminate the need for a computer source. To display files: Turn on the power of the projector and the projector displays the home screen. Cnnect the projector to one of the above external memory devices.
  • Page 67 File playing Videos Music Photos NAME DESCRIPTION Go to the previous file. Previous Play or pause file. Play/pause Go to the next file. Next Shuffle play Play type Rotate screen Rotation Go back to the upper level. Back Go back to file browser. Home Operation 67...
  • Page 68 Documents NAME DESCRIPTION While page is not zoomed. • Up/Left: Move to the previous page. Down • Down/Right: Move to the next page. Left While page is zoomed. • Up: Move to the top side of the page. • Left: Move to the left side of the page. Right •...

  • Page 69: Shutting Down The Projector

    Shutting down the projector Press POWER and a confirmation message displays prompting you. If you don't respond in a few seconds, the message will disappear. Press POWER a second time. The POWER indicator light flashes orange, the projection lamp shuts down, and the fans will continue to run for approximately 90 seconds to cool down the projector.

  • Page 70: Menu Operation

    Menu operation Menu system Please note that the on-screen display (OSD) menus vary according to the signal type selected. Main menu Sub-menu Options Off/Light Yellow/Pink/Light Green/ Wall Color Blue/Blackboard Aspect Ratio Auto/Real/4:3/16:9/16:10 Keystone Position Phase H. Size Digital Zoom DISPLAY Auto/Top Bottom/Frame sequential/ 3D mode Frame packing/Side by side/Off...
  • Page 71 Instant Restart On/Off Disable/5 mins/10 mins/15 mins/ Blank Timer 20 mins/25 mins/30 mins Disable/30 mins/1 hr/2 hrs/3 hrs/ Sleep Timer 4 hrs/8 hrs/12 hrs Fan Speed Normal/High Panel Key Lock On/Off Yes/No Background Color BenQ/Black/Blue/Purple Splash Screen BenQ/Black/Blue Operation 71...
  • Page 72 High Altitude On/Off Yes/No Mode Mute On/Off Volume Audio Settings Microphone Volume Power on/off Ring Tone On/Off Lamp Mode Normal/Economic/SmartEco Lamp Settings Reset Lamp Timer Reset/Cancel Equivalent Lamp Hour Change Password Security Settings Change Security Power on lock 2400/4800/9600/14400/19200/ Baud Rate 38400/57600/115200 Test Pattern On/Off...
  • Page 73 Note that the menu items are available when the projector detects at least one valid signal. If there is no equipment connected to the projector or no signal detected, limited menu items are accessible. Operation 73...

  • Page 74: Description Of Each Menu

    Description of each menu • The default values listed in this manual, especially on pages 74-83, are for reference only. They may vary between the projectors due to the continuous improvement to the products. FUNCTION DESCRIPTION Corrects the projected picture’s color when the projection surface is Wall Color not white.
  • Page 75 FUNCTION DESCRIPTION This projector features a 3D function which enables you to enjoy the 3D movies, videos, and sporting events in a more realistic way by presenting the depth of the images. You need to wear a pair of 3D glasses to view the 3D images.
  • Page 76 FUNCTION DESCRIPTION Pre-defined picture modes are provided so you can optimize your Picture Mode projector image set-up to suit your program type. See "Selecting a picture mode" on page 35 for details. Selects a picture mode that best suits your need for the image quality Reference and further fine-tune the image based on the selections listed on the same page below.
  • Page 77 FUNCTION DESCRIPTION "Adjusting Brilliant Color" on page 36 for details. Brilliant Color "Selecting a Color Temperature" on page 36 for details. Color Temperature "Setting a preferred color temperature" on page 37 for details. Color Temperature Fine Tuning 3D Color "3D Color Management" on page 37 for details.
  • Page 78 FUNCTION DESCRIPTION Reminds the presenter to finish the presentation within a certain Presentation time frame. See "Setting the presentation timer" on page 39 Timer details. Sets the language for the On-Screen Display (OSD) menus. See Language "Using the menus" on page 29 for details.

