Summary of Contents for Xerox WorkCentre 5632
Page 1
As fast as 3.4 seconds Copy Specifications Copying Document Scanner Platen (available with WorkCentre 5632) or Duplex Automatic Document Handler (DADH) option (Standard with WorkCentre 5638/5645/5655). Scans sizes up to A3/297 x 420 mm SEF Sides (input:output) 1:1, 1:2, 2:2 and 2:1...
Page 2
Customer device administration/software upgrade Accessibility Option Xerox Copier Assistant (XCA) Software provides a PC-based alternative to the user interface touchscreen. Used in conjunction with a customer-supplied PC attached via the USB port, this software provides text-to-speech, screen magnification and easy PC keyboard access to basic and advanced copy features.
Page 3
Transparencies Tab Stock Bond Envelopes Custom Settings (up to 7) Paper Handling – High Capacity Tandem Tray (optional with WorkCentre 5632, 5638, 5645; standard on 5655) Capacity Two trays: 1,600 and 2,000 sheets Sizes A4/210 x 297 mm LEF Weights 60 to 200 gsm Paper Handling –...
Page 4
WorkCentre 5632/5638/5645/5655 Output Option – Basic Office Finisher option (available for 5632, 5638 and 5645 only) Capacity Top Tray – 250 sheets Stacking Tray – 1,000 sheets Sizes A6/105 x 148 mm to A3/297 x 420 mm Weights 60 to 216 gsm...
Page 5
WorkCentre 5632/5638/5645/5655 Output Option – High Volume Finisher with Booklet Maker Option (available for 5645 and 5655 only) Capacity Top Tray – 250 sheets Stacking Tray – 3,000 sheets Sizes A6/105 x 148 mm to A3/297 x 420 mm Weights...
Page 6
WorkCentre 5632/5638/5645/5655 Print Specifications Network Printing – Controller (Simultaneous rip, receive, program ahead, queue processing and transmit) Processor 1.2 GHz (FreeScale 8545) Memory (ESS) 512 MB System Disk 80 GB Hard Drive shared Printer Language (PDL) • PCL 6/PCL 5e auto switching •...
Page 7
Xerox Mobile Express Driver Makes it easy for mobile users to find, use and manage Xerox and non-Xerox devices in every new location. Plug (X-MED) into a new network, and X-MED automatically discovers available printers and provides status and capability information.
Page 8
WorkCentre 5632/5638/5645/5655 Xerox Global Print Driver A truly universal print driver that lets IT administrators install, upgrade and manage Xerox and non-Xerox (X-GPD) devices from a single driver. It provides a consistent, easy-to-use interface for end-users, reducing the number of support calls, and simplifying print services management.
Page 9
• Printer banner sheet – Provide the ability to enable/disable printer banner sheets • Barcode printing – Xerox standard PostScript device types available at www.xeroxofficesapsolutions.com supports Intelligent Barcode Printing with Xerox Barcode Pro PS. This Barcode Pro PS can be purchased at www.font.net...
Page 10
WorkCentre 5632/5638/5645/5655 Scan Specifications Scanning Concurrency Scan while the system is printing, copying, or while it is transferring scan to network or fax jobs Input Speed Scan at up to 60 ipm – A4/210 x 297 mm LEF at all resolutions...
Page 11
ScanSoft OmniPage Pro Office (for desktop/client installation) – Professional OCR software for digital archiving and document conversion Image Retriever – provides fully automated retrieval of scanned images direct from a scan enabled Xerox WorkCentre to individual desktops. Also includes an email inbox polling capability.
Page 12
WorkCentre 5632/5638/5645/5655 Fax Specifications Fax Options – Walkup Option (One or Two Lines Options) Compatibility ITU (CCITT) Group 3 Memory 256 MB (One Line and Two Line options) Speed/Modem(s) 1 or 2 V.34 modems: 33,600bps. Less than 4 seconds per page transmission time, ISDN via third party adapter...
Page 13
WorkCentre 5632/5638/5645/5655 Fax Options – LAN Fax with Walkup Fax (optional with the Copier / Printer) Driver based LAN fax for Windows and Macintosh users (PCL and PS drivers) Recipient options (add recipient or add from phone book) User personal phone book – up to 1,000 entries Confirmation sheet Send speed (14.4/33.6kbps or 4800bps)
Page 14
Auditron report printout, ability to upload/download account and usage data via direct connection using Microsoft Windows based software Accounting Features – Xerox Standard Accounting (standard with the Copier / Printer and the Copier / Printer / Scanner) Tracking Copy, Print, Fax and Scan usage...
Page 15
Secure Access Unified ID System adds an advanced layer of security at the device by enabling users to log-in to a Xerox multifunction system with a swipe of their magnetic or proximity ID card. When combined with Follow You Print functionality, Secure Access allows private print jobs to be accessed from any Xerox printer or multifunction system on your network.
Page 16
Scan to PC Desktop SE and Professional (Available with Copier/Printer only) Xerox Unicode International Printing Kit Enablement for Network Accounting and Xerox Alliance Partner Solutions Upgrade Kit to Copier/Printer/Scanner (includes Network Scanning, Scan to Email, Network Server Fax and Internet Fax) Features, confi...
Page 18
Energy Star Bypass Tray closed. Weights do not include Shelf (1.36 kg). Noise levels shown are “Not to Exceed” levels. Actual noise levels will be lower. Does not include the Copier-Only confi guration of WorkCentre 5632 and 5638. Detailed Specifi cations...
Page 19
WorkCentre 5632/5638/5645/5655 Supplies Description Order Number No. per Box Expected Yield Toner Cartridge 006R1046 > 32,000 at 6% area coverage per bottle Waste Toner Bottle 008R12896 100,000 (supplied with each toner cartridge box) Staple Cartridge / Pack 108R00535 3 cartridges...
Page 20
, WorkCentre , Copier Assistant and the sphere of connectivity design are trademarks of Xerox Corporation in the United States and/or other countries. PostScript is a registered trademark of Adobe Systems Incorporated in the United States and/or other countries. Other marks are trademarks or registered trademarks of the companies with which they are associated.
