Hayter 13/30 Instruction Book

13/30 heritage tractor
Hide thumbs Also See for 13/30:
Table of Contents

Advertisement

Quick Links

See also: Instruction Book
Code
Serial No.
131F
290000001
Issue 11/2008
13/30
HERITAGE TRACTOR
CODE 131F
INSTRUCTION BOOK
CAUTION: Read and
follow all instructions.
Part No. 111-2912 (Rev. A)
1742389
Revision B
TP10006226

Advertisement

Table of Contents
loading

Related Manuals for Hayter 13/30

Summary of Contents for Hayter 13/30

  • Page 1 13/30 HERITAGE TRACTOR CODE 131F INSTRUCTION BOOK CAUTION: Read and follow all instructions. Code Serial No. Part No. 111-2912 (Rev. A) 131F 290000001 1742389 Revision B Issue 11/2008 TP10006226...

  • Page 3: Table Of Contents

    Table of Contents International Pictorials..........4 Identification Numbers .

  • Page 4: International Pictorials

    International Pictorials I I MPORTANT: The following pictorials are located on your unit or on literature supplied with the product. Before you operate the unit, learn and understand the purpose for each pictorial. Saf ety Warning Pictorials WARN ING IMPORTANT: Read owner s manual before operating this machine.

  • Page 5: Identification Numbers

    Identification Numbers CE Identification Tag Markings A. Manufacturer’s Identification Number Part No. xxxxxxx B. Manufacturer’s Serial Number C. Power Rating in Kilowatts xxxxxxxxxxxxxxx D. Maximum Engine Speed in Rotations per Minute Serial No. xxxxxxxxxx E. Manufacturer’s Name and Address F. Year of Manufacture xxxxxxxxxxxxxxxxxxxxxxx kg: xxx G.

  • Page 6: Limited Warranty

    Limited Wa rranty Hayter Limited warrants to the original user / purchaser that this unit shall be free from defects in material and workmanship under normal use and service for a period of t t hree years from the date of purchase. The manufactur- ers of the engine and battery pack system (where applicable) furnish their own warranty and services are provided through their authorized network (Refer to “Engine/Battery Pack Warranty Statement”).

  • Page 7: Owner's Information

    Owner’s Information Responsibility of the Owner Know Your Product If you under stand the unit and how the unit operates, WARNING you will get the best per formance. As you read this manual, compare the illustrations to the unit. Learn the This cutting machine is capable of amputating location and the function of the controls.

  • Page 8: Safe Operation Practices

    Safe Operation Practices For Ride-On (Riding) Rotary Mower Ma- d. If petrol is spilled, do not attempt to start the engine but move the machine away from the chines area of spillage and avoid creating any source of ignition until petrol vapours have dissipated Training e.
  • Page 9 Safe Operation Practices 16. Reduce the throttle setting during engine run-out 9. When using any attachments, never direct discharge of material toward bystanders nor allow and, if the engine is provided with a shut-off valve, anyone near the machine while in operation. turn the fuel off at the conclusion of mowing.

  • Page 10: Assembly

    Assembly All fasteners are in the parts bag. Do not discard any Install the Seat parts or material until the unit is assembled. 1. Carefully remove the plastic bag from the seat. NOTE: In this Instruction Book, left and right describe 2.

  • Page 11: Assemble The Grass Bag

    Assembly 3. Slide the frame assembly (8) into the grass bag (9) (see Figure 6). Make sure the Velcro flap (10) is on top. (25x3) 4. Open the Velcro flap (10) (see Figure 7). Slide the (17x146) handle (3) through the opening and secure the Vel- cro flap under the handle.

  • Page 12: Assemble The Rear Deflector

    Assembly Assemble the Rear Deflector 6. Push down on the rear handle. A locking spring (15) on the rear plate will secure the bottom of the 1. Mount the carriage bolts (1) in the square holes of grass bag assembly (12) (see Figure 9). the rear plate (2) (see Figure 11).

  • Page 13: Charge The Battery

    Assembly Charge the Battery Check the Level of the Mower Housing Make sure the level of cut is still correct. After you mow WARNING a short distance, look at the area that was cut. If the mower housing does not cut level, see “Level the Mower Housing”.

  • Page 16: Operate On Hills

    Clear the Connector Tube and the Extension Tube Empty the Grass Bagger...