  • Page 79: Sleep Timer

    Lock Allows you to select which background color will display when no Background signal is input into the projector. Four options are available: BenQ Color logo, Black, Blue, or Purple. Allows you to select which logo screen will display during projector Splash Screen start-up.
  • Page 80 FUNCTION DESCRIPTION A mode for operation in high altitude areas. See "Operating in a high High Altitude altitude environment" on page 42 for details. Mode Allows you to enter the audio setting menu. Mute Sets the mute function. Volume Audio Adjusts the audio volume level.

  • Page 81: Monitor Out

    FUNCTION DESCRIPTION Closed Caption Enable Activates the function by selecting On when the selected input signal carries closed captions. • Captions: An on-screen display of the dialogue, narration, and Closed sound effects of TV programs and videos that are closed Caption captioned (usually marked as "CC"...

  • Page 82: Wired Lan

    FUNCTION DESCRIPTION Wired LAN "Controlling the projector through a LAN environment" on page for details. Wireless LAN "Controlling the projector through a LAN environment" on page for details. Network Projection Log in code Settings "Using the projection login code" on page 60 for details.
  • Page 83 FUNCTION DESCRIPTION Source Shows the current signal source. Picture Mode Shows the selected mode in the PICTURE menu. Resolution Shows the native resolution of the input signal. Lamp Mode Current Shows the current lamp mode. System 3D Format Status Shows the current 3D mode. Color System Shows input system format, NTSC, PAL, SECAM, or RGB.

  • Page 84: Maintenance

    Maintenance Care of the projector Your projector needs little maintenance. The only thing you need to do on a regular basis is to keep the lens and case clean. Never remove any parts of the projector except the lamp. Contact your dealer if other parts need replacing.

  • Page 85: Lamp Information

    Lamp information Getting to know the lamp hour When the projector is in operation, the duration (in hours) of lamp usage is automatically calculated by the built-in timer. The method of calculating the equivalent lamp hour is as follows: Total (equivalent) lamp hour = 1 (hours used in Economic mode) + 4/3 (hours used in normal mode) "Setting Lamp Mode eco function as Economic or SmartEco mode"...
  • Page 86 presentation, select Disable. The projector will not automatically shut down in a certain time period. Maintenance...

  • Page 87: Timing Of Replacing The Lamp

    Timing of replacing the lamp When the Lamp indicator lights up red or a message appears suggesting it is time to replace the lamp, please install a new lamp or consult your dealer. An old lamp may cause a malfunction in the projector and in some instances the lamp may explode. Do not attempt to replace the lamp yourself.

  • Page 88: Replacing The Lamp

    • To assure optimal performance from the projector, it is recommended that you purchase a BenQ projector lamp for lamp replacement. • Ensure good ventilation when handling broken lamps. We recommend that you use respirators, safety glasses, goggles or face shield and wear protective clothing such as gloves.
  • Page 89 Remove the lamp cover by (a) sliding the cover toward the side of the projector and (b) lifting it off. • Do not turn the power on with the lamp cover removed. • Do not insert your fingers between the lamp and the projector.

  • Page 90: Resetting The Lamp Timer

    Tighten the screws that secure the lamp. • Loose screw may cause a bad connection, which could result in malfunction. • Do not over tighten the screws. Ensure the handle is fully laid flat and locked in place. Replace the lamp cover by sliding it into place.
  • Page 91 Indicators Light Status & Description POWER TEMP LAMP System messages Stand-by mode Orange Green Powering up Flashing Normal operation Green Orange Normal power-down cooling Flashing Download CW start fail Green Scaler shutdown fail (data abord) Flashing Scaler reset fail (video projector only) LAN download fail LAN download processing Green...
  • Page 92 Green Thermal Sensor 2 short error Green Flashing Green Green Thermal IC #2 I2C Connection error Flashing Flashing Maintenance...

  • Page 93: Troubleshooting

    Troubleshooting The projector does not turn on. Cause Remedy Plug the power cord into the AC inlet on the projector, and plug the power cord into the There is no power from the power cable. power outlet. If the power outlet has a switch, make sure that it is switched on.

