EV E N T B A R
User Instructions
Rev. 8/12
Event Bar
Unpacking:
Thank you for purchasing the Event Bar by Elation Pro-
fessionals
. Every Event Bar has been thoroughly tested and has been
®
shipped in perfect operating condition. Carefully check the shipping
carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your fixture for any
damage and be sure all equipment necessary to operate the unit has
arrived intact. In the event damage has been found or parts are miss-
ing, please contact our toll free customer support number for further
instructions. Please do not return this unit to your dealer without con-
tacting customer support first.
Introduction:
The Event Bar DMX intelligent LED fixture. The Event
Bar has 3 DMX Modes; 12 Channel DMX Mode, 14 Channel Mode, and
25 Channel Mode. The fixture three operating modes; sound active
mode, show mode or DMX controlled. The Event Bar can only be run
as stand alone unit. This unit is suitable for theaters, studios, retail
stores, and other similar locations. For best results use fog or special
effects smoke to enhance the light projections.
Customer Support:
Elation Professionals
tomer support line, to provide help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.elationlighting.com for any com-
ments or suggestions. Service Hours are Monday through Friday 8:00
a.m. to 4:30 p.m. Pacific Standard Time.
Voice:
(323) 582-3322
Fax:
(323) 832-9142
E-mail:
support@elationlighting.com
To purchase parts online visit http://parts.elationlighting.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Warning!
This may cause severe eye damage. Avoid looking directly
into the light source at all times!
©Elation Pr
fessionals® - www.elationlighting.com - Event Bar Instruction Manual Page 2
o
General Information
provides a toll free cus-
®
