User Instructions
6/05
American DJ
®
4295 Charter Street
Los Angeles, CA. 90058
www.americandj.com
Emerald Scan™
Introduction:
Thank you for purchasing the American DJ
Scan.
The Emerald Scan™ is a DMX intelligent, laser effect that cre-
™
ates 12 different patterns. This unit can be used as a stand alone,
sound-active unit or in a Master/Slave configuration. The unit can also
be controlled via DMX controller. For a dramatic laser show use several
Emerald Scans™ together. This piece is best used with a fog or haze
machine to enhance the beam output.
Unpacking:
Every Emerald Scan™ has been thoroughly tested and
has been shipped in perfect operating condition. Carefully check the
shipping carton for damage that may have occurred during shipping.
If the carton appears to be damaged, carefully inspect the unit for
any damage and be sure all accessories necessary to operate the unit
have arrived intact. In the event damage has been found or parts are
missing, please contact our toll free customer support number for fur-
ther instructions. Please do not return the unit to your dealer without
first contacting customer support.
Customer Support:
American DJ
support line, to provide set up help and to answer any question should
you encounter problems during your set up or initial operation. You
may also visit us on the web at www.americandj.com for any com-
ments or suggestions. For service related issue please contact Ameri-
can DJ
. Service Hours are Monday through Friday 9:00 a.m. to 5:00
®
p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2610
E-mail:
support@americandj.com
To purchase parts online visit http://parts.americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty. In the unlikely event your unit may require service please
contact American DJ customer support.
PLEASE recycle the shipping carton whenever possible.
American DJ
- www.americandj.com - Emerald Scan™ Instruction Manual Page 2
©
®
General Introduction
Emerald
®
provides a toll free customer
®

Advertisement

Table of Contents
loading

Related Manuals for American DJ Emerald Scan

Summary of Contents for American DJ Emerald Scan

  • Page 1 Thank you for purchasing the American DJ Emerald ® Scan. The Emerald Scan™ is a DMX intelligent, laser effect that cre- ™ ates 12 different patterns. This unit can be used as a stand alone, sound-active unit or in a Master/Slave configuration. The unit can also be controlled via DMX controller.
  • Page 2 • Always be sure to mount this unit in an area that will allow proper The Emerald Scan™ carries a 90 day limited warranty. Please fill out ventilation. Allow about 6” (15cm) between this device and a wall.

  • Page 3: Control And Functions

    5. XLR Output Jack - This jack is used to transmit the incoming DMX signal to another DMX fixture, or transmit a Master/Slave signal to the next Emerald Scan™ in the chain. For best results in DMX or Master/Slave mode terminate this jack if it is the last unit in the chain.
  • Page 4 The Emerald Scan™ is a four channel DMX unit. The DMX gle controller, as long as all fixtures and the controller are DMX com- address is set on the side panel of the Emerald Scan. ™ Your unit and pliant. To ensure proper DMX data transmission, when using several your DMX controller require a standard 3-pin XLR connector for data DMX fixtures try to use the shortest cable path possible.

  • Page 5: Operating Modes

    Master/Slave configuration. It can Figure 3 also operate via DMX controller. The Emerald Scan™ is ready to be plugged in out of the box. After plugging the power cord into a power Special Note: Line Termination.
  • Page 6 American DJ - www.americandj.com - Emerald Scan™ Instruction Manual Page 11 American DJ - www.americandj.com - Emerald Scan™ Instruction Manual Page 12 ©...

  • Page 7: Dmx Traits

    45-59 6 7 8 Head 3 30-44 15-29 Head 4 00-14 0%%D Laser Off American DJ - www.americandj.com - Emerald Scan™ Instruction Manual Page 13 American DJ - www.americandj.com - Emerald Scan™ Instruction Manual Page 14 © ® © ®...

  • Page 8: Warranty

    ® tive parts at its expense, and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship. The sole responsibility of American DJ ® under this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of American DJ .
