- Page 1 Cordless Circular Saw MODEL 5620D 001320 I N S T R U C T I O N M A N U A L WARNING: For your personal safety, READ and UNDERSTAND before using. SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE.
-
Page 2: Specifications
SPECIFICATIONS Model 5620D Blade diameter 165 mm at 90° 54 mm Max. Cutting depth at 45° 38 mm 2,600 No load speed (min Overall length 364 mm Net weight 3.4 kg Rated voltage D.C. 18V • Due to our continuing programme of research and development, the specifications herein are subject to change without notice. -
Page 3: Safety Instructions
SAFETY INSTRUCTIONS ENA002-2 WARNING: When using battery operated tools basic safety precautions, including the following, should be followed to reduce the risk of fire, leaking batteries and personal injury: Read these instructions before operating this product and save these instructions. 14. - Page 4 ADDITIONAL SAFETY RULES FOR TOOL ENB077-1 Be aware that this tool is always in an operating condition, because it does not have to be plugged into an electrical outlet. Wear hearing protection. Keep Guards In Place and In Working Order. Never wedge or tie lower guard open.
- Page 5 15. Avoid Cutting Nails. Inspect for and remove all nails from lumber before cutting. 16. Operate with proper hand support and proper workpiece support. WARNING: It is important to support the workpiece properly and to hold the saw firmly to prevent loss of control which could cause personal injury.
- Page 6 IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY CARTRIDGE ENC004-1 (1) Do not touch the terminals with any con- Before using battery cartridge, read all instruc- tions and cautionary markings on (1) battery ductive material. charger, (2) battery, and (3) product using bat- (2) Avoid storing battery cartridge in a con- tery.
-
Page 7: Functional Description
FUNCTIONAL CAUTION: DESCRIPTION • Always be sure that the tool is switched off and the battery cartridge is removed before adjusting or checking function on the tool. Installing or removing battery cartridge 001328 • Always switch off the tool before insertion or removal of the battery cartridge. - Page 8 • Use only the Makita wrench to install or remove the blade. To remove the blade, press the shaft lock so that the blade cannot revolve and use the wrench to loosen the hex bolt clockwise. Then remove the hex bolt, outer flange and blade.
-
Page 9: Operation
Hex wrench storage 001453 When not in use, store the hex wrench as shown in the figure to keep it from being lost. 1. Hex wrench OPERATION CAUTION: • Be sure to move the tool forward in a straight line gently. Forcing or twisting the tool will result in overheating the motor and dangerous kickback, possibly causing severe injury. -
Page 10: Maintenance
To maintain product SAFETY and RELIABILITY, repairs, any other mainte- nance or adjustment should be performed by Makita Authorized Service Cent- ers, always using Makita replacement parts. 1. Brush holder cap... - Page 11 CAUTION: • These accessories or attachments are recommended for use with your Makita tool specified in this manual. The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose.
- Page 12 Makita Corporation Anjo, Aichi, Japan 884192D1...
