Sennheiser EK 100 G3 Specifications

EK 100 G3
FEATURES
Sturdy metal housing
42 MHz bandwidth: 1680 tunable UHF
frequencies for interference-free reception
Enhanced frequency bank system with up
to 12 compatible frequencies
Adaptive-diversity reception for high
reception quality
Pilot tone squelch for eliminating RF inter-
ference when transmitter is turned off
Automatic frequency scan feature
searches for available frequencies
Enhanced AF frequency range
Wireless synchronization of transmitters
via infrared interface
User -friendly menu operation with more
control options
Illuminated graphic display
Auto-Lock function avoids accidental
changing of settings
HDX compander for crystal-clear sound
Receiver features battery indicatation in
4 steps
Contacts for recharging BA 2015 accu pack
directly in the receiver
Wide range of accessories adapts the
system to any requirement
Optimized PLL synthesizer and micro-
processor technology
Scan function (Easy Setup) for scanning
the frequency banks for unused channels
Portable receiver
Portable components always work easiest when you
do not have to think about them. This was the basis on
EK 100 G3
which the was developed. Its adaptive-
diversity technology provides excellent reception at all
times. This receiver is designed to securely attach to
a camera's shoe using a clamp mount. The EK 100 G3
also can synchronize to a G3 transmitter with a simple
push of a button. The EK 100 G3 is compatible with the
optional DC 2 external adapter for extended use without
batteries where a 12 V DC source is available.

TECHNICAL DATA

Modulation ...............................................................wideband FM
Frequency ranges.................................................... 516 – 558, 566 – 608, 626 – 668,
Receiving frequencies ............................................ 1,680 frequencies, tuneable in steps
Switching bandwidth .............................................42 MHz
Nominal/peak deviation .......................................±24 kHz/±48 kHz
Receiver principle ....................................................adaptive diversity
Sensitivity (with HDX, peak deviation) .............< 4 µV, typ. 1.6 µV for 52 dBArms S/N
Adjacent channel rejection ...................................typ. ≥ 65 dB
Intermodulation attenuation ...............................typ. ≥ 65 dB
Blocking .....................................................................≥ 70 dB
Squelch ...................................................................... Off, Low: 5 dBmV, Middle: 15 dBmV,
Pilot tone squelch ...................................................can be switched off
Compander system .................................................Sennheiser HDX
S/N ratio (1 mV, peak deviation) ........................≥ 60 dBA
THD .............................................................................≤ 0.9 %
AF output voltage
(at peak deviation, 1 kHz AF) .............................. 3.5 mm jack socket: +11 dBu
Adjustment range of audio output level ...........42 dB, adjustable in steps of 6 dB
Temperature range .................................................−10 °C to +55 °C
Power supply............................................................ 2 AA size batteries, 1.5 V
734 –776, 780 – 822, 823 – 865 MHz
of 25 kHz
20 frequency banks, each with up to
12 factory-preset channels
1 frequency bank with up to 12 user
programmable channels
High: 25 dBmV
(mono, unbalanced)
or BA 2015 accupack