  • Page 94: Specifications

    Specifications All specifications are subject to change without notice. Optical Input terminals Resolution Computer input 1024 x 768 XGA RGB input Display system D-Sub 15-pin (female) x 2 1-CHIP DMD Video signal input Lens F/Number S-VIDEO F = 2.51 to 2.69, Mini DIN 4-pin port x 1 f = 21.95 to 24.18 mm VIDEO...

  • Page 95: Dimensions

    Dimensions 326.5 mm (W) x 126.0 mm (H) x 230.1 mm (D) 326.5 230.1 126.0 77.1 74.1 Ceiling mount installation Ceiling mount screws: Unit: mm M4 x 8 (Max. L = 8 mm) 84.0 149.5 65.5 14.0 242.0 537.9 21.1 81.2 87.5 112.2...

  • Page 96: Timing Chart

    84.997 68.667 94.500 XGA_120** 119.989 97.551 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1024 x 576 BenQ Notebook_ 60.0 35.820 46.966 timing 1024 x 600 BenQ Notebook_ 64.995 41.467 51.419 timing 1280 x 720 1280 x 720_60* 45.000...
  • Page 97 115.5 (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1280 x 768 1280 x 768_60* 59.87 47.776 79.5 1024 x 576@60Hz BenQ Notebook_ 60.00 35.820 46.996 timing 1024 x 600@65Hz BenQ Notebook_ 64.995 41.467 51.419 timing 1280 x 720 1280 x 720_60 45.000...
  • Page 98 • The timings showing above may not be supported due to EDID file and VGA graphic card limitations. It is possible that some timings cannot be chosen. Timing Resolution Vertical Horizontal Pixel Remark Frequency Frequency Frequency (Hz) (kHz) (MHz) 480i* 720 x 480 59.94 15.73...
  • Page 99 Supported timing for Component-YPbPr input Timing Resolution Vertical Horizontal Pixel Frequency Frequency Frequency (Hz) (kHz) (MHz) 480i* 720 x 480 59.94 15.73 13.5 480p 720 x 480 59.94 31.47 576i 720 x 576 15.63 13.5 576p 720 x 576 31.25 720/50p 1280 x 720 37.5...
  • Page 100 XGA_85 84.997 68.667 XGA_120 119.989 97.551 ◎ (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1024 x 576 BenQ Notebook 35.82 Timing 1024 x 600 BenQ Notebook 64.995 41.467 Timing 1280 x 720 1280 x 720_60 ◎ ◎ ◎...
  • Page 101 ◎ XGA_70 70.069 56.476 XGA_75 75.029 60.023 XGA_85 84.997 68.667 XGA_120 119.989 97.551 ◎ (Reduce Blanking) 1152 x 864 1152 x 864_75 67.5 1024 x 576 BenQ Notebook 35.82 Timing 1024 x 600 BenQ Notebook 64.995 41.467 Timing Specifications 101...

  • Page 102: Video Mode

    1280 x 720 1280 x 720_60 ◎ ◎ ◎ 1280 x 720_120 ◎ 1280 x 768 1280 x 768_60 47.396 ◎ ◎ ◎ (Reduce Blanking) 1280 x 768_60 59.87 47.776 ◎ ◎ ◎ 1280 x 800 WXGA_60 59.81 49.702 ◎ ◎...

  • Page 103: Warranty And Copyright Information

    Proof of purchase date will be required with any warranty claim. In the event this product is found to be defective within the warranty period, BenQ's only obligation and your exclusive remedy shall be replacement of any defective parts (labor included). To obtain warranty service, immediately notify the dealer from which you purchased the product of any defects.

