MAIN FEATURES Main Features Handlebar Securing Knob. Cable. Switch Control Unit. Bail Arm. Handlebar. Cable Cleat. Grassbag Assembly. Rear Deflector. Serial No. Decal. Height of Cut Lever Motor Housing Specifications Code (100C) (101C) Supply 220-240V~50Hz Rated Input 1.4 kW Fuse Rating Weight 23 Kg Cutterblade Speed...
Any arbitrary modifications carried out to this machine may relieve Hayter Limited of liability for any resulting damage or injury. Hayter mowers are robustly constructed and designed for efficient economical performance under normal mowing conditions. Correct operation and maintenance will ensure a long and satisfactory service life.
WARRANTY LIMITED WARRANTY Hayter Limited warrants to the original user/purchaser that this unit shall be free from defects in material or workmanship under normal use for a period of two years from the date of purchase. To qualify for the full benefit of the warranty, the warranty registration card must be returned to Hayter Limited within 14 days of purchase.
SAFETY PRECAUTIONS Safety Alert Symbol This safety alert symbol indicates important safety messages. When you see this symbol be alert to the possibility of injury. Carefully read the following and inform others. Your mower is perfectly safe if used correctly. Failure to observe the following precautions may result in serious injury.
Page 7
Always ensure that the mower is in a safe operating condition. Frequently check all nuts, bolts and screws for tightness. Use only gen- uine Hayter parts. A damaged cutterblade and loose fixing bolt are major hazards. Before use, visually inspect the cutting mechanism to ensure that it is in good condition.
Page 8
SAFETY PRECAUTIONS Operation Use extreme caution when reversing or pulling the mower towards you. Switch off if the mower has to be tilted for transportation when cross- ing surfaces other than grass and when transporting the mower to and from the area to be mowed. Never operate the mower unless the guards are securely in position and in good condition.
Safety Alert - Be aware to the possibility of injury. Carefully read the Owners Handbook before using the machine. Do not use in rain or in wet conditions. Switch ON / OFF (Symbol) SAFETY PRECAUTIONS Safety Symbols Danger of severing toes or fin- gers in cutting mechanism.
ASSEMBLING THE MOWER Delivery Checklist Remove the mower from the packaging and check that the following items have been supplied correctly. If any items are missing contact, your local Hayter dealer. 1. Instruction Sheet 2. Grassbag Frame 3. Grassbag Top Cover 4.
OPERATING MOWER Electrical Connection Position the mower on the grass area to be cut. Carefully uncoil the supply cable clear of the mower. Ensure that the mains socket is switched 'OFF' before connecting. Switch 'ON'. Note: We recomend the use of a RCCB unit- Refer to "Safety Precautions"...
OPERATING THE MOWER Stopping Release the bail arm to stop the motor. WARNING: AVOID ACCIDENTS - The cutterblade may contin- ue to rotate after the mower is switched off Height of Cut Move the height of cut lever sideways to disengage it from the locking notch, then push forwards to lower or pull backwards to raise the height of cut.
OPERATING MOWER Grassbag To empty the grassbag raise the rear deflector and pass the grassbag under the handlebar and lower the rear deflector to rest against the rear of the mower. Pour out the grass clippings and shake the grassbag vigorously to clean the airways.
OPERATING THE MOWER Safe Mower Practice WARNING: PREVENT ACCIDENTS -Take extreme care do not mow across the supply cable. If this should occur, switch off immedi- ately and disconnect the plug from the power supply. Carefully exam- ine the cable for cuts and damage. A defective cable must be replaced before the mower is used again.
OPERATING MOWER Overloading Protection Do not let the motor labour or slow down through being overloaded in work. When this situation occurs, raise the front of the mower slightly by bearing down on the handlebar, allow the motor to reach maximum speed and proceed to mow at a slower pace.
LAWN CARE CALENDAR To be used as a guide only. January There is very little work to do this month apart from brushing away leaves. Keep off the grass if frozen or waterlogged. February Rake the grass thoroughly. Spike the lawn to aerate and stimulate soil organisms and root growth and apply lawn sand if necessary.
