Icom IC-4008A Service Manual page 7

SECTION 3
•
REMOVING THE REAR PANEL
Unscrew 1 screw , and 4 screws
Remove the rear panel in the direction of the arrow.
A
•
REMOVING THE RF UNIT
Remove 1 knob, , and unscrew 1 nut,
Unsolder 1 point, , and then remove the RF unit.
E
C
D
DISASEMBLY INSTRUCTIONS
.
B
B
.
RF unit
MAIN unit
•
REMOVING THE MAIN UNIT
Unscrew 2 screws,
Remove the PTT rubber,
Unsolder 2 points,
F
3 - 1
.
.
, and remove the MAIN unit.
G
H
