- Page 1 LIP Phone 6812 User Guide SIP (Session Initiation Protocol) for Sylantro, SIP4B Please read this guide carefully before operating your set. Retain this guide for future reference. LGN6812-1235SSUG-01.03 Sept 07...
- Page 2 Copyright Laws. LG-Nortel reserves the right to make changes in specifications at any time without notice. The information furnished by LG Nortel in this material is believed to be accurate and reliable, but is not warranted to be true in all cases.
- Page 3 LIP Phone 6812 User Guide Care & Precautions: Before connecting or using your new phone, take a moment to consider safety and reliability. Use common sense when locating, connecting and using your LIP Phone 6812. • Locate on a dry level surface. Keep the phone away from the edges of the surface to avoid the potential of a fall.
-
Page 4: Table Of Contents
LIP Phone 6812 User Guide Table of Contents LIP Phone 6812 Overview ..................1 Installing your LIP Phone 6812................3 Using Features of LIP Phone 6812 ...............4 3.1. Receiving a Call..........................4 3.2. Placing a Call..........................4 3.3. Putting a Call on Hold ........................4 3.4. - Page 5 LIP Phone 6812 User Guide 5.6.2. Time Zone........................... 21 5.6.3. DST Auto Adjustment ......................21 5.6.4. Time Format........................22 5.6.5. Date Format ........................22 5.7. Lock Outgoing Call ........................23 5.8. Enabling Speed Number Dialing ....................23 Appendix A Dial Pad Character Set ................24 Appendix B Time Zones....................25 Oct.
-
Page 6: Lip Phone 6812 Overview
User Guide 1. LIP Phone 6812 Overview Your new LG-Nortel LIP Phone 6812 is an Internet Protocol (IP) phone employing Session Initiation Protocol (SIP), the well-known open standard for establishing, managing and terminating a communication session. LIP Phone 6812 interoperates with call servers, proxies and gateways to exchange SIP signaling messages for call control. - Page 7 LIP Phone 6812 User Guide Line in use at this phone Green LED On Incoming call on private line Green LED flashes at 60 ipm, fast flash Call held at this phone Green LED flashes at 30 ipm, slow flash BLA in use at another phone LED On Incoming call on BLA...
-
Page 8: Installing Your Lip Phone 6812
LIP Phone 6812 User Guide 2. Installing your LIP Phone 6812 The figure below shows the cable connections for your LIP Phone. The LAN and desktop PC connections employ standard category 5 cables terminated with RJ-45 connectors. The LIP Phone supports PoE (Power over Ethernet) in accordance with the IEEE-802.1af standard. -
Page 9: Using Features Of Lip Phone 6812
LIP Phone 6812 User Guide 3. Using Features of LIP Phone 6812 3.1. Receiving a Call When you receive a call, your phone rings, the LCD displays the incoming call information and the associated line button flashes. To answer a ringing call: [Answ] o Lift the handset. -
Page 10: Announcing A Call Transfer
LIP Phone 6812 User Guide [Rsum] o Press the slow flashing line button, or the softkey. To toggle between two calls on the same line: o Press the line button, the active call status changes to hold and the held call connects. 3.4. -
Page 11: 3-Party Conference
LIP Phone 6812 User Guide [CFwd] o Press softkey. The message “Fwd to xxxx” disappears from the LCD. 3.7. 3-Party Conference The LIP Phone has a 3-Party Conference feature that lets you converse with two other parties simultaneously. To set-up a conference: o Place first call as normal. -
Page 12: Speed Dial Buttons
LIP Phone 6812 User Guide 3.11. Speed Dial Buttons Flexible buttons not assigned as a line are available for configuration as feature buttons including Speed dial. Pressing a Speed dial button selects your line and sends the stored number to the call server for processing. -
Page 13: Accessing Your Voice Mail
LIP Phone 6812 User Guide 3.15. Accessing Your Voice Mail When you have a message waiting, the MWI LED flashes to indicate you have new messages in your mailbox. The LIP Phone delivers the message waiting indication for your primary line, line button 1. To access your voice mailbox: [MSG] o Press the... -
Page 14: Hotline/Warm-Line
LIP Phone 6812 User Guide 3.17. Hotline/Warm-Line With Hotline/Warm-Line operation configured, the LIP Phone automatically calls the defined destination when you take the handset off-hook or press the speaker button. The call initiates immediately, Hotline, or after a delay of up to 10 seconds, Warm-Line. The later permits you the time to access another feature or line as needed. -
Page 15: Advanced Services And The Lip Phone 6812 Lcd Menu
Setting Your Preferences for instruction on defining flexible buttons. To access the Phone Book menu: Phone Book (Page 1) o Press the Phone Book flexible button, the LCD >1.LG-Nortel, 1305 displays the first Phone Book record. [Prev] [Next] [Dial] To call a contact from the Phone Book: o Press the Phone Book flexible button. - Page 16 LIP Phone 6812 User Guide [Prev]-[Next] o Use the softkeys to display the desired record or dial the digit preceding the desired record. [Dial] o Press the softkey. To add a record to the Phone Book: Phone Book (Page 1) o Press the Phone Book flexible button.
