- Page 1 User's Manual MX-30 3-CHANNEL DJ MIXER www.altoproaudio.com Version 1.3 October 2005 English...
- Page 3 SAFETY RELATED SYMBOLS Fuse To prevent fire and damage to the product, use only the recommended fuse type as indicated in this CAUTION manual. Do not short-circuit the fuse holder. Before RISK OF ELECTRIC SHOCK DO NOT OPEN replacing the fuse, make sure that the product is OFF and disconnected from the AC outlet.
- Page 4 LTO MX-30 is an extremely flexible 3-Channel DJ Mixer, configured with three input channels, which is equipped with a variety of key features including 3 phone/line inputs; 1microphone input; treble, middle and bass EQ on each channel, crossfader curve etc..
-
Page 5: Table Of Contents
TABLE OF CONTENTS 1. INTRODUCTION.............................4 2. FEATURE LIST............................4 3. CONTROL ELEMENTS..........................5 3.1 The Top Cover 3.1.1 CHANNEL Section 3.1.2 MAIN OUT Section 3.1.3 PFL Section 3.1.4 LEVER METER Section 3.1.5 CROSSFADER Section 3.2 The Front Panel 3.2.1 MIC IN Jack 3.2.2 PHONE OUT Jack 3.2.3 REVERSE Switch 3.2.4 CROSSFADER CURVE Control... -
Page 6: Introduction
1. INTRODUCTION What a great DJ mixer you have just bought. Your MX-30 is packed with features such as 3 turntable inputs 3 line inputs, 1 microphone input, 3 bands equalizer and gain control for per channel etc.. Through your MX-30 is very easy to operate, for getting the best out of your MX-30, please go through this manual carefully. -
Page 7: Control Elements
3. CONTROL ELEMENTS 3.1 The Top Cover MX-30 CHANNEL 1 CHANNEL 2 CHANNEL 3 3-CHANNEL DJ MIXER PHONO PHONO PHONO MAIN OUT LINE LINE LINE LINE LINE LEVEL METER GAIN GAIN GAIN OUT A -30dB +15dB -30dB +15dB -30dB +15dB... -
Page 8: Channel Section
3.1.1 The CHANNEL Section CHANNEL 1 -. MIC to PHONO-LINE Switch The channel 1 is equipped with the MIC to PHONO-LINE PHONO switch. This switch is used to select microphone input and LINE phono/line Input. When it is in the right position, you can use the PHONO/LINE switch on the rear panel to input the line signal to the phono input connector. -
Page 9: Main Out Section
You can turn off the TALK function via this button 3.1.3 The PFL Section When you connect a headphone to your MX-30, you have the chance of pre-listening the audio signal before the signal PFL LEVEL reach the main output. -
Page 10: Crossfader Section
3.1.5 The CROSSFADER Section -. FADER Control CH 2 CH 3 Through this crossfader you can fade in between channel 2 and channel 3. The crossfader on your MX-30 is user re- placeable. 3.2 The Front Panel REVERSE HOLD SMOOTH... -
Page 11: The Rear Panel
3.3.1 AC Inlet and Fuse Holder Use it to connect your MX-30 to the main AC with the supplied AC cord. Please check the Voltage available in your country and make sure the voltage is identical to the values marking on the product. Replace the fuse with the same type by the qualified personnel only. -
Page 12: Effects Send And Return
You can send the PFL signal through the SEND sockets to a signal processor such as reverb, equaliser, etc.. Then from the same effect unit you bring the signal back into the MX-30 via the RETURN sockets and the audio signal is routed into the MAIN output. -
Page 13: Technical Specifications
4. TECHNICAL SPECIFICATIONS INPUTS 40dB gain@1kHz,unbalanced Phono Inputs 1,2 and 3 Line Inputs 1,2 and 3 0dB gain, unbalanced Mic Input 40dB gain, servo-balanced 0dB gain, unbalanced Return OUTPUTS Headphones typically 125mW@ 1% THD Main Out max +21dBu Booth Out max +21dBu Tape Out typically 0dBu... -
Page 14: System Block Diagram
5. SYSTEM BLOCK DIAGRAM Amplifier Controlled Volta... -
Page 15: Warranty
6. WARRANTY 1. WARRANTY REGISTRATION CARD To obtain Warranty Service, the buyer should first fill out and return the enclosed Warranty Registration Card within 10 days of the Purchase Date. All the information presented in this Warranty Registration Card gives the manufacturer a better understanding of the sales status, so as to purport a more effective and efficient after-sales warranty service. - Page 16 No. 1, Lane 17, Sec. 2, Han Shi West Road, Taichung 40151, Taiwan http://www.altoproaudio.com Tel: 886-4-22313737 email: alto@altoproaudio.com Fax: 886-4-22346757 All rights reserved to ALTO. All features and content might be changed without prior notice. Any photocopy, translation, or reproduction of part of this manual without written permission is forbidden. Copyright...