  • Page 104: Regulatory Statements

    Regulatory Statements Battery Caution (if product includes remote control) Do not put the remote control in the direct heat, humidity & Avoid fire. Do not drop the remote control. Do not expose the remote control to water or moisture, this could result in malfunction. Confirm there is no object between the remote control and the remote sensor of the product.
  • Page 105 statement (for the United States only) CLASS B: This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures: —...
  • Page 106 All BenQ monitors and projectors come with user manuals on compact discs which could be easily read by commercial software such as Adobe Reader via a connected computer system. These documents are also available on the BenQ's web site (www.BenQ.com).
  • Page 107 If the plug has a detachable fuse cover, remember to place the fuse cover back if you need to change the fuse. Do NOT use a plug without the fuse cover. If the fuse cover is missing, contact your nearest BenQ Customer Service Center for assistance.
  • Page 108 CE DOC English DECLARATION OF CONFORMITY The device complies with the requirements set out in the Council Directives on the Approximation of the Laws of the Member States relating Electromagnetic Compatibility (2004/108/EC) and Low Voltage Directive (2006/95/EC) and Radio and Telecommunications Terminal Equipment Directive (1999/5/EC), the Restriction of The Use of Certain Hazardous Substances in Electrical And Electronic Equipment Directive (2011/65/EU), Turkish EEE Directive;...
  • Page 109 Deutsch KONFORMITÄTSERKLÄRUNG Dieses Gerät erfüllt die Voraussetzungen, welche in den Richtlinien zur Angleichung der Rechtsvorschriften der Mitgliedstaaten in Bezug auf elektromagnetische Kompatibilität (2004/108/EC), Niederspannungsrichtlinie (2006/95/EC), Richtlinie für Funkanlagen und Telekommunikations-Endeinrichtungen (1999/95/EC), Beschränkung der Verwendung bestimmter gefährlicher Stoffe in Elektro- und Elektronikgeräten (2011/65/EU), Türkische EEE-Direktive, Kommissionreglementierung (EC) Nr.
  • Page 110 Svenska KONFORMITETSDEKLARATION Denna enhet uppfyller kraven i rådets direktiv om tillnärmning av medlemsstaternas lagstiftning om elektromagnetisk kompatibilitet (2004/108/EG) och lågspänningsdirektiv (2006/95/EG) och direktivet om radioutrustning och teleterminalutrustning (1999/5/EC), begränsning av användningen av vissa farliga ämnen i elektriska och elektroniska produkter (2011/65/EU), turkiskt EEE-direktiv, kommissionsbestämmelse (EG) nr. 1275/2008 med implementering av direktiv 2005/32/EG i Europaparlamentet och rådet för att fastställa krav...
  • Page 111 eština PROHLÁŠENÍ O SHOD Toto za ízení odpovídá požadavk m stanoveným ve sm rnici Rady o sbližování právních p edpis lenských stát týkajících se elektromagnetické kompatibility (2004/108/ES), ve sm rnici týkající se nízkonap ových za ízení (2006/95/ES), ve sm rnici o rádiových za ízeních a telekomunika ních koncových za ízeních (1999/5/ES), ve sm rnici o omezení...
  • Page 112 Magyar MEGFELEL SÉGI NYILATKOZAT Az eszköz megfelel a Bizottság tagállamainak harmonizált jogszabályainak az elektromágneses kompatibilitás (2004/108/EK) és a kisfeszültség direktíva (2006/95/EK), a rádiófrekvenciás és telekommunikációs végberendezések direktíva (1999/5/EK), továbbá az elektromos eszközök egyes veszélyesanyag-felhasználását korlátozó direktíva (2011/65/EU), a török EEE direktíva, a 1275/2008 sz. Bizottsági szabályozás (EK) (amely az Európai Parlament és a Bizottság 2005/32/EK sz.
  • Page 113 Român DECLARA IE DE CONFORMITATE Acest dispozitiv este în conformitate cu prevederile stabilite prin Directivele Consiliului privind apropierea legisla iilor statelor membre cu privire la compatibilitatea electromagnetic (2004/108/CE) i Directiva privind joasa tensiune (2006/95/CE) i Directiva privind echipamentele hertziene i echipamentele terminale de telecomunica ii (1999/5/CE), Directiva de Restric ie a Utiliz rii Anumitor Substan e Periculoase în Echipamentele Electrice i Electronice (2011/65/UE), Directive EEE pentru Turcia, Regulamentul Comisiei (EC) Nr.
  • Page 114 Finnish VAATIMUSTENMUKAISUUSVAKUUTUS Laite täyttää sähkömagneettista yhteensopivuutta koskevan EMC-direktiivin (2004/108/EY), pienjännitedirektiivin (2006/95/EY), radio- ja telepäätelaitedirektiivin (1999/5/EY) ja vaarallisten aineiden käytön rajoittamista sähkö- ja elektroniikkalaitteissa koskevan direktiivin (2011/65/EU), turkkilaisen EEE-direktiivin; komission asetuksen (EY) N:o 1275/2008 direktiivin 2005/32/EY täytäntöönpanosta kotitalouksissa ja toimistoissa käytettävien sähkö- ja elektroniikkalaitteiden lepovirtakulutuksen ekologista suunnittelua koskevien vaatimusten osalta sekä...

