  • Page 1 NOTE: Please read all instructions carefully before using this product IRON GRIP STRENGTH Table of Contents DELUXE COMBO BENCH Safety Notice IGS-8859 Hardware Pack Assembly Instruction Exploded Diagram Parts List Warranty Ordering Parts Model IGS-8859 Retain This Manual for Reference...
  • Page 2: Table Of Contents

    EXPLODED DIAGRAM..................PARTS LIST..................... WARRANTY..................... ORDERING PARTS..................BEFORE YOU BEGIN Thank you for selecting the IRON GRIP STRENGTH IGS-8859 COMBO ® BENCH by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.
  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.
  • Page 4 WARNING LABEL REPLACEMENT The Warning Labels shown here have been placed on the Support Frame and Lat Bar. If the labels are missing or illegible, please call customer service at 1-800-999-8899 for replacement. Apply the labels in location shown...
  • Page 5: Hardware Pack

    HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 6 HARDWARE PACK NOTE: The following parts are not drawn to scale. Please use your own ruler to measure the size.
  • Page 7: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches and Allen Wrenches. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Attach the Left Support Frame (#4) and the Rear Support (#13) to the Left Upright Beam (#1).
  • Page 8 STEP 2 (See Diagram 2) A.) Connect the Left Support Frame (#4) to the Right Support Frame (#5). Align the holes. Secure them together with two M10 x 3 ¾” Allen Bolts (#51), four Ø ¾” Washers (#64), and two M10 Aircraft Nuts (#67). Do not tighten the Nuts and Bolts yet. B.) Attach the Main Seat Support (#3) to both Left &...
  • Page 9 STEP 3 (See Diagram 3) A.) Attach the side-holes on the two Backrest Supports (#19) to the pivot on the Main Seat Support (#3). Align the holes. Secure them together with one M12 x 6 ¾” Allen Bolt (#50), two Ø 1” Washers (#63), and one M12 Aircraft Nut (#66). Do not over tighten the Nut and Bolt.
  • Page 10 DIAGRAM 3...
  • Page 11 STEP 4 (See Diagram 4) A.) Attach the Backrest Board (#23) to the Backrest Supports (#19). Secure it with four M8 x 1 3/8” Allen Bolts (#59) and Ø 5/8” Washers (#65). B.) Place the Seat Pad (#24) onto the Seat Bracket (#12). Secure it with four M8 x 1 3/8” Allen Bolts (#59) and Ø...
  • Page 12 STEP 5 (See Diagram 5) A.) Attach the Leg Developer (#9) to the Main Seat Support (#3). Secure it with one M10 x 3 ½” Allen Bolt (#52), two Ø ¾” Washers (#64), and one M10 Aircraft Nut (#67). B.) Insert two Foam Tubes (#20) halfway through the holes on the Leg Developer. Push four Foam Rolls (#30) onto the Tubes from both ends.
  • Page 14: Parts List

    PARTS LIST KEY NO. DESCRIPTION QTY’ Left Upright Beam M10 x 3 ¾” Allen Bolt Right Upright Beam M10 x 3 ½” Allen Bolt Main Seat Support M10 x 2 ¾” Allen Bolt Left Support Frame M10 x 2 ½” Allen Bolt Right Support Frame M10 x 2 3/8”...
  • Page 15: Impex Inc

    IMPEX INC. LIMITED WARRANTY ® IMPEX Inc. ("IMPEX ") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser.