-
Page 17: Park
LIP Phone 6812 User Guide To delete all records: o Press the Phone Book flexible button. Phone Book (Page 1) [DALL] >[01]Tom,1234 o Press the right arrow softkey to locate the [DALL] [Find] softkey. [DALL] o Select softkey and confirm the deletion by [Yes ] softkey. -
Page 18: Directed Call Pickup
LIP Phone 6812 User Guide [Pick] o Press the softkey. The LIP Phone activates the Input Extension speakerphone and selects your line. You may select a [Pick] different line button prior to pressing the softkey. ] [Mode] [ OK ] o Dial the extension number where the call is parked [ OK ] then press the... -
Page 19: Acd Agent Menu
LIP Phone 6812 User Guide 4.8. ACD Agent Menu Your call services may include Automatic Call Distribution (ACD). Calls to an ACD group enter a queue and the call routes to the next available ACD agent. This feature is useful for customer support groups, user taking reservations, or making appointments. - Page 20 LIP Phone 6812 User Guide To set the extension to the “unavailable” status: o Press the ACD Agent button. ACD Status (Line 1) [Unvl] o Press the line button, and then press the Available [Unvl] softkey. The softkey appears only if the Agent [Unvl] [COut] [PRIM] is available.
-
Page 21: Setting Your Preferences
LIP Phone 6812 User Guide 5. Setting Your Preferences In the LCD Menu, you can set various preferences for the LIP Phone. Settings you can adjust include: LCD contrast Ring Setting Ringer off Headset auto mode Flexible button settings Time Configuration Outgoing Call Lock Speed Number Dialing The following paragraphs provide detailed instructions for each of the preferences as well as descriptive... -
Page 22: Setting Line Ring Type And Delay
LIP Phone 6812 User Guide 3.Phone Settings [Prev]-[Next] o Dial 3, or move the cursor to using the softkeys and press the [ OK ] softkey. 2.Ring Setting o Dial 2, or move the cursor to using the [Prev]-[Next] [ OK ] softkeys and press the softkey. -
Page 23: Ringer Off
LIP Phone 6812 User Guide 3.Phone Settings [Prev]-[Next] o Dial 3, or move the cursor to using the softkeys and press the [ OK ] softkey. 2.Ring Setting [Prev]-[Next] o Dial 2, or move the cursor to using the softkeys and press the [ OK ] softkey. -
Page 24: Setting Flexible Buttons
LIP Phone 6812 User Guide 4.Headset Auto Mode [Prev]-[Next] o Dial 4, or move the cursor to using the softkeys and press [ OK ] softkey. [Yes ] o Press the softkey to enable the Headset Auto [ No ] Headset Auto Mode Mode or press the softkey to disable the... -
Page 25: Time Configuration
LIP Phone 6812 User Guide 3.Phone Settings [Prev]-[Next] o Dial 3, or move the cursor to using the softkeys and press the [ OK ] softkey. 6.Flexible Key Setting o Dial 6, or move the cursor to Press Flexible Button [Prev]-[Next] [ OK ] using the... -
Page 26: Time Zone
LIP Phone 6812 User Guide o Input the SNTP server address using the dial pad and [ OK ] SNTP Server Address press the softkey to save the entry. To enter [Mode] clock.via.net alphanumeric characters select the softkey. ] [Mode] [ OK ] Refer to Appendix A for the character mapping of dial... -
Page 27: Time Format
LIP Phone 6812 User Guide 5.6.4. Time Format The format of the LCD time display can be set for 12-hour format or 24-hour format. In addition, the LCD time display can be disabled. To set the display format for time: o Press the button. -
Page 28: Lock Outgoing Call
LIP Phone 6812 User Guide 5.7. Lock Outgoing Call The LIP Phone can be configured to allow outgoing calls only if a password is entered. When enabled, the LCD screen will display the password request as shown and the password must be entered prior to connecting an outgoing call. -
Page 29: Appendix A Dial Pad Character Set
LIP Phone 6812 User Guide Appendix A Dial Pad Character Set The LIP Phone 6812 dial pad inputs digits or alphanumeric characters. The table below maps between each dial pad digit to characters. Dial Pad Mode Digit Upper Case Lower Case Symbols ‘[A]’... -
Page 30: Appendix B Time Zones
LIP Phone 6812 User Guide Appendix B Time Zones Country Country GMT-12:00 International Date Line, West GMT+01:00 Oslo, Norway GMT-11:00 Midway/Samoa GMT+01:00 Paris, France GMT-10:00 Hawaii GMT+01:00 Rome, Italy GMT-09:00 Alaska GMT+01:00 Stockholm, Sweden GMT-08:00 Los Angeles, California GMT+01:00 Vienna, Austria GMT-08:00 Pacific Standard GMT+02:00 Athens, Greece GMT-07:00 Mountain Standard... - Page 31 LIP Phone 6812 User Guide Oct. 07...
