Summary of Contents for Zanussi ZGF 68
-
Page 2: Important Safety Information
Important Safety Information You MUST read hese warnings carefully before installing or using the hob. If you need assistance, contact our Customer Care Department on 08705 727727 Installation Never use plastic or aluminium foil dishes on the hob. This appliance must be installed and serviced by a competent person as stated in the Gas Safety ( Perishable food, plastic items and aerosols may be Installation and Use) Regulations Current Editions... -
Page 3: Table Of Contents
Contents For the Installer For the User Instructions for the Installer Important Safety Information Installation Description of the Hob Conversion from Natural Gas to LPG Operation Commissioning Maintenance and Cleaning Electrical connections Something Not Working? Buiding in Service and Spare Parts This appliance complies with the following E.E.C. -
Page 4: Operation
Operation Hob burners To light a burner: turn the relevant control knob anticlockwise to the maximum position, then push it down to ignite the burner; then, check the flame is regular and adjust it as required. If you cannot light the flame even after several attempts, check the "cap"... -
Page 5: Maintenance And Cleaning
Maintenance and Cleaning Before any maintenance or cleaning can be carried out, you must DISCONNECT the hob from the electricity supply. The hob is best cleaned whilst it is still warm, as spillage can be removed more easily than if it is left to cool. The Hob Top Regularly wipe over the hob top using a soft cloth well wrung out in warm water to which a little washing up... -
Page 6: Something Not Working
Something Not Working? If the hob is not working correctly, please carry out the following checks before contacting your local Service Force Centre. IMPORTANT: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation, a charge will be made even if the appliance is under guarantee. -
Page 7: Instructions For The Installer
Instructions for the Installer Engineers technical data Overall dimensions Rear Left Burner (semi-rapid) Heat Input 2.0 kW (6824 BTU/HR) Width: 580 mm. Depth: 510 mm. Front Left Burner (auxiliary) Heat Input 1.0 kW (3412 BTU/HR) Cut out dimensions Rear Right Burner (semi-rapid) Width: 560 mm. -
Page 8: Important Safety Requirements
Important safety requirements This hob must be installed in accordance with the Gas Location Safety (Installation and Use) Regulations (Current Edition) and the IEE Wiring Regulations (Current Edition). The hob may be located in a kitchen, a kitchen/diner or bed sitting room, but not in a bathroom, shower room or garage. -
Page 9: Installation
Installation IMPORTANT: This hob must be installed by a competent person to the relevant Gas Standards. Please, ensure that, once the hob is installed, it is easily accessible for the engineer in the event of a breakdown. WHEN THE HOB IS FIRST INSTALLED Once the hob has been installed, it is important to remove any protective materials, which were put on in the factory. -
Page 10: Commissioning
Commissioning When the hob has been fully installed it will be necessary to check the minimum flame setting. To do this, follow the procedure below. Turn the gas tap to the MAX position and ignite. Set the gas tap to the MIN flame position then turn the control knob from MIN to MAX several times. -
Page 11: Buiding In
Building In Building over a cupboard or drawer If the hob is to be installed above a cupboard or drawer it It is also recommended to carry out the electrical will be necessary to fit a heat resistant board below the connection to the hob as shown in diagrams 1 and 2. -
Page 12: Cut Out Size
Cut Out Size The dimensions of the cut-out are given in the diagram. Rectangular cut-out size for hob FO 2038 Dimensions are given in mm. - Page 14 www.electrolux.com 35692-6501 05/06...
