Page 1: Impex Inc
NOTE: Please read all instructions carefully before using this product Table of Content ® MARCY Multi Purpose Bench Safety Notice SB-241 Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model SB-241 Retain This Manual for Reference 06-19-09 OWNER'S MANUAL ®... -
Page 2: Table Of Contents
ORDERING PARTS..................… BEFORE YOU BEGIN ® Thank you for selecting the MARCY SB-241 Multi Purpose Bench by IMPEX Inc. For your safety and benefit, read this manual carefully before using the machine. As the manufacturer, we are committed to provide you complete customer satisfaction. -
Page 3: Important Safety Notice
IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1. -
Page 4: Warning Label Placement
WARNING LABEL PLACEMENT The Warning Label shown here has been placed on the Rear Stabilizer. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in the location shown. -
Page 5: Hardware Pack
HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size. - Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
-
Page 7: Assembly Instruction
ASSEMBLY INSTRUCTION Tools Required for Assembling the Machine: Two Adjustable Wrenches and Allen Wrench... - Page 8 NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injuries. STEP 1 (See Diagram 1) A.) Do not tighten all Nuts and Bolts until instructed to do so. B.) Attach the Front Vertical Frame (#4) to the Front Stabilizer (#2). Secure it with two M10 x 2 3/8”...
- Page 9 A.) Attach the pivot on Incline Support (#5) in between the two Backrest Supports (#6). Attach the other end of Incline Support to the selected open slot on Main Frame (#1) to hold the selected incline in position. B.) Attach the side-holes of the two Backrest Supports (#6) to the Pivot on the Main Frame (#3).
- Page 10 STEP 3 (See Diagram3) A.) Place the Seat pad (#10) onto Main Frame (#1). Secure it to the two L-shaped Brackets (#11) with two M8 x ¾” Allen Bolts (#32) and two Ø 5/8” Washers (#35). Secure the Seat to the Main Frame with one M8 x 2 1/8”...
-
Page 12: Parts List
Parts list KEY NO. DESCRIPTION Q’ty Main Frame Front Stabilizer Rear Stabilizer Front Vertical Frame Incline Support Backrest Support Long Foam Tube Foam Tube Backrest Board Seat Pad L-shaped Seat Bracket Bracket Ø 3 1/8” Foam Roll Ø 2 ¾” Foam Roll Foam Grip 1”... -
Page 13: Limited Warranty
® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.
