- Page 1 IP Telephone User Guide LIP-6812 SIP (Session Initiation Protocol) Sylantro SIP4B Please read this manual carefully before operating your set. Retain manual for future reference. LGN-6812-1224SS01.01...
- Page 2 Copyright Laws. LG-Nortel reserves the right to make changes in specifications at any time without notice. The information furnished by LG Nortel in this material is believed to be accurate and reliable, but is not warranted to be true in all cases.
-
Page 3: Table Of Contents
2.14. Muting a Call ....................10 2.15. Accessing Your Voice Mail ................10 2.16. Shared Call Appearance / Bridge Line Appearance .........11 2.17. DSS/BLF Coverage button ................11 2.18. Hotline/ Warm-Line...................12 3. Advanced Services and the LIP-6812 LCD Menu ......13 3.1. Call Logs ......................13 3.2. Phone Book......................14 3.3. -
Page 4: Introducing The Lip-6812
Service Provider’s network. Features and functions available to the LIP-6812 through the SIP Call Server are similar to those of a conventional business telephone. For ease of use, the LIP-6812 is equipped with fixed feature buttons, flexible (programmable) feature buttons, an LCD display, Softkeys, and a dial pad. -
Page 5: Lip-6812 General Description
1.3. LIP-6812 General Description The LIP-6812 interfaces with you to deliver voice and audio signals over the handset and speaker. A Microphone, which can be switched On and Off (muted), is located in the right front for audio input to the LIP-6812 Speakerphone. The 3-line, 24-character LCD is a visual output for status and interactive menus. - Page 6 LIP Phone configuration. Volume control button. Use to adjust Ring, Headset, Handset, and Speaker volume. Speaker button. Toggle the LIP-6812 speakerphone On and Off. Mute button. Toggle audio from the microphone to the connected party On and Off.
- Page 7 LIP-6812 User Guide Flexible buttons (11) with Red/Green LEDs. Assign as Line or Feature using LCD Menu or Web Manager. Default assignments for buttons 1 and 2 are primary and secondary Line appearance for the extension. June 07...
-
Page 8: Using Basic Lip-6812 Features
Some buttons on the LIP-6812 represent Lines or SIP call appearances. The Line buttons present and manage calls to the specific Line or appearance. The LIP-6812 can support up to eleven (11) Lines, each associated with their own Line button. The LED of the Line button indicates Line status as follows: Green LED On –... -
Page 9: Making A Call
LIP-6812 User Guide NOTE: Calls can not be received unless the Line is registered to a Call Server. When not registered, the Line button LED will blink red and orange. 2.2. Making a Call You can make a call using on-hook or off-hook dialing. -
Page 10: Transferring Calls, Blind/Unannounced
LIP-6812 User Guide To cancel the Transfer: 1) Press the Softkey. [Cncl] 2.5. Transferring Calls, Blind/Unannounced You can transfer an active call to another extension without talking to the party who is to receive the call, using Blind Transfer. The caller is transferred to the new party without verifying that the new party is there or willing to receive the call. -
Page 11: 3-Party Conference
LIP-6812 User Guide 2.7. 3-Party Conference The LIP-6812 3-Party Conference feature lets you speak with two other parties at once. To initiate a conference between the current party, you, and another party: 1) Press the Softkey, and dial the number you want to join in the conference. -
Page 12: Last Call Return
“Empty speed number.” 2.13. DND (Do-Not-Disturb) The DND (Do Not Disturb) feature places the LIP-6812 in a ‘no-ring’ state. If the LIP-6812 is in DND, an incoming call to your extension will not cause the phone to ring. To use this feature,... -
Page 13: Muting A Call
When you have a message waiting, the MSG light will flash and messages may be retrieved. A MSG button may be assigned to the LIP-6812 for ease of use (refer to the Installer Guide for the steps to configure the Flexible button). -
Page 14: Shared Call Appearance / Bridge Line Appearance
2.16. Shared Call Appearance / Bridge Line Appearance The LIP-6812 can support up to 11 Lines, each associated with its own button. A Line button could be set up as a Private Line, a Shared Line or DSS/BLF Call Coverage Line. A Private Line is used by only one phone. -
Page 15: Hotline/ Warm-Line
Busy Lamp Field (BLF) — visual status indication of covered extensions. The DSS/BLF feature in the LIP-6812 uses the Shared call appearance feature. Operation of the DSS/BLF Coverage button however is distinctively different than a Shared Line. -
Page 16: Advanced Services And The Lip-6812 Lcd Menu
Softkeys or by dialing the digit preceding the item. 3.1. Call Logs The LIP-6812 has access to a log of all calls placed or received by the phone, including incoming calls that were not answered (missed calls). The Call Logs can be viewed on the LCD and used to place a call to the logged party. -
Page 17: Phone Book
User Guide 3.2. Phone Book The LIP-6812 contains an internal Phone Book that has 100 entries. You can add to, delete, edit, and dial entries from the Phone Book. The Phone Book is accessed with a programmable button assigned for the Phone Book function (refer to Installer Guide for the steps to configure the Phone Book). - Page 18 LIP-6812 User Guide 1) Press the Phone Book button. 2) Select the desired record; press the to view additional records. Phone Book (Page 1) >[01]Tom,1234 [Edit] [Add ] [Del ] 3) Select Softkey. [Edit] Phone Book (Page 1) >[15]Tommy,9876 [Edit] [Add ] [Del ]...
-
Page 19: Call Park
LIP-6812 User Guide 3) Select Softkey and [DAll] [Yes ] Phone Book (Page 1) >[15]Tommy,9876 [DALL] [Find] To search the records in the Phone Book: 1) Press the Phone Book button. 2) Press the to locate the selection. [Find] Phone Book (Page 1) >[01]Tom,1234... -
Page 20: Direct Call Pick Up
Your Call Server may provide an intercom feature; this feature allows for Voice Announce intercom calling with handsfree reply. If available, a button on your LIP-6812 may be assigned to access the intercom (refer to the Installer Guide for the steps to configure the Intercom button and beep tone). -
Page 21: Acd Agent Group
A programmable button on the LIP-6812 should be assigned as an ACD Agent button for Agent control. Using the ACD Agent button, the user can activate ACD for a Line, enter an ACD Group ID (if not preconfigured), control the Agent status and assign the ACD Primary Line to display the Agent status on the LCD. - Page 22 LIP-6812 User Guide ACD Status (Line 1) Check-Out [C.In] [PRIM] 2) Press the Line button, and then press the Softkey. [C.In] NOTE: The check-in Softkey is only available if the Agent is checked out. 3) Accept the pre-defined ACD Group ID with the...
- Page 23 LIP-6812 User Guide 3) Press the Softkey. [COut] NOTE: The check-out Softkey is only available if the Agent is checked in. ACD Status (Line 1) Unavailable [Avail] [COut] [PRIM] To set the Line as the Primary ACD Line to display the ACD status from the LCD:...
- Page 24 LIP-6812 June 07...
- Page 25 LIP-6812 LGN-6812-1224SS01.01 June 07...