  • Page 115: Weee Directive

    Battery manner that protects human health and environment. Recycling information: See http://www.benq.com/support/recycle for details. Français Directive DEEE Mise au rebut des déchets d’équipements électriques et électroniques et/ou des piles par les particuliers dans l’Union Européenne.

  • Page 116: Directiva Weee

    Al reciclar materiales ayudamos a conservar el medio natural y a garantizar el reciclaje de manera que proteja la salud y el medioambiente. Batería Recycling information: See http://www.benq.com/support/recycle for details. Deutsch WEEE-Richtlinie Entsorgung von Elektro- und Elektronikgeräten bzw. Batterien in Privathaushalten der Europäischen Union.
  • Page 117 Pycc WEEE WEEE Recycling information: See http://www.benq.com/support/recycle for details. Svenska WEEE-direktiv Riktlinjer för kassering av avfall som utgörs av eller innehåller elektriska eller elektroniska produkter och/eller batteri, gällande hushåll i EU. Den här symbolen kan finnas på produkten eller på förpackningen och betyder att produkten inte kan kasseras som vanligt hushållsavfall.
  • Page 118 Recycling information: See http://www.benq.com/support/recycle for details. Polski Dyrektywa WEEE Utylizacja odpadów z urz dze elektrycznych i elektronicznych lub baterii przez u ytkowników prywatnych w Unii Europejskiej. Ten symbol na urz dzeniu lub opakowaniu oznacza, e nie mo e by ono utylizowane razem z odpadami domowymi.
  • Page 119 Recycling information: See http://www.benq.com/support/recycle for details. Português Directiva REE Eliminação de Resíduos de Equipamentos Eléctricos e Electrónicos e/ou Baterias por particulares na União Europeia. Este símbolo no produto ou na embalagem indica que não pode ser eliminado como lixo doméstico. Deverá eliminar os resíduos dos seus equipamentos e/ou baterias entregando-os nos pontos de recolha aplicáveis para reciclagem de equipamentos de...
  • Page 120 WEEE WEEE Recycling information: See http://www.benq.com/support/recycle for details. Hrvatski WEEE direktiva Odlaganje u otpad elektri nih i elektroni kih ure aja i/ili baterija iz ku anstava u Europskoj uniji. Ovaj simbol na proizvodu ili pakiranju nazna uje da se ovaj proizvod ne može odbaciti s ku nim otpadom.
  • Page 121 Reciclarea acestor materiale va ajuta la p strarea resurselor naturale i asigur c Baterie sunt reciclate într-o modalitate care protejeaz via a i mediul oamenilor. Recycling information: See http://www.benq.com/support/recycle for details. WEEE WEEE Recycling information: See http://www.benq.com/support/recycle for details.
  • Page 122 For Mexico only (for RF module only) El manual de usuario contendr las siguientes leyendas o su equivalente en una posici n notoria: La operaci n de este equipo est sujeta a las siguientes dos condiciones: (1) es posible que este equipo o dispositivo no cause interferencia perjudicial y (2) este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que pueda causar su operaci n no deseada.
  • Page 123 WLAN/BT module) 5GHz , 5.15GHz~5.25GHz Warranty and Copyright information 123...
  • Page 124 Warranty and Copyright information...
  • Page 125 RoHS Cr6+ PBBs PBDEs “×” WEEE < > <China WEEE> < > Warranty and Copyright information 125...
  • Page 126 SINGAPORE Warranty and Copyright information...

Table of Contents