LAWN CARE CALENDAR August Keep mowing regularly and watering as necessary. Fill any cracks caused by drought with a mixture of sharp sand and soil. In dry weath- er conditions leave the grass longer to help retain ground moisture. September Raise the height of cut to allow the grass to thicken and protect the roots from the winter frost and snow.
MAINTENANCE SCHEDULE Follow the hourly or calendar intervals, whichever occurs first. More frequent service will be required if working for prolonged periods under dusty, dry conditions, or when airborne debris is present or after extensive operation cutting tall, dry grass. Daily Remove grass debris from around the height of cut ratchet, air filter in the cowl and the underside of the deck housing.
MOWER MAINTENANCE Deck Housing Remove grass debris from the top and underside of the deck housing immediately after use. Securing Fasteners Regularly check that all securing nuts and bolts are tight. Replace missing or damaged items immediately. Bolt - Cutterblade fixing Torque 20Nm Plastic Screws - Bottom of Handlebar Torque 3.5Nm General Screws - Used on plastic parts 1.5Nm (Note: Use manual 1CG480V36B...
MOWER MAINTENANCE Cutterblade Removal Turn the mower on its side. Firmly grip the end of the cutterblade (2) with a gloved hand and remove bolt (1). When replacing ensure that the new cutterblade is the correct way up with the turned edges facing towards the motor before locating onto the two carrier pins.
MOWER MAINTENANCE Cutterblade Sharpening A slightly worn cutterblade may be re-sharpened. Both blade edges 30°-45° must be sharpened equally to ensure balance. Sharpen the cutterblade every 25 mowing hours or more frequently if conditions require. Remove the cutterblade from the mower and clean using a brush and water.
MOWER MAINTENANCE Storage Handlebar storage: To collapse the handlebar first unscrew the two top securing knobs to allow the top section of the handlebar to pivot forward to rest against the middle section then unscrew the bottom two securing knobs sufficiently to allow both top and middle sections to be folded forwards.
PROBLEM Motor fails to start. Motor will not stop. Cutterblade runs on exces- sively after switching 'OFF'. TROUBLE SHOOTING POSSIBLE FAULT Mains supply socket dead. RCCB tripped. Plug pulled out of mains socket. Fuse failure. Supply cable damaged. Cutterblade obstructed. Faulty switch control unit.
Page 24
TROUBLE SHOOTING PROBLEM Motor vibrates excessively. Uneven cut Discharge chute blocks. Mower is hard to push. Poor grass collection. 1.24 POSSIBLE FAULT Mounting bolts loose. Cutterblade bolt loose. Cutterblade out of balance. Undulating ground contours. Cutterblade worn. Cutterblade out of balance. Wheels / Roller damaged.
EC DECLARATION OF CONFORMITY Manufactured for: HAYTER LIMITED, Spellbrook, Bishop’s Stortford, Herts, CM23 4BU. ENGLAND declare that the lawnmower: Type. Model name: Model No: Cutting width: Speed of rotation of cutting device: Motor manufacturer: Speed of rotation of motor: Complies with the provisions of Directive: 98/37/EC Essential Health & Safety Requirements relating to the Design &...
PARTS LIST DESCRIPTION ITEM NO. Motor Capacitor Underdeck Throw Plate Wheel - Wide Assy Bearing - Wheel Hub - Cap Starlock 12mm Rod - Rear Axle Wheel - Thin Assy Lever - HOC Spring - HOC Rear Axle Assy Plate - Axle Pivot Screw - M4 Bolt - Fixing Cutterblade Cutterblade...
Page 27
ITEM NO. DESCRIPTION Spring - Deflector Knob - HOC Ratchet - HOC Washer - Spring M8 Grassbag - Fabric/base Frame - Grassbag Top - Grass Bag Screw - M6 x 20 Bolt - Plastic Handlebar Fan - Motor Top Spacer - Rear Wheel Pin - Spring HOC Spring - Counter Balance Cleat - Cable...
