Ryobi P2400 Operator's Manual

18v home and garden sprayer
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Your home and garden sprayer has been engineered and manufactured to our high standard for dependability, ease of
operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.
WARNING:
To reduce the risk of injury, the user must read and understand the operator's manual before using
this product.
Thank you for your purchase.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
18V HOME AND GARDEN SPRAYER
P2400
BATTERIES AND CHARGERS
SOLD SEPARATELY

Advertisement

Table of Contents
loading

Related Manuals for Ryobi P2400

Summary of Contents for Ryobi P2400

  • Page 1 OPERATOR’S MANUAL 18V HOME AND GARDEN SPRAYER P2400 BATTERIES AND CHARGERS SOLD SEPARATELY Your home and garden sprayer has been engineered and manufactured to our high standard for dependability, ease of operation, and operator safety. When properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    The replacement power tool will be covered by the limited warranty for the balance of the two year period from the date of the original purchase. WHAT THIS WARRANTY COVERS: This warranty covers all defects in workmanship or materials in your RYOBI power tool ®...

  • Page 3: General Safety Rules

    MODEL BATTERY PACK (P100) CHARGER (P110) alcohol or medication. A moment of inattention while operating this product may result in serious personal P2400 130255004 1423701, 140237021 or 130224028 or 140237023 injury.

  • Page 4: Specific Safety Rules

    SPECIFIC SAFETY RULES IMPORTANT SAFETY INSTRUCTIONS  Maintain this product. Thoroughly inspect both the DANGER: inside and outside of the sprayer and examine the components before each use. Check for cracked Risk of fire or explosion. Do not spray flammable liquids and deteriorated hoses, leaks, clogged nozzles, such as gasoline.

  • Page 5: Safety Rules For Charger

    SAFETY RULES FOR CHARGER  An extension cord should not be used unless WARNING! absolutely necessary. Use of improper extension cord could result in a risk of fire and electric shock. If extension READ AND UNDERSTAND ALL INSTRUCTIONS. cord must be used, make sure: Failure to follow all instructions listed below, may result in a.

  • Page 6: Symbols

    SYMBOLS Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the product better and safer. SYMBOL NAME DESIGNATION/EXPLANATION Volts Voltage Amperes Current Hertz Frequency (cycles per second)
  • Page 7 If you servicing, use only identical replacement parts. do not understand the warnings and instructions in the operator’s manual, do not use this product. Call Ryobi customer service for assistance. WARNING: The operation of any power tool can result in foreign objects being thrown into your eyes, which can result in severe eye damage.

  • Page 8: Features

    FEATURES PRODUCT SPECIFICATIONS Charger Input ........120 V, 60 Hz, AC only Motor ...............18V DC Tank Capacity ............ 1.25 gallon TRIGGER WITH LOCK-ON MEASURING TANK SPRAY WAND Fig. 1 KNOW YOUR HOME AND GARDEN SPRAYER MEASURING CAP See Figure 1. The measuring cap can be used to measure up to 4 oz.

  • Page 9: Assembly

    ASSEMBLY UNPACKING This product requires assembly.  Carefully remove the product and any accessories from the box. Make sure that all items listed in the packing list are included.  Inspect the product carefully to make sure no breakage or damage occurred during shipping. ...

  • Page 10: Operation

    OPERATION CHARGING THE BATTERY PACK WARNING: Battery packs for this product are shipped in a low charge condition to prevent possible problems. Therefore, you Do not allow familiarity with products to make you care- should charge them until the green LED on the front of the less.
  • Page 11 OPERATION Fig. 4...
  • Page 12 OPERATION TO INSTALL THE BATTERY PACK See Figure 7.  Make sure the trigger is not in the locked-on position.  Place the battery pack into the battery port. Slide the battery pack into the sprayer. BATTERY PACK  Make sure the latches on each side of the battery pack slide into place and the battery pack is secured in the sprayer before beginning operation.
  • Page 13 OPERATION OPERATING THE SPRAYER  Thoroughly inspect both the inside and outside of the sprayer before each use.  Never point the spray end of the wand at yourself or others.  Avoid spraying on windy days. Spray can be acciden- TIGHTEN tally blown onto plants or objects that should not be FOR FAN SPRAY...

  • Page 14: Maintenance

    MAINTENANCE GENERAL MAINTENANCE WARNING: Avoid using solvents when cleaning plastic parts. Most plastics are susceptible to damage from various types of When servicing, use only identical replacement parts. commercial solvents and may be damaged by their use. Use Use of any other parts may create a hazard or cause clean cloths to remove dirt, dust, oil, grease, etc.
  • Page 15 MAINTENANCE CLEANING THE SPRAYER See Figure 11. WARNING: Always store and dispose of chemicals properly. Disposal of contaminated rinse water should be performed according to local ordinances and bylaws FILL AREA DRAINING THE TANK If there is any liquid left in the tank after spraying, the tank should be drained before cleaning.
  • Page 16 HOW TO OBTAIN CUSTOMER OR TECHNICAL SUPPORT: To obtain Customer or Technical Support please contact us at 1-800-860-4050. Ryobi is a registered trademark of Ryobi Limited used under license. ® ONE WORLD TECHNOLOGIES, INC. 1428 Pearman Dairy Road, Anderson, SC 29625 Phone 1-800-860-4050 www.ryobitools.com...
