Setting Up Your Appliance for Initial Configuration

Introduction
Using Microsoft
emulation
Requirements
Procedure
IBM Proventia Network Enterprise Scanner User Guide, Version 1.3
To configure the initial appliance settings, you must connect the appliance to the network
and set up a terminal emulation session with your appliance. You can use a laptop or a
mobile desktop.
Terminal emulation programs are installed with Microsoft and Linux operating systems.
Documentation for using them should be provided by the vendor. A common Microsoft
emulation program is HyperTerminal. You can start it as follows:
Click Start on the taskbar, and then click All
●
→
Programs Accessories
You need the following items to set up terminal emulation:
a computer with a terminal emulation program that you connect to the appliance with
●
an RS-232 serial (COM) port
the power cord that came in the box with the appliance
●
the serial cable with an RJ45 connection that came in the box with the appliance
●
a static IP address for the Management network interface
●
To connect with terminal emulation:
1. Connect the power cord to the power receptacle on the back of the appliance, and
plug the cord into the power source.
2. Connect the Management Port to a router or a switch on your network that has
connectivity with the SiteProtector system that will manage your agent.
3. Connect Scan Port (if connecting the ES750) or Scan Port 1 (if connecting the ES1500)
to the network to scan.
4. Connect the laptop or mobile desktop to the same network as the appliance using the
Ethernet adapter on the computer and a standard Ethernet cable.
5. Plug the RJ45 connection into the Console outlet on the appliance, and plug the other
end of the cable into a serial port on the back of the computer.
6. Start your terminal emulation program with the following settings:
Setting
Baud rate
Flow control
Data bits
Parity
Stop bits
Emulation
Setting Up Your Appliance for Initial Configuration
→ →
Communications
Value
9600
Hardware
8
None
1
VT100
HyperTerminal.
