Nady Systems P-Cab Speakers PCS-15X Features, Instructions & Technical Data

F E A T U R E S
AND SPECIFICATIONS
• Full-range, two-way powered speaker
• 15" woofer
• 500W peak (250W RMS)
• Durable but lightweight molded polypropylene enclosures
(designed to deflect bumps and scrapes)
• Versatile design perfect for small room PA (as FOH and
monitor speakers), and studio recording applications
• Can be mounted upright on a speaker stand or lay on its side
to be used as a floor monitor (with included floor wedge mounts)
W A R N I N G S
IMPORTANT SAFETY INSTRUCTIONS
When using this speaker, basic precautions should always be taken, including the following:
• Read all instructions before using the product.
• This product may be capable of producing sound levels that could
cause permanent hearing loss. Do not operate for a long period of
time at a high volume level or at a level that is uncomfortable. If you
experience any hearing loss or ringing in the ears, you should consult
an audiologist.
• To avoid damage to the drivers, never overload the speaker.
• To avoid the risk of fire, do not ever expose the speaker to a source
of naked flames. Also, it should be located away from heat sources
such as radiators, heat vents, or other devices (including amplifiers)
that produce heat.
• The product should be positioned so that proper ventilation
is maintained.
• This speaker is designed for indoor use only. Do not expose to weather
or high humidity, rain, etc.
• Care should be taken so that objects do not fall into, and liquids are
not spilled through, the enclosure's openings. Do not place containers
of liquids on the speaker.
Features, Instructions
& Technical Data
P-Cab Speakers
TM
PCS-15X
Two-Way Powered Speakers
Powerful 2-way active speakers with superior performance, state-of-the-
art versatile design, unprecedented affordability — perfect for all small
venue applications.
Congratulations!
You have just purchased one of the finest powered speakers on the
market today. The P-Cab™ Series was developing using the expertise
of professional sound engineers and working musicians. You will find
your new NADY AUDIO P-Cab™ Series powered speaker has superior
performance and greater flexibility than any other powered speaker in
its price range.
We recommend that you read this instruction sheet carefully to get the
most out of your new unit. Thanks for selecting Nady Audio and our
PCS-15X as your choice in powered speakers.
• Wide-angle, short throw, high-frequency dispersion horns
with 1.5" diameter precision compression driver
• Channel and Master Level controls; Treble and Bass EQs
• XLR balanced RCA and ¼" unbalanced inputs; ¼" unbal-
anced output
• Frequency Response: 40Hz-20KHz
• Compact sizing for ease of portability: 17.3" x 26.6" x 13.6"
(43.9 cm x 67.6 cm x 34.5 cm)
• Lightweight: 52.2 lbs (23.68 kg)
• The product should be connected to a power supply only of the type
described in the operating instructions or as marked on the product.
Replace the fuse only with one of the specied type, size, and correct
rating.
• The power supply cord should: (1) be undamaged, (2) never share an
outlet or extension cord with other devices so that the outlet's or exten-
sion cord's power rating is exceeded, and (3) never be left plugged into
the outlet when not being used for a long period of time.
• Don't place any heavy appliance or object on the speaker enclosure.
• This product should be serviced by qualied service personnel if:
A. Objects have fallen into, or liquid has been spilled onto the
product.
B. The product has been exposed to rain.
C. The product does not appear to operate normally or exhibits a
marked change in performance.
D. The product has been dropped, or the enclosure damaged.
• Do not attempt to service this unit. All servicing should be referred to
qualied service personnel.
