Bosch DS7447V2 Series Specifications

Intrusion Alarm Systems | DS7447V2 Series LCD Keypads
DS7447V2 Series LCD Keypads
www.boschsecurity.com
The DS7447V2 is a four-wire alphanumeric liquid
crystal display (LCD) keypad that works with the
DS7060, DS7080iP-32, DS7200 Series, and DS7400Xi
Series Control Panels. It supports all system functions.
The keypad is required for programming the control
panel locally.
Functions
Adjustable Volume and Display
Adjust the non-alarm volume, display brightness, and
display contrast at the keypad.
Accessible Instruction Label
Basic user instructions are on a pull-out slide that you
can install to pull from either the left or the right.
Programmable Emergency Keys
The three unmarked keys across the bottom row of the
keypad are programmable as a fire emergency key, a
special emergency key, and a panic key. Adhesive
labels are provided.
Certifications and approvals
All DS7447V2 Keypad Models:
DS7447V2-FRA Keypad:
EN50131-1 Grades 1, 2, and 3
NF A2P Type 2 Certification
number: 122000076-01
Adjustable volume, display brightness, and display
u
contrast
Accessible instruction label
u
Programmable emergency keys
u
Region Certification
Europe CE 2004/108/EC EMC Directive (EMC),
2006/95/EC Low-Voltage Directive
(LVD); 2011/65/EU Restriction of the
use of certain hazardous substances in
electrical and electronic equipment [-
EXP, -SWE, --FRA, -BEL, -NL, -HU]
Belgium INCERT B-509-0004/c
Installation/configuration notes
Compatibility Information
Control Panels DS7060, DS7080iP-32, DS7400Xi Series,
DS7200 Series
Wiring and Mounting Considerations
The wire length between the keypad and the control
panel cannot exceed 305 m (1000 ft). Do not mount
the keypad outdoors.
Number of Keypads Wire Type
Up to two Unshielded, four-wire,
0.8 mm (22 AWG)
Up to three Unshielded, four-wire,
1.2 mm (18 AWG)
Keypad Distance
from Control Panel
Up to 305 m
(1000 ft)
Up to 305 m
(1000 ft)
