NOTE: Please read all instructions carefully before using this product ® MARCY Table of Contents WEIGHT BENCH Safety Notice MWB-719 Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model MWB-719 Retain This Manual for Reference 08-28-08 ® IMPEX INC.
WARRANTY....................…. ORDERING PARTS..................… BEFORE YOU BEGIN ® Thank you for selecting the MARCY MWB-719 Weight Bench by ® IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.
IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.
Page 4
WARNING LABEL REPLACEMENT The Warning Label shown here has been placed on the Cross Brace. If the label is missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the label in location shown.
ASSEMBLY INSTRUCTION Tools Required for Assembling this Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended that two or more people assemble this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Connect the twp Upright Beams (#1) by a Cross Brace (#3) in the Mid-span. Secure each end of the Cross Brace with two M10 x 3 1/8”...
Page 7
STEP 2 (See Diagram 2) A.) Do not tighten Nuts and Bolts until instructed to do so. B.) Attach the Main Seat Support (#4) to the Front Post (#5). Secure it with three M10 x 5/8” Allen Bolts (#40) and Ø ¾” Washers (#35). C.) Attach the Main Seat Support to the Cross Brace (#3).
Page 8
STEP 3 (See Diagram 3) A.) Attach the Leg Developer (#7) to the open bracket on the Front Post (#5). Secure it with one M8 x 3” Allen Bolt (#30), two Ø 5/8” Washers (#37), and one M8 Aircraft Nut (#33). B.) Attach the pivot on Backrest Support (#8) to the open bracket on Main Seat Support (#4).
Page 9
STEP 4 (See Diagram 4) A.) Attach the Backrest Board (#14) to the Backrest Support (#8). Secure it with two M8 x 1 ¾” Allen Bolts (#29) and two Ø 5/8” Washers (#37). B.) Attach the Seat Pad (#13) to Main Seat Support (#4). Secure it with four M6 x 1 ¼” Hex Bolts (#27) and four Ø...
PARTS LIST KEY NO. DESCRIPTION QUANTITY Upright Beam Crutch Cross Brace Main Seat Support Front Post Diagonal Support Leg Developer Backrest Support Incline Support Bracket Foam Tube Lock Knob Seat Pad Backrest Board Ø 2” End Cap 2 3/8” x Ø 2” Crutch Sleeve Foam Roll Ø...
® IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