  • Page 17: Before Starting The Engine

    Operation Start the Engine WARNING The electrical system has an operator presence system that includes a sensor switch for the seat. These components tell the electrical system if the operator is sitting on the seat. This system will stop the engine when the operator leaves the seat. For your protection, always make sure this system operates correctly.

  • Page 19: Maintenance Chart

    Frequency Maintenance Required Comments Daily or before each use Maintenance engine. Refer to the Engine Owner’s Manual. Examine blade(s). Check for cracks, wear, and exces- sive damage. Remove debris from unit and moving parts. Examine all rotating and sliding parts. Check tire inflation.

  • Page 20: Maintenance

    Maintenance General Recommendations 1. The owner’s responsibility is to maintain this product. This will extend the life of the product and is also necessary to maintain warranty coverage. 2. Check the spark plug, drive brake, lubricate the unit, and clean the air filter once a year. 3.

  • Page 21: Inspect The Blade

    Maintenance Remove and Install the Blade 1. Remove the mower housing. See “Remove the Mower Housing.” 2. Use a piece of wood to keep the blade from rotating. 3. Remove the nut (3) that holds the blade (1) (see Install the Connector Tube 1.

  • Page 22: Adjust The Blade Rotation Control

    Maintenance WARNING Always keep the nut tight that holds the blade. A loose nut or blade can cause an accident. 11 . Tighten the nut that holds the blade to 41,5 N-m (30 ft-lbs). 12. Install the mower housing. See “Remove the Mower Housing.”...

  • Page 23: Adjust The Shift Lever

    Maintenance 13. When you move the b rotation control to the 4. Push the unit forward. Make sure the gearbox is in DISENGAGE position, all movement will stop neutral. within five seconds. If there is movement of the belt 5. To align the adjuster nut (2) with the hole in the or the blade(s) continue to rotate, engage and dis- shifter bracket (3), turn the adjuster nut (2).

  • Page 24: Check And Adjust The Drive Brake

    Maintenance 6. Assemble the adjustable nut to the parking Remove the Battery brake latch, brake lever and brake spring. Fasten To charge or clean the battery (1), remove the battery with the washer (2) and cotter pin (1). from the unit as follows (see Figure 12). 7.

  • Page 25: Level The Mower Housing

    Maintenance Level the Mower Housing If the mower housing is level, the blade will cut easier and the lawn will look better. WARNING Before you make an inspection, adjustment, or repair to the unit, disconnect the wire to the spark plug.

  • Page 26: Check The Tires

    Maintenance Check the Tires 7. Remove the adjuster nut (2) from the shifter bracket (3). Pull the motion drive belt over the Check the air pressure in the tires. Tires with too much shifter bracket (3) (see air pressure will cause the unit to ride rough. Also, the 8.

  • Page 27: Replace The Mower Drive Belt

    Maintenance 12. To install the motion drive belt, reverse the above 4. To install the mower drive belt, reverse the above steps. steps. 13. Check the routing of the motion drive belt (1) (see 5. Before you mow, check the blade rotation control. F igure 26).

  • Page 29: Order Replacement Parts

    Maintenance Warranty service is available only through Authorized Order Replacement Parts Service Dealers. Locate your nearest dealer in our lo- The replacement parts are shown either on the back cator map at www.murray.com. pages of this Instruction Book or in a separate Parts Replacement parts for the engine, transaxle, or trans- List Book.

  • Page 30: Troubleshooting Chart

    Troubleshooting Chart Solution The engine will not start. 1. Follow the steps, “Start the Engine” in this book. 2. Electric-Start Models: Clean the battery terminals. Tighten the cables. 3. Drain the fuel tank. Clean the fuel line. Replace the fuel filter. 4.
  • Page 31 Troubleshooting Chart Problem Solution The engine will not idle. 1. Replace the spark plug. 2. Clean the air filter. 3. Adjust the carburetor. 4. Adjust the throttle control. 5. Drain the fuel tank. Clean the fuel line. Replace the fuel filter. A hot engine causes a decrease in power.
  • Page 32 Troubleshooting Chart Solution When the clutch/brake pedal is released, belt 1. Temporary belt noise does not change the operation of the unit. If belt noise is continuous, check the routing of the belt. Make sure the noise can be heard. belt is inside all belt guides.
  • Page 36 BRIGGSandSTRATTON Yard Power Products Group Copyright © 2008 Briggs & Stratton Corporation Milwaukee, WI USA. All Rights Reserved...
