- Page 1 Ghid de instalare in limba romana TEG-S50g TEG-S80g H/W: V1...
-
Page 2: Table Of Contents
Table of Contents Table of Contents English .................. 1. Before You Start ............2. Hardware Installation ............3. LEDs ................4 Româna ................... 1. Înainte de a începe ............2. Instalarea hardware ............3. LED-uri ................Specificaţii tehnice ................Troubleshooting ..................Remedierea erorilor de funcţionare .......... -
Page 3: English
1. Before You Start Package Contents TEG-S50g/TEG-S80g Quick Installation Guide AC Power Adapter (7.5V DC, 1A) Installation Requirements A computer with a network adapter installed Cat-5e or Cat-6 Network Cable The surface must support at least 1.5 Kg for the Switch ... - Page 4 Delivers less power Switch with shorter Full Power cable lengths 100m Regular Switch *Max power savings compared with standard TRENDnet switches. TEG-S80g Delivers less power to unused ports less power Delivers less power when devices are off less power 100m...
-
Page 5: Hardware Installation
2. Hardware Installation 1. Connect the AC Power Adapter to the TEG-S50g/TEG-S80g and then to a power outlet. 2. Connect a CAT-5e or CAT-6 RJ-45 network cable from the computer to an available Ethernet port of the TEG-S50g/TEG-S80g. English... -
Page 6: Leds
3. LEDs TEG-S50g Power Link/ACT Green: Power is on. Green(Solid): Link to another Not Illuminated: Power is off. device. Green(Blinking): Activity is occurring from the link Not Illuminated: Nothing is detected on the port. 1000Mbps 100Mbps Green: Connection for the port is... - Page 7 Your configuration is now complete. Register Your Product To ensure the highest level of customer service and support, please take a moment to www.trendnet.com/register register your product Online at: Thank you for choosing TRENDnet English...
-
Page 8: Româna
1. Înainte de a începe Continutul pachetului TEG-S50g/TEG-S80g Ghid rapid de instalare Adaptor AC/DC (7.5V DC, 1A) Cerinte de sistem Computer cu placă de reţea instalată Cablu de reţea Cat-5e sau Cat-6 Locul de amplasare trebuie să suporte cel puţin 1.5 Kg pentru Switch ... - Page 9 Delivers less power Switch with shorter Full Power cable lengths 100m Regular Switch *Max power savings compared with standard TRENDnet switches. TEG-S80g Delivers less power to unused ports less power Delivers less power when devices are off less power 100m...
-
Page 10: Instalarea Hardware
2. Instalarea Hardware 1. Conectaţi adaptorul AC/DC la TEG-S50g/TEG-S80g şi la priza electrică. 2. Conectaţi un cablu de reţea CAT- 5e sau CAT-6 RJ-45 de la computer la un port liber Ethernet de la TEG-S50g/TEG-S80g. Româna... -
Page 11: Led-Uri
3. LED-uri TEG-S50g Power Link/ACT Verde: pornit. Verde(continuu): conexiune Stins: oprit. stabilă cu un alt dispozitiv. Verde(intermitent): port activ. Stins: nu este detectată nici o activitate la port. 100Mbps 1000Mbps Verde: conexiunea la port este Verde: conexiunea stabilită este 100 Mbps (Full/Half) - Page 12 Configurarea este acum completă! Inregistrati-va produsul Pentru a va asigura ca veti primi cel mai ridicat nivel de suport, va rugam sa va inregistrati electronic produsul la www.trendnet.com/register Va multumim pentru ca ati ales TRENDnet Româna...
-
Page 13: Specificaţii Tehnice
Fast Ethernet: 100Mbps (half-duplex), 200Mbps (full-duplex) Gigabit Ethernet: 2000Mbps (full-duplex) Protocol/Topologie CSMA/CD / Star Interfaţă TEG-S50g: 5 x 10/100/1000 Auto-MDIX RJ-45 ports TEG-S80g: 8 x 10/100/1000 Auto-MDIX RJ-45 ports Date RAM Buffer TEG-S50g: 104KBytes per device TEG-S80g: 128Kbytes per device Opţiune Jumbo Frame... - Page 14 Hardware TEG-S50g: Power, Link/ACT, 100Mbps, 1000Mbps Indicatoare LEDs TEG-S80g: Power, Link/ACT, 100/1000Mbps Adaptor reţea electrică 7.5V DC, 1A External Power Adapter Dimensiuni 171 x 98 x 28 mm (6.7 x 3.86 x 1.1 in.) Greutate TEG-S50g: 430g TEG-S80g” 450g Temperatură...
-
Page 15: Troubleshooting
When I connect a computer to one of the ports on the Switch, the Power and the Link/ACT LED is lit, but I am not getting Gigabit speeds. First, check the LEDs. If you have the TEG-S50g, if the 1000Mbps LED is off, the computer's connection speed is 10Mbps or 100Mbps. If you have the TEG-S80g, if the 100/1000Mbps LED is amber, the computer's connection speed is 100Mbps. -
Page 16: Remedierea Erorilor De Funcţionare
Unde este localizat portul uplink al Switch-ului? Odată ce toate porturile Switch-ului sunt Auto-MDIX, orice port poate fi utilizat ca şi port uplink. Dacă mai întâmpinaţi probleme sau aveţi întrebări privind TEG-S50g/TEG-S80g rugăm contactaţi Serviciul de Asistenţă Tehnică de la Trendnet. - Page 17 Return Material Authorization (RMA) number, accompanied by a copy of the dated proof of the purchase. Products returned to TRENDnet must be pre- authorized by TRENDnet with RMA number marked on the outside of the package, and...
- Page 18 ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE OR USE OF TRENDNET’S PRODUCTS. TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S...
- Page 19 Certifications This equipment has been tested and found to comply with FCC and CE Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference. (2) This device must accept any interference received. Including interference that may cause undesired operation.
- Page 20 Product Warranty Registration Please take a moment to register your product online. Go to TRENDnet’s website at http://www.trendnet.com/register 20675 Manhattan Place Torrance, CA 90501 Copyright ©2009. All Rights Reserved. TRENDnet.
