QuickSpecs
Overview
At a Glance
At a Glance
At a Glance
At a Glance
AMD Athlon™ 64 1500+ processor
40-GB Ultra ATA/100 5400 rpm hard drive
512-MB DDR SDRAM PC2700 (333-MHz) expandable to 2 GB (2 SODIMM slots)
Two Broadcom 5705F 10/100 Integrated Network Controllers. NIC A is compliant with PXE (Pre-boot execution Environment)
Connector for graphics diagnostics card
USB 2.0
Restriction of Hazardous Substances
Blade PCs are protected by HP Services, including a limited three-year parts warranty with Advanced Unit Exchange for
express permanent replacement of a blade PC. Optional service uplifts available.
1 Products are designed to reduce the material used and to reduce or eliminate the use of hazardous materials to lower the
environmental impact of HP products.
HP BladeSystem bc1500 Blade PC
HP BladeSystem bc1500 Blade PC
HP BladeSystem bc1500 Blade PC
HP BladeSystem bc1500 Blade PC
1
(RoHS) compliant
DA - 12390
North America — Version 4 — January 22, 2007
HP BladeSystem bc1500 Blade PC
HP BladeSystem bc1500 Blade PC
HP BladeSystem bc1500 Blade PC
HP BladeSystem bc1500 Blade PC
Page 1

Advertisement

loading

Related Manuals for HP BladeSystem bc1500

Summary of Contents for HP BladeSystem bc1500

  • Page 1 Restriction of Hazardous Substances (RoHS) compliant Blade PCs are protected by HP Services, including a limited three-year parts warranty with Advanced Unit Exchange for express permanent replacement of a blade PC. Optional service uplifts available. 1 Products are designed to reduce the material used and to reduce or eliminate the use of hazardous materials to lower the environmental impact of HP products.

  • Page 2: Configuration Steps

    1. HP BladeSystem bc1500 Blade PC (sold in a single-pack or 10-pack) 2. HP BladeSystem PC Blade Enclosure (each can hold up to 20 blade PCs). The enclosure includes the HP BladeSystem PC Blade Switch (pre-installed) and comes bundled with 20 licenses for the ProLiant Essentials Rapid Deployment Pack.

  • Page 3: Standard Features

    IPC-A-610; PC2700; PCI 2.3; PXE 2.1; SPD 1.2B; UL 94; UL 796; USB 2.0. RoHS / WEEE complaint Manageability Manageability Manageability Manageability HP Session Allocation Manager (SAM) auto roll over to new blade (sold separately) HP Systems Insight Manager HP Rapid Deployment Pack HP BladeSystem PC Blade Switch Integrated Administrator ROM Based Setup Utility (RBSU)
  • Page 4 Includes the HP BladeSystem PC Blade Switch pre-installed within the enclosure. Mounts in HP 10000 and 9000 series, HP System-E, as well as third-party, and Telco racks. Rack mounting hardware for HP and third-party racks ships standard with each blade enclosure. Telco rack-mounting hardware is a separately available option kit.
  • Page 5 Utilities Utilities HP BladeSystem PC Blade Switch Features (Pre-installed with HP PC Blade Enclosure and sold HP BladeSystem PC Blade Switch Features (Pre-installed with HP PC Blade Enclosure and sold HP BladeSystem PC Blade Switch Features (Pre-installed with HP PC Blade Enclosure and sold...
  • Page 6 Emergency blade shutdown in the event of a critical temperature fault Service and Support Service and Support Service and Support Service and Support HP Services provides a wide range of service offerings, including a three-year, limited parts warranty on the HP BladeSystem bc1500 Blade PC. CAUTION: CAUTION: CAUTION: CAUTION: Do not ship Blade PCs and enclosure while inside the rack without first installing the e-Class Enclosure Shipping Bracket (part number PH555A).
  • Page 7 Hard Drive Hard Drive 40-GB Ultra ATA/100 5400 rpm Form Factor Form Factor Form Factor Form Factor Plugs vertically into HP e-Class Blade PC Enclosure bc1500 Blade PC bc1500 Blade PC bc1500 Blade PC bc1500 Blade PC Processor Processor Processor...
  • Page 8 Blade PC Diagnostic Kit (2 diagnostic adapters with USB 2.0 support + 5 graphics AG136AA cards) Fiber GBIC Fiber GBIC Fiber GBIC Fiber GBIC Avago Gigabit SX Mini-GBIC (2 per pack – for use with the HP BladeSystem PC Blade AH064AA Switch) Enclosure Shipping Enclosure Shipping Enclosure Shipping Enclosure Shipping...
  • Page 9 QuickSpecs HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC Memory HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC...

  • Page 10: Technical Specifications

    QuickSpecs HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC Technical Specifications HP BladeSystem bc1500 HP BladeSystem bc1500 HP BladeSystem bc1500 HP BladeSystem bc1500 Dimensions Dimensions Dimensions Dimensions Height...
  • Page 11 QuickSpecs HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC Technical Specifications Broadcom 5705F 10/100 Broadcom 5705F 10/100 Broadcom 5705F 10/100 Broadcom 5705F 10/100 Network interface Network interface Network interface...
  • Page 12 QuickSpecs HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC HP BladeSystem bc1500 Blade PC Technical Specifications Enclosure Hot-Plug Power Enclosure Hot-Plug Power Enclosure Hot-Plug Power Enclosure Hot-Plug Power Dimensions Dimensions Dimensions Dimensions Height...
  • Page 13 AMD, the AMD Arrow logo, AMD Athlon, and combinations thereof, are trademarks of Advanced Micro Devices, Inc. Microsoft and Windows are U.S. registered trademarks of Microsoft Corporation. The only warranties for HP products and services are set forth in the express warranty statements accompanying such products and services. Nothing herein should be construed as constituting an additional warranty.
